- Page 1 Operating Instructions Liquid Level Transducer Model: MM Series & NBK level transmitter options...
-
Page 2: Table Of Contents
MM series, NBK-transmitter options 1 Contents Contents ..............................2 Note ............................... 3 Instrument Inspection ..........................3 Regulation Use ............................4 Float types ............................. 4 Operating Principle ..........................5 Mechanical Connection ......................... 5 Area of application ..........................5 Maintenance ............................6 Technical details............................ -
Page 3: Note
If you need an instruction manual that correspond to the purchased product version, you can request it from us free of charge by email (info.de@kobold.com) in PDF format, specifying the relevant invoice number and serial number. If you wish, the operating instructions can also be sent to you by post in paper form against an applicable postage fee. -
Page 4: Regulation Use
MM series, NBK-transmitter options 4 Regulation Use Kobold level transducers are used for the continuous level indication and level control of all kinds of liquids. The simple design with only one moving part (the float) is suitable for applications that demand reliability. Kobold level transducers allow the continuous level indication and level control of liquids unaffected by electrical conductivity, temperature, pressure. -
Page 5: Operating Principle
The Kobold-liquid Level Transducers model MM consist of a tube around which a float travels with inserted magnet, like the Kobold level float switch model M, models without float around the tube, the float is placed in an adjacent bypass tube to actuate the reed chain contacts inside the tube. -
Page 6: Maintenance
MM series, NBK-transmitter options 9 Maintenance In liquids that can cause deposits, the float has to be cleaned at regular intervals. In this case the measuring tube and float should be cleaned from such deposits (valid for models where float is directly guided on the reed chain). Other maintenance jobs are not required. - Page 7 MM series, NBK-transmitter options Model LCD touch screen (KMDFON) Exi Option D (MM): Version with display model D: 14,5…35 Vdc Ex ia parameters: Ui:30 Vdc, Ii:100 mA, Pi:0,75 W, Li:10uH, Ci:15nF Model LCD touch screen + relays (KMDFON) non Ex Option R (MM): Version with display model R: 14,5…35 Vdc...
- Page 8 MM series, NBK-transmitter options Dead band: MM-M05* Top: 30 mm, Bottom: 40mm MM-M15* Top: 52 mm, Bottom: 50 mm MM-M07* Top: 27 mm, Bottom: 40 mm MM-M16* Top: 45 mm, Bottom: 50 mm MM-M13* Top: 25 mm, Bottom: 60 mm...
-
Page 9: Head Transmitter
MM series, NBK-transmitter options 11 Head transmitter Part Nr. 903.505: Option M (NBK) analogue output 4…20 mA, 2 wires Model 5333D: Option M (MM), A (NBK) analogue output 4…20 mA, 2 wires, Sensor error action : Namur upscale (23 mA) -
Page 10: Wiring Diagram Resistance Output Sensor (Model Mm-Options P/S/Y/2, Model Nbk-Option W/2/4)
MM series, NBK-transmitter options 13.2 Wiring diagram resistance output sensor (Model MM-Options P/S/Y/2, Model NBK-Option W/2/4) Resistance value Resistance value decreases increases Signal proportionally with proportionally with level increase. level increase Models with cable white Brown Green Models with box... -
Page 11: Wiring Diagram With Touch Screen Lcd Display Type R (Kmdfon) (Model Mm)
MM series, NBK-transmitter options 13.4 Wiring diagram with touch screen LCD display type R (KMDFON) (model MM) 13.5 Wiring diagram with LED display options E (LPI02) (MM), options LE/KE/AE/HE (NBK) 13.6 Wiring diagram with LCD display options C (ST0028) (MM),... -
Page 12: Electrical Connection In Intrinsically Safe Mode Ex Ia (Mm)
MM series, NBK-transmitter options 13.7 Electrical connection in intrinsically safe mode Ex ia (MM) page 12 DT0593... -
Page 13: Electrical Connection In Explosion Proof Mode Ex D (Mm)
MM series, NBK-transmitter options 13.8 Electrical connection in explosion proof mode Ex d (MM) 13.9 Electrical connection in intrinsically safe mode Ex ia (NBK Sensor/transmitter options E, R, B) page 13 DT0593... -
Page 14: Electrical Connection In Explosion Proof Mode Ex D (Nbk Sensor/Transmitter Options 4, L, K, N)
MM series, NBK-transmitter options 13.10 Electrical connection in explosion proof mode Ex d (NBK Sensor/transmitter options 4, L, K, N) page 14 DT0593... -
Page 15: Safety Instructions ( Atex )
MM series, NBK-transmitter options 14 Safety Instructions ( ATEX ) 14.1 Area of validity These security instructions apply to MM…E (reed chain for NBK Sensor/transmitter options 2/E/R/B) and MM…F (reed chain for model NBK Sensor/transmitter options 4/L/K/N) series magnetic level sensor for use in explosion-proof atmospheres conforming to certificate LOM 06ATEX2054 X and MM…F (NBK…4/L/K/N) series conforming to certificate LOM 14ATEX2075 X... -
Page 16: Protection Against Esd (Electrostatic Discharges)
14.5 Maintenance and repairs The instrument does not require maintenance or servicing. Repairs must be only carried out by Kobold Mesura (manufacturer). 14.6 Storage Measuring instruments should be protected against humidity and dust. -
Page 17: Installation In Hazardous Zone
MM series, NBK-transmitter options 15 Installation in hazardous zone In classified zones, magnetic level switches series MM…E (reed chain for NBK Sensor/transmitter options 2/E/R/B) (intrinsically safe version), can be installed in zone 0, 1, 2 and series MM…F (reed chain for model NBK Sensor/transmitter options 4/L/K/N) (explosion proof version) can be installed in zone 0,1, 2, 21, 22. -
Page 18: Disposal
Electrical and electronic equipment 19 Technical Information Operating instructions, data sheet, approvals and further information via the QR code on the device or via www.kobold.com 20 Order Codes Operating instructions, data sheet, approvals and further information via the QR code on the device or via www.kobold.com... -
Page 19: Declaration Of Conformity Atex Ex Ia
Inscription Certificazione per esame di tipo CE Marcatura LOM06ATEX2054X II 1 G Ex ia IIC T6 Ga Fabricado en KOBOLD MESURA SLU Avda. Conflent 68 nave 15 08915 BADALONA (Spain Made in: Hergestellt in: Fabriqué dans: Fabbricato in: Organismo notificado LOM 0163 Número notificación... -
Page 20: Declaration Of Conformity Atex Ex D
LOM 14ATEX2075 X II 1/2 G Ex d IIC T1..T6 Ga/Gb II 2 D Ex t IIIC T410..T85ºC Db Fabricado en KOBOLD MESURA SLU Avda. Conflent 68 nave 15 08915 BADALONA (Spain Made in: Hergestellt in: Fabriqué dans: Fabbricato in:... -
Page 21: Eu Declaration Of Conformity
Angewandte harmonisierte Normen und normativer Dokumente: Normes harmonisées et documents normatifs appliqués Norme armonizzate e documenti normativi applicati: EN61000-6-2:2019 EN61326-1:2021 Fabricado en KOBOLD MESURA SLU Avda. Conflent 68 nave 15 08915 BADALONA (Spain) Made in: Hergestellt in: Fabriqué dans: Fabbricato in: Badalona March 2024... -
Page 22: Declaration Of Conformity
DICHIARAZIONE DI CONFORMITÀ UK KOBOLD MESURA SLU Avda. Conflent, 68 nave 15 08915 Badalona (España) We Kobold Mesura S.L.U. declare under our sole responsibility that the product: Liquid Level Transducers MM… / NBK ... To which this declaration relates is in conformity with the standards noted below:... -
Page 23: Ec-Type Certificate
MM series, NBK-transmitter options 26 EC-Type certificate page 23 DT0593... - Page 24 MM series...
- Page 25 MM series page 25 DT0493...
- Page 26 MM series page 26 DT0493...
- Page 27 MM series page 27 DT0493...
- Page 28 MM series page 28 DT0493...
- Page 29 MM series page 29 DT0493...
- Page 30 MM series page 30 DT0493...
- Page 31 MM series page 31 DT0493...
- Page 32 MM series page 32 DT0493...
-
Page 33: Avda. Conflent 68 Nave 15
KOBOLD MESURA S.L.U Avda. Conflent 68 nave 15 08915 Badalona Tel.: +34 93 460 38 83 Fax: +34 93 460 38 76 E-Mail: info.es@kobold.com www.kobold.com Technical data Subject to change without prior notice...
