  • Page 1 PT-PIS4PB1S PoE Switch Quick Installation Guide www.procetpoe.com...
  • Page 2 Declaration This docum ent belongs to PROCET com pany. It is not allowed to reproduce m odify without the original author's perm ission. It is PROCET's policy to   im prove its products as new technology, com ponents, software, and firm ware at any tim e.
  • Page 3 Overview The installation Guide for PT- PIS4PB1S and mainly introduces the hardware    specification, installation methods, and precautions of the installation.  There may be differences in the appearance and config uration from other  models. All product imag es in this manual are for illustration purposes only  and may differ from the actual product. This manual includes the following  chapters: 1. Product Introduction. Including  the basic functions and specification of  PT- PIS4PB1S, as well as the product appearance and applications  introduction. 2. Installation Introduction. Introducing  the preparation work and  precautionsbefore installing  the product. 3. Product Installation. Two methods of product installation. 4. Accessories information. Introducing  accessories for this product For W hom Network Engineers Network Adm inistrators Field Technicians Overview...
  • Page 4 Table of Contents 1.Introduction 1.1  Introduction..................................................................01   1.2  Appearance...................................................................01     1.3  Specification.................................................................03     2.Installation Preparation 2.1 Installation toolkit......................................................05         2.2  Inspection.......................................................................05   3.Installation 3.1  Installing in waterproof case................................... 07   3.2  Inspection......................................................................09             Table of contents...
  • Page 5 1.  Introduction 1.1 Introduction PT-PIS4PB1S is a 4-port, industrial-scale PoE switch, which includes 1 SFP fiber data uplink Interface, DC input port, and 4 PoE ports, provides power and transfer signal for rem ote PDs over 4 pairs output at 10/ 100/ 1000 M bps of data speed.
  • Page 6: Side View

    Side View 42.2± 1mm 37.6± 1mm Heat Sink 50mm 151.5± 1mm DIN M ounting  brack ets   48± 1mm 1- 2  Side V iew Front View 16.8 15mm ± 1mm 23.4± 1mm 19.5± 1mm Power Indicator  SFP Indicator PoE Output Port 66.6± 1mm SFP Port 15mm 18± 1mm 1- 3  Front V iew 02        Introduction...
  • Page 7  (Include a series of PoE switch indicators' status) LED Indicator Display Status Items Description Solid Green  PD is powered up and working . Power Indicator Lig ht Off PD is not powered on or failed to power on Solid Yellow  Data Connection PoE Data   Flashing  Yellow Data Transfer Indicator The port is not connected to the device or  Lig ht Off the connection has failed. Solid Green PoE Power Norm al PoE  Flashing...
  • Page 8 Item Description Backplane Bandwidth 14Gbps M AC Address Capacity 10K Packet Forwarding  Rate 7× 1.488M pps Power Pin 4,5(+ )/7,8(- ) 3,6(+ )/1,2(- ) 48- 55V dc  1.64A M ax(90W  M ax per port), total Output power budget 360W (m ax) Com m on m odel surg e protection: 4kv PoE Surg e Protection Differential mode surg e protection:1.5kv  W...
  • Page 9 2. Installation Preparation 2.1 Installation toolkit The fllowing  tools are needed during  equipment installation, which are  included in the product box. Ground W ire  PT- PIS4PB1S Operation M anual & M 3 screw 2.2 Inspection 2.2.1 Connect the device to a DC Power System and check the PW R LED  to ensure proper function before installation.  2.2.2 Connect the PoE port to the PoE powered device(PD). Such as the IP Cam eras or Wireless APs to check the PoE function. As showed in Figure 2-1;...
  • Page 10 DC Input GND Terminal Switch DC Power PT- PIS4PB1S ≤100m PD X4 PoE Data & SFP input Power Output 2- 1  Device Connection Caution: 1. Please read the instructions carefully and follow the standard operating procedures before using. 2. Please place it in a well-ventilated and dry area, and it is for indoor use only.
  • Page 11 3    Installation This product is safe to use for waterproof case installation . 3.1 Installation in waterproof case The device is mainly placed in a waterproof box to achieve stable water proof  operation. If it is placed in an outdoor environment, please try to install the  device in a waterproof case with a heig ht of 45cm. (1)Install the waterproof case first, and keep the case open. As showed in3- 1; M etal Plate Cable 3- 1   Waterproof case Installation      07...
  • Page 12 (2) Remove the metal backplate from the waterproof case and fix the DIN  rail bracket on the backplate, then install this product on DIN rail bracket.  (as showed in 3- 2) M etal Plate DIN Rail Rail  M ounting   DIN Rail Screws 3- 2  Installation (3)Reinstall the backplate with the installed product into the waterproof  case. Caution: To ensure that outdoor PD(IP cam era, Wireless AP) has better surge lightning protection, please buy PROCET Ethernet surge protectors. 08        Installation...
  • Page 13 3.2  Grounding PROCET PoE switchPT- PIS4PB1S has the following  g rounding  solutions  for reference during  construction: If the installation is in the computer room, it can be connected to the  dedicated g rounding  busbar in the room.The g rounding  busbar is a connecting  conductor between the g rounding  bodies of the building , such  as flat iron, flat steel, nanomaterial conductors, copper- clad steel, etc. (as showed in 3- 6.) GND Terminal M 3 Screw Grounding  Busbar 3- 6  Grounding    For the safety of personnel and equipment in an environment without  dedicated g rounding  equipment, a simple g rounding  device can  be constructed as follows(As showed in 3-...
  • Page 14 GND Terminal  M 3 Screw Ground Soil 2200  M M 3- 7  Simple Grounding Caution: Use a galvanized m etal pipe buried underground at a depth of one m eter or m ore, such as a water or sew age pipe , as an em ergency grounding if no other grounding environm ent is available.
