Network Video Server User's Guide
Network Video Server
Model 550000
User's Guide V1.1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 550000 and is the answer not in the manual?

Questions and answers

Related Manuals for Intellinet 550000

Summary of Contents for Intellinet 550000

  • Page 1 Network Video Server User’s Guide Network Video Server Model 550000 User’s Guide V1.1...
  • Page 2 - Increase the separation between the equipment and receiver - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Network Video Server 550000 User Manual Copyright March 2006...

  • Page 3: Important Notice

    4. In the event that the NETWORK VIDEO SERVER does not function properly, please contact your INTELLINET NETWORK SOLUTIONS dealer for assistance. Do not disassemble the product, as this may void the service warranty. 5. It is important to carefully examine the contents upon opening the package. If there are any components missing, please contact your INTELLINET NETWORK SOLUTIONS dealer.

  • Page 4: Table Of Contents

    Network Video Server User’s Guide TABLE OF CONTENTS PRODUCT OVERVIEW ............................6 NETWORK VIDEO SERVER......................6 BOUT .........................7 EATURES AND ENEFITS ............................9 YSTEM EQUIREMENTS PHYSICAL DESCRIPTION ..........................10 ................................10 ONTENTS ..............................11 RONT ANEL ..........................13 NSTALLATION VERVIEW ASSIGNING IP ADDRESS & ACCESSING NETWORK VIDEO SERVER’S HOMEPAGE ....14 IP A ..........................14 CCESS VIA...
  • Page 5 Network Video Server User’s Guide H. D (DDNS) ....................64 YNAMIC OMAIN ERVICE DNS DDNS ......................67 OW TO USE SERVER I. H ..........................71 PEED OLUTIONS J. R ..................73 EINSTATING THE ACTORY EFAULT ETTINGS K. G ...........................75 LOSSARY OF ERMS...

  • Page 6: Product Overview

    Network Video Server User’s Guide PRODUCT OVERVIEW About NETWORK VIDEO SERVER The NETWORK VIDEO SERVER is a network CCD camera server with an integrated Internet Server, image compression device, flash memory, and many other features. No other hardware is necessary for use. The NETWORK VIDEO SERVER relays video source from a CCD camera to network and provides real time images over networks and the Internet.

  • Page 7: Main Features And Benefits

    Using a standard web browser, you can configure and manage the NETWORK VIDEO SERVER directly from its own embedded web pages. The embedded operating system is upgradeable through the network; please check with your local INTELLINET NETWORK SOLUTIONS dealer for firmware upgrades.
  • Page 8 Network Video Server User’s Guide Embedded Linux Operating System NETWORK VIDEO SERVER uses an embedded Linux operating system within its 32bit RISC CPU. Linux like other UNIX is one of the most stable operating system available. There is very little chance of the operating system crashing. Real-time JPEG compression Video input can be efficiently compressed into packets of JPEG images without delay.

  • Page 9: System Requirements

    Network Video Server User’s Guide System Requirements Network 10Base-T Ethernet or 100Base TX Fast Ethernet Recommended PC or Notebook to Access the NETWORK VIDEO SERVER. System requirement: CPU : Pentium II, 266 MHz or above Memory Size: 32 MB (64MB recommended) VGA card resolution: 800x600 or above Web Browser: Internet Explore 5.0 or above (Active X &...

  • Page 10: Physical Description

    INTELLNET Copyright by I/O Terminal connector Quick Installation Guide INTELLINET Network Video Server Model 550000 Quick Installation Guide If any item is missing, or if you find any damage or mismatch, promptly contact your INTELLINET NETWORK SOLUTIONS dealer for assistance.

  • Page 11: Front Panel

    Network Video Server User’s Guide Front Panel Video Video Output Network LED Power On Air LED Video Input To input video signal through a coaxial cable Video Output : To output video signal through a coaxial cable. (Roof-through from “Video Input” BNC connector) PWR LED (RED): This LED indicates the status of Power on and off.

  • Page 12: Rear Panel

    Network Video Server User’s Guide Rear Panel Power Ethernet RS232/485 Port Digital Input Power Out Digital Output Power Connector: Only use the AC Adapter provided by your dealer to avoid any possible damage from electric shock. Power Out, Digital Input, Digital Output To connect external devices such as infrared Sensors, alarms, or motion detectors (please refer to Appendix F –...

  • Page 13: Installation Overview

    Network Video Server User’s Guide Installation Overview Installation Summary Connect Ethernet and Power to NETWORK VIDEO SERVER on local network for configuration Insert a program CD of NETWORK VIDEO SERVER to a PC on local network Assign an IP address with IP installer to NETWORK VIDEO SERVER and configure administrator’s condition Configure Users and Access Rights Connecting...

  • Page 14: Assigning Ip Address & Accessing Network Video Server's Homepage

    Network Video Server User’s Guide ASSIGNING IP ADDRESS & ACCESSING NETWORK VIDEO SERVER’S HOMEPAGE Access via IP Addresses To access the NETWORK VIDEO SERVER, you need to assign an appropriate network IP address. Important To access NETWORK VIDEO SERVER, you first should assign an appropriate IP address. When you assign an IP address to NETWORK VIDEO SERVER, make sure to use an unoccupied IP address which is in the same subnet as the rest of your Network •...

  • Page 15: Installing Network Video Server In Your Network

    Network Video Server User’s Guide Installing NETWORK VIDEO SERVER in your Network 1. Connecting with direct cable (Non Crossover UTP cable). Used when connecting the NETWORK VIDEO SERVER to a switch, hub or router. Leased Line, xDSL Line, etc Internet ROUTER Remote User Direct Cable...

  • Page 16: Installation Using Windows Ip Installer

    Network Video Server User’s Guide Installation Using Windows IP Installer To install an IP address, you should use the IP Installer provided with NETWORK VIDEO SERVER. After you start IP INSTALLER it scans your network for available NETWORK VIDEO SERVERS and NETWORK IP CAMERAS.
  • Page 17 Network Video Server User’s Guide Information on IP Addresses 1. If you do not know which IP Address you have to enter in IP INSTALLER you should ask your Network Administrator for an available IP Address. 2. In case you are installing Network IP Camera in Home Network which communicates to the Internet using a Broadband Router, you should perform the following steps: 2.1.
  • Page 18 Network Video Server User’s Guide Assigning IP Address by using Hyper Terminal (Advanced Users only) This chapter is for advanced users only. Normally it is not required to access the camera via Hyper Terminal. The installation via IP INSTALLER is the preferred method. You may skip this chapter and continue with “Accessing NETWORK VIDEO SERVER Homepage”.
  • Page 19 Network Video Server User’s Guide ③ Configure bit/sec as 19200 and leave other settings at the default values. ④ The panel shows up like thus image when configured properly. (If it doesn’t, please try again from beginning)
  • Page 20 Network Video Server User’s Guide Assigning IP Address Follow these steps to assign an IP address using Hyper Terminal 1. Execute “Hyper Terminal” on your PC 2. Connect RS232 Cable to the serial port of PC that you have selected in Chapter 4.3.1 - Configuring Hyper Terminal and the NETWORK VIDEO SERVER serial port while Hyper Terminal is executed.
  • Page 21 Network Video Server User’s Guide 6. You can see Network Configuration while [Boot] Prompt is running by pressing ‘p’ key again. Here, inet on ethernet (e), host inet (h) and gateway inet (g) values are network configuration values. You should review these values and change accordingly. If you don’t know what value you should assign, contact your network administrator.
  • Page 22 Network Video Server User’s Guide Gateway inet (g) is the gateway address of Network Camera 7. Type ‘c’ key to change the network configuration in [Boot] prompt. If you type ‘c’ key, NETWORK VIDEO SERVER shows you the information you can change its values and the current assigned values.

  • Page 23: Accessing Network Video Server

    Network Video Server User’s Guide Accessing NETWORK VIDEO SERVER After assigning NETWORK VIDEO SERVER an IP address you may access NETWORK VIDEO SERVER and monitor real-time image on Internet. You may configure NETWORK VIDEO SERVER with any standard Web browser on local or remote network. Starting Web Browser Start your web browser and enter the IP Address of Network Video Server.
  • Page 24 Network Video Server User’s Guide 1. ID and Password If you key in a user ID and password, you can access the camera to monitor real-time video. With administrator’s ID and password, you can access real-time video with administrator’s authority. The default value of both user ID and password are “admin” and the administrator may change it at the Administrator Menu.
  • Page 25 If Active-X program fails to be installed automatically, you may install it manually. The manual installation program is to be downloaded by clicking ‘here’ as follows: Note: If you have any problem when you install ActiveX, visit http://www.intellinet- to download and install ActiveX manually. network.com/driver/NetCam.exe Please follow the instructions to install Active-X manually.
  • Page 26 Network Video Server User’s Guide 4) Java Applet for Macintosh or Unix/Linux System users and Windows Users who do not use MS Internet Explorer If you are using Microsoft Windows as the Operating System and use MS Internet Explorer as the primary web browser, than there is no need to use the JAVA Applet.
  • Page 27 Network Video Server User’s Guide NETWORK VIDEO SERVER Homepage Having completed the login procedure, you now see the NETWORK VIDEO SERVER homepage 1. Connected Client It show the number of multi access users. (100 multi users can be accessed simultaneously.) 2.
  • Page 28 Network Video Server User’s Guide 4. Save, Stop save, snap shot, show only image ① Save, stop save Users can save real time images from NETWORK VIDEO SERVER on PC. Press ‘save’ button then select folder that you want to save images. (The image is saved as an AVI file.) Once it starts to save images, “Saving”...
  • Page 29 Network Video Server User’s Guide ② Snap Shot To save only one image, press “snap shot” button and then select a folder. Save the image as JPG file. (Default file name dedicate the date and time) ③ Show only image When you want to see only video panel, Press “show only image”.

  • Page 30: Configuring Administration Tools

    Network Video Server User’s Guide CONFIGURING ADMINISTRATION TOOLS Press “Administrator Menu”. You can control the configurations of NETWORK VIDEO SERVER by Administrator’s Tool. Only authorized user can access administrator tool. If non-authorized users try to access it, you may see the caution message “You are not an administrator”. You may control all configurations for NETWORK VIDEO SERVER.

  • Page 31: Administration Menu's Overview

    Network Video Server User’s Guide Administration Menu’s Overview The table below provides a one-step overview of the Administrations Tools: Image Configuration To configure compression rate, image size, brightness, contrast, etc. Network Configuration To configure camera IP, web server port, image transfer port User Configuration To configure user ID &...

  • Page 32: Image Configuration

    Network Video Server User’s Guide Image Configuration NETWORK VIDEO SERVER Image Parameters Video Input Network Video Server supports two different types of analog video Signals: NTSC and PAL. NTSC is used in the United States mainly while PAL is being used across the globe, especially in Europe. Ultimately this setting depends on the standard which the CCTV Camera you connect supports.
  • Page 33 Network Video Server User’s Guide Image size You may choose the image size VGA (640x480) or QVGA (320x240) and SQVGA (160*120). Larger resolutions g lower frame rates while small sizes result in higher frame rates. Vertical Flip To turn the image view upside down (no effect on images uploaded via FTP or Email!). Horizontal Flip To switch the image view right from left (no effect on images uploaded via FTP or Email!).

  • Page 34: Network Configuration

    Network Video Server User’s Guide Network Configuration This screen defines the network type and addresses of the NETWORK VIDEO SERVER. Here you can configure the Camera’s IP address, the DNS server, the DDNS Setup and the SMTP Server.
  • Page 35 Network Video Server User’s Guide 1. Set IP Address, Subnet mask, gateway address. To set the IP address, Subnet mask, and gateway address manually, you may select “manually” in combo box. In case of selecting “manually”, you can configure them with the IP installer as well as this page.
  • Page 36 ETSP port number (ETSP Client currently not available) To set the port number for ETSP (Event Trigger Saving Program). (Default is “11000” and users can select from 8000 to 65535. ETSP can be downloaded for free from the INTELLINET NETWORK SOLUTIONS Web Site once available.
  • Page 37 Network Video Server User’s Guide Use SMTP authentication If you need user authentication for using the SMTP server, check in a box. and enter you ID, Password and Realm for your SMTP server. (The NETWORK VIDEO SERVER’s SMTP authentication is supporting “LOGIN” method) - Authentication method: Choose the SMTP authentication method.

  • Page 38: User Configuration

    Network Video Server User’s Guide User Configuration This screen is used to configure IDs and Passwords for an administrator and up to 5 users. User Account (max. 10 characters) There is one administrator account and 5 user accounts. Account names can be changed. Password (max.

  • Page 39: Event Trigger Configuration

    Network Video Server User’s Guide Event Trigger Configuration NETWORK VIDEO SERVER can perform certain tasks without user interaction. It can send images via Email or upload JPG images to an FTP Server, i.e. an Internet Web Server or a shared network drive.

  • Page 40: Motion Detection

    Network Video Server User’s Guide 1. Trigger Condition This is to select option how to send an event signal to NETWORK VIDEO SERVER. ① Activation of digital input port The NETWORK VIDEO SERVER receives an event signal from external devices such as infrared Sensor Alarm sensor etc.
  • Page 41 Network Video Server User’s Guide 2. Image capture option This is to configure image capture option when an event is triggered. ① Before Event You may set the starting time to capture image before event is triggered. (Input limitation is from 0 to 21 seconds.) ②...
  • Page 42 Network Video Server User’s Guide 3. Trigger Output Here you define which action the camera is to perform when a trigger condition is met. 1. External devices signal output This is to supply voltage to output port when events are triggered. (This option is only activated when you select “Activation of digital output”...

  • Page 43: Time Configuration

    Network Video Server User’s Guide Time Configuration This screen is to configure date and time. 1. Synchronized with NTP server The NETWORK VIDEO SERVER automatically configures Date & Time through the NTP (Network Time Protocol) server. The NTP Server is based on Greenwich time. Select NTP server, IP address and Time zone.

  • Page 44: System Configuration

    Network Video Server User’s Guide System Configuration This screen is used to configure camera name, location, and image sensor oscillator for frequency, PTZ control and System information for NETWORK VIDEO SERVER. 1. Server name You can enter the Name of your camera here. The name must not be longer than 15 characters. 2.
  • Page 45 Network Video Server User’s Guide 4. Direct public access to image via HTTP Controls access to the live image via http command http://camera_address/jpg/image.jpg. This feature can be important when using the Video Server in 3 party video surveillance systems. With Direct Public Access disabled a username and password must be provided in order to view the image.

  • Page 46: Ptz Control (Only For Use With Ptz Cctv Cameras)

    Network Video Server User’s Guide PTZ CONTROL (only for use with PTZ CCTV Cameras) This screen is to control PTZ function. This PTZ control box may be activated only if PTZ external devices are connected to NETWORK VIDEO SERVER and configure PTZ control enable in System Configuration screen.

  • Page 47: Poe (Power Over Ethernet) Support

    The current enters the cable by means of a component called an injector. As the NETWORK IP CAMERA 550710 and NETWORK VIDEO SERVER 550000 are PoE compatible, then they will function properly without modification when connected to PoE injector directly using standard LAN cable as shown below.

  • Page 48: Appendix

    Network Video Server User’s Guide APPENDIX A. Technical Specifications Image Resolution: 640x480, 320x240, 160x120 Standard JPEG Compression – 10 levels of compression Network 10BaseT Ethernet or 100Base-TX Fast Ethernet Twisted pair category 5 cables, Standard RJ45 connector Supporting protocol: TCP/IP, UDP, PING, ARP, FTP, TFTP, and HTTP Configuring is achieved by private setup program and Web server built in administration page.
  • Page 49 Network Video Server User’s Guide Approvals EMC: FCC Class B, CE EN55022/1994, EN61000-3-2 & 3: 1995, EN50082-1: 1997 Operating Temperature 0 ~ 50 Degrees Centigrade Others Operating Status LED, Power LED, Image Capture LED, Network Packet Transmit LED EEPROM clear button...
  • Page 50 Network Video Server User’s Guide B. Frequently Asked Question (FAQ) Asks for the features What is a Video Server? A Network Video Server is a network CCD camera server with an integrated Internet Server, image compression device, flash memory, and many other features. No other hardware is necessary for use.
  • Page 51 In this case the use of a 3 Part Video Surveillance Software is mandatory. A list of tested applications can be found at the INTELLINET NETWORK SOLUTIONS Web Site. How does the built-in motion detection work? It very simply compares what it sees now to what it saw in the last frame and based on a sensitivity you select will trigger an event.

  • Page 52: Trouble Shooting

    PC 2002, Windows Mobile 2003 and Windows Mobile 2005 devices, such as the Compaq iPAQ, HP Jornada, Dell Axim, Casio Cassiopeia and many other devices. The free Pocket PC Viewer can be downloaded from the INTELLINET NETWORK SOLUTIONS Web Site.
  • Page 53 Network Video Server User’s Guide Symptoms, Possible Causes and Remedial Actions Symptoms Possible causes Remedial actions NETWORK VIDEO address 1.Disconnect your NETWORK VIDEO SERVER SERVER cannot already used by another from the network accessed from a Web devices 2. Run the PING utility (as described in PINGing browser your IP Address below) and follow The Power LED is not...
  • Page 54 The camera is not Referring to the above, adjust the camera manually Focused correctly NOTE If you still have a problem after reading this information, please contact your dealer or check the FAQ on the INTELLINET NETWORK SOLUTIONS web site at http://www.intellinet-network.com.

  • Page 55: Utilizing Ip Addresses On Local Network

    Network Video Server User’s Guide D. Utilizing IP Addresses on Local Network Introduction Access to the Internet is achieved via Internet IP addresses. Currently, IP addresses are limited. There are 5 classes of networks, and each network contains IP addresses. A network can only hold a limited number of IP addresses.
  • Page 56 Network Video Server User’s Guide C Class Network 1. Features of Addresses IP address: The three-digit number in room ‘X4’ is for the Host ID. The number ranges from 0 to 255. Among the numbers, 0 is used for Network ID, 1 is used for Router IP (Gateway address) and 255 are used for Broadcast address.
  • Page 57 Network Video Server User’s Guide Sub-Network ID: xxx.xxx.xxx.0 Gateway Address: xxx.xxx.xxx.1 Subnet Mask: 255.255.255.192 Broadcast Address: xxx.xxx.xxx.63 IP Addresses: xxx.xxx.xxx.2 – xxx.xxx.xxx.62 Sub-Network ID: xxx.xxx.xxx.64 Gateway Address: xxx.xxx.xxx.65 Subnet Mask: 255.255.255.192 Broadcast Address: xxx.xxx.xxx.127 IP Addresses: xxx.xxx.xxx.66 – xxx.xxx.xxx.126 Sub-Network ID: xxx.xxx.xxx.128 Gateway Address: xxx.xxx.xxx.129 Subnet Mask: 255.255.255.128 Broadcast Address: xxx.xxx.xxx.225...
  • Page 58 Network Video Server User’s Guide Gateway Address: xxx.xxx.xxx.193 Subnet Mask: 255.255.255.192 Broadcast Address: xxx.xxx.xxx.255 IP Addresses: xxx.xxx.xxx.194 – xxx.xxx.xxx.254...

  • Page 59: Updating Firmware

    Also write down the Serial Number. Download New Firmware You can download the latest Firmware from the INTELLINET NETWORK SOLUTIONS Website located at www.intellinet-network.com/ipcamera. Be sure to verify that the Serial Number of the camera matches the serial number given on the...
  • Page 60 Network Video Server User’s Guide The Firmware Upgrade Process. The NETWORK VIDEO SERVER can be upgraded via the LAN or remotely over the Internet (please see note below). Follow these steps to install a new Firmware: 1. Confirm that the NETWORK VIDEO SERVER is connected to your PC.

  • Page 61: The I/O Connector

    Network Video Server User’s Guide F. The I/O Connector The I/O Connector provides the physical interface to a digital output, and a single digital photo- coupled input that is used for connecting a variety of external alarm devices to the NETWORK VIDEO SERVER;...

  • Page 62: Rs 232 Cable & Pan/Tilt/Zoom Control

    Network Video Server User’s Guide G. RS 232 CABLE & Pan/Tilt/Zoom Control The Serial Connector In absence of a local network connection, the RS232 serial connector provides a physical interface for connecting a PTZ devices or computer to NETWORK VIDEO SERVER. This means that NETWORK VIDEO SERVER can operate as a standard unit -independent of any computer network.
  • Page 63 Network Video Server User’s Guide RI : Ring Indicator Pan/Tilt/Zoom Control Pan/Tilt/Zoom control interface of NETWORK VIDEO SERVER is initially set to support RS485. To operate Pan/Tilt/Zoom control through NETWORK VIDEO SERVER, camera or receiver is to be connected to 9PIN DIN connector of rear panel as shown below; 9PIN DIN Connector Receiver or Camera If your camera supports RS232 instead RS485 for Pan/Tilt/Zoom control, then, follow the next...

  • Page 64: Dynamic Domain Name Service (Ddns)

    The Internet uses DNS servers to lookup domain names and translates them into IP addresses. Domain names, such as www.intellinet-network.com, are just easy to remember aliases for IP addresses. A dynamic DNS service is unique because it provides a means of updating your IP address so that your listing will remain current when your IP address changes.
  • Page 65 Network Video Server User’s Guide How to use ODS DDNS service 1. Get access to ODS homepage (www.ods.org). 2. In case you didn’t register your ID, you should select ‘REGISTER’ menu and then register your ID/ Password. Otherwise, you just login with registered ID/Password. 3.
  • Page 66 ④ Target: Write initial IP of equipment but just write any IP address that is in the form of “xxx.xxx.xxx.xxx” ⑤ TTL Priority: Do NOT select. This is option. If you want to select “intellinet.dyndns.org” for domain name, type ‘intellinet’ in the Host field and then select dyndns.org for domain. Otherwise, please refer to the premium service. NOTE After completing DynDNS setting, you should activate DDNS support in Network Video Server.

  • Page 67: How To Use Dyndns Ddns Server

    Network Video Server User’s Guide How to use DynDNS DDNS server 1. Get access to DynDNS Homepage (www.dyndns.org). 2. In case you didn’t register your ID, click “Sign Up Now” and then register your ID. Otherwise, you just login with registered ID.
  • Page 68 Network Video Server User’s Guide 3. Click “Add Host”, and then go to the next page.
  • Page 69 Network Video Server User’s Guide Enter Domain name you want and just leave other items, and then Click the “Add Host” button to register. If you want to know detail of each field, please refer to FAQ of each homepage. 5.
  • Page 70 3. Enter your DDNS Account Password. 4. Enter the Host Name you have registered with your DDNS Service, i.e. example.dyndns.org or yourcamera.dyndns.org or intellinet.ods.org. 5. Activate the checkbox (x) DDNS manual update and click on SUBMIT. 6. After 30 seconds click on NETWORK CONFIGURATION to refresh the screen.

  • Page 71: High Speed Solutions

    Network Video Server User’s Guide I. High Speed Solutions This information is to help you access high-speed Internet services such as xDSL or a cable modem connection. However, most high-speed Internet Services provide you with some external IP addresses, there are several practical issues that should be considered. AVAILABLE IP ADDRESS ISP (Internet Service Provider) will provide you with several external static IP addresses ideally –in which case you can assign any one of these to your NETWORK VIDEO SERVER to make it fully...
  • Page 72 Network Video Server User’s Guide ROUTERS AND FIREWALLS Another solution is to use one of several small routers/firewalls currently available on the market. These provide the necessary NAT functionality and allow complete independence for your PC, which can be switched off or rebooted without affecting the image transmission from your NETWORK VIDEO SERVER. WINGATE SERVER SOFTWARE: Running on a single Windows 9x/2000/XP computer, this software allows multiple users simultaneous access to the Internet through a LAN or higher-speed line, such as xDSL or cable modem connection;...

  • Page 73: Reinstating The Factory Default Settings

    Network Video Server User’s Guide J. Reinstating the Factory Default Settings This information explains instructions in detail on how to set the default settings in the NETWORK VIDEO SERVER. In certain circumstances it may become necessary to restart or reinstate the Factory Default settings for your NETWORK VIDEO SERVER: This is performed by pressing the Reset Button, or using Hyper Terminal Setting.

  • Page 74: Factory Default Setting

    Network Video Server User’s Guide NOTE Reinstating the original default settings will cause all parameters (Including IP address) to be reset. Factory default setting Administrator ID: admin Administrator Password: admin Guest ID: guest Guest Password: guest IP Address: 192.168.1.221 Subnet Mask Address: 255.255.255.0 Gateway Address: 192.168.1.1 Server IP Address: 192.168.1.200 Compression Rate: Level 10 (highest)

  • Page 75: Glossary Of Terms

    Network Video Server User’s Guide K. Glossary of Terms ActiveX – A control (or set of rules) used by a browser. ActiveX controls are often downloaded and installed automatically as required. ARP – Address Resolution Protocol. A method for finding a host's Ethernet address from its Internet address.
  • Page 76 Network Video Server User’s Guide FTP - A client-server protocol that allows a user on one computer to transfer files to and from another computer over a TCP/IP network. Also the client program the user executes to transfer files. It is defined in STD 9, RFC 959. HTML - A markup language used to structure text and multimedia documents and to set up hypertext links between documents, used extensively on the World Wide Web.
  • Page 77 Network Video Server User’s Guide SMTP – Simple Mail Transfer Protocol TCP/IP - Transmission Control Protocol/Internet Protocol. Wide-area-networking protocol that makes the Internet work. TCP/IP is used on many networks, including the Internet. TCP keeps track of the individual packets of information and IP contains the rules for how the packets are actually sent and received.
  • Page 78 Network Video Server User’s Guide www.intellinet-network.com Copyright 2006...
