WWW.MOBILE-SIGNAL-BOOSTERS.SHOP
CELL PHONE AMPLIFIER
Nikrans MA-600GDW
Calls/GSM / 3G / 4G/LTE
Indoor coverage: 6500 ft²
Frequency bandwidth of 900, 1800, 2100 MHz
https://www.mobile-signal-boosters.shop/
repeater-30/
Nikrans MA-600GDW
Free Support
3-YEAR warranty & service
30-DAY return policy
3-7 business day delivery
Chat with us
info@mobile-signal-boosters.shop
+448000698689
Indoor Antennas /
Outdoor Antennas
Safety for Human Health
Conformity to CE and RoHS standarts
Full kit ready to use
Full duplex mode (improvement of outcoming and incoming signal)
(Sales)
SPECIFICATION
Indoor coverage: 6500 ft²
Up-link freq: 890-915 & 1710-1785 & 1920-1980 MHz
Down-link freq: 935-960 & 1805-1880 & 2110-2170
MHz
Up-link Gain: 75 dB
Down-link Gain: 80 dB
Power supply: Input AC90~264V,output DC5V/3A
Working t °C: -25/+55
IP-Code: IP40
Humidity: 5 - 95 %
Size (mm): 270 × 210 × 50
Booster Weight: 0.86 kg
dBm: 27 dBm
PACKAGE
Cables
Power supply
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the MA-600GDW and is the answer not in the manual?

Questions and answers

Summary of Contents for Nikrans MA-600GDW

  • Page 1 WWW.MOBILE-SIGNAL-BOOSTERS.SHOP CELL PHONE AMPLIFIER Nikrans MA-600GDW SPECIFICATION Indoor coverage: 6500 ft² Up-link freq: 890-915 & 1710-1785 & 1920-1980 MHz Down-link freq: 935-960 & 1805-1880 & 2110-2170 Up-link Gain: 75 dB Down-link Gain: 80 dB Power supply: Input AC90~264V,output DC5V/3A Working t °C: -25/+55...
  • Page 2 PRODUCT DESCRIPTION MA-600GDW is a unique triband mobile signal repeater for home that improves mobile signals at three different frequencies, GSM 900 MHz & 1800 MHz and 2100MHz for 3G internet. The device is compatible for improving signal strength of all providers in Europe inclusive those of the UK.
  • Page 3 INSTALLATION SCHEME 1. Find the best position of an outdoor antenna (on the roof/ outside the window where your mobile phone displays 2-3 bars of mobile coverage). Choose the best direction of the antenna – it’s recommended to direct it towards the nearest GSM base station.
