Kobold KP46 Series Quick Start Manual

Explosion-proof pressure transducers

Advertisement

Quick Links

User's Responsibility for Safety: KOBOLD manufactures a
wide range of process sensors and technologies. While each
of these technologies are designed to operate in a wide
variety of applications, it is the user's responsibility to select a
technology that is appropriate for the application, to install it
properly, to perform tests of the installed system, and to
maintain all components. The failure to do so could result in
property damage or serious injury.
Wiring and Electrical: Because this is an electrically
operated device, only properly trained personnel should install
and maintain this product. Be sure that the power supplied to
the unit is appropriate for the electronics version supplied.
Electrical wiring of the sensor MUST be performed in
accordance with all applicable national, state and local codes
AND in accordance with the most recent version of the
National Electric Code ANSI/NFPA 70 (NEC) Articles 500
thorough 505.
Specifications:
Available Ranges: 0-50 through 0-20000 PSIG
Over Range Protection: 2X full scale
Burst Pressure: 5X full scale
Cycle Life: >100 million cycles
Process Connection: ¼" MNPT (to 10K PSIG),
½" MNPT (15K & 20K PSIG)
Wetted Materials: 316 L Stainless Steel
others available upon request
Corrosion Resistance: Complies with NACE MR0175
Linearity: ±0.25% BFSL
Zero Offset: <±1% of full scale
Span Tolerance: <±2% of full scale
Media Temp Range: -55 to +250°F
Ambient Temp Range: -40-185°F
Compensated Range: 30 to 130°F
Temp. Drift: <±1.5% of full scale for zero
and span over the compensated range
Shock Resistance:100G, 11mSec.
Vibration Resistance: 10G peak, 20-2000Hz
Stability (1 year): ±0.25% of full scale
Electrical Specifications:
Output: 4-20 mA, 2-wire
Input Power Supply: 10-28 VDC
Max. Loop Load: 800 Ohms
Elec. Connection: ½" NPT Conduit with 6 Ft. 18 AWG wire leads
Elec. Protection: NEMA 4X / IP 66
KOBOLD Instruments Inc.
1801 Parkway View Drive
Pittsburgh, PA 15205
PH: 412-788-2830
FAX: 412-788-4890
www.koboldusa.com
Precautions
Make a Fail-Safe System: Design a fail-safe system
that accommodates the possibility of sensor, relay or
power failure. In critical applications, KOBOLD
recommends the use of redundant backup systems and
alarms in addition to the primary system.
Hazardous Location Approval: CSA approved to
standards CSA 30 and U.L. 1203, Explosion-Proof for
Class 1, Div 1 Groups A, B, C, D and Div. 2 Groups A,
B, C, D for use in Hazardous Areas
- ANSI/ISA 12.27.01-2003 Single
Seal Approved
- CE EN61326 as per CECV,
Canadian Electrical Code
Variance
Wiring Connections:
CAUTION: BE SURE THAT POWER IS DISCONNECTED
BEFORE PROCEEDING!
4-20 mA, 2-wire Output
Red: +V Supply (10-28VDC)
Black: + Signal Output (4-20mA)
Green: Case/Equipment Ground
Installation:
1. Mount the transmitter so that the sensor port will not
become clogged with sediment or debris that could
hamper the sensing ability.
2. Although the transmitter is highly vibration resistant, it is
always good practice to mount the device appropriately to
minimize any potentially damaging shock and vibration.
3. Apply PTFE tape, or other appropriate thread sealant to
the NPT pressure fitting thread before installation. Tighten
the device using the 7/8" Hex next to the pressure
connection. DO NOT USE A PIPE WRENCH ON THE
TRANSMITTER HOUSING!
Series KP46
Explosion-Proof
Pressure Transducers
FM Rev. 05/10/13
KP46_manual_5-13
