- Page 1 ＥＮ－Ｓ４Ｐ１Ｃ ＰｏＥ Ｓｗｉｔｃｈ Ｑｕｉｃｋ Ｉｎｓｔａｌｌａｔｉｏｎ Ｇｕｉｄｅ ｗｗｗ．ｐｒｏｃｅｔｐｏｅ．ｃｏｍ...
- Page 2 Ｄｅｃｌａｒａｔｉｏｎ This document belongs to PROCET company. It is not allowed to reproduce and modify without the original author's permission. It is PROCET's policy to improve its products as new technology, components, software, and firmware at any time. PROCET, therefore, reserves the right to change specifications without prior notice.
- Page 3 Ｏｖｅｒｖｉｅｗ The installation Guide for EN-S4P1C and mainly introduces the hardware specification, installation methods, and precautions of the installation. There may be differences in the appearance and configuration from other models. All product images in this manual are for illustration purposes only and may differ from the actual product.
- Page 4 Ｔａｂｌｅ ｏｆ Ｃｏｎｔｅｎｔｓ １． Ｉｎｔｒｏｄｕｃｔｉｏｎ １．１ Ｉｎｔｒｏｄｕｃｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０１ １．２ Appearance．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０１ １．３ Specification．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０３ ２． Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ ２．１ Ｐａｃｋａｇｅ ｃｏｎｔｅｎｔｓ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０４ ２．２ Ｉｎｓｐｅｃｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０４ ３． Ｉｎｓｔａｌｌａｔｉｏｎ ３．１ Ｉｎｓｐｅｃｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０６ Ｔａｂｌｅ ｏｆ ｃｏｎｔｅｎｔｓ...
- Page 5 １． Ｉｎｔｒｏｄｕｃｔｉｏｎ １．１ Ｉｎｔｒｏｄｕｔｉｏｎ ＥＮ－Ｓ４Ｐ1C ｉｓ ａ ４－ｐｏｒｔ Ｇｉｇａｂｉｔ ＰｏＥ ｓｗｉｔｃｈ ｗｉｔｈ ａｎ ｕｐｌｉｎｋ ＲＪ４５ ＬＡＮ ｄａｔａ ｐｏｒｔ． Ｄｅｓｉｇｎｅｄ ｗｉｔｈ ＯＶＰ， ＯＣＰ， ＳＣＰ ｆｕｎｃｔｉｏｎ， ｃａｎ ｄｅｌｉｖｅｒ ｐｏｗｅｒ ａｎｄ ｔｒａｎｓｍｉｔ ｄａｔａ ｔｏ ４ ８０２．３ａｆ／ａｔ ＰＤｓ ｓｉｍｕｌｔａｎｅｏｕｓｌｙ， ｔｏｔａｌ ｐｏｗｅｒ ｂｕｄｇｅｔ ｉｓ ６０Ｗ． Ｃｏｍｅ ｗｉｔｈ ａｎ ＡＣ ｔｏ ＤＣ ｐｏｗｅｒ ｓｕｐｐｌｙ ａｔ Ｌｅｖｅｌ ６ ｅｎｅｒｇｙ ｅｆｆｉｃｉｅｎｃｙ． Ｇｏｏｄ ｈｅａｔ ｄｉｓｓｉｐａｔｉｏｎ ｗｉｔｈ ｖｅｎｔｉｌａｔｉｏｎ ｈｏｌｅｓ ｔｏ ｅｎｓｕｒｅ ｌｏｎｇ ｔｅｒｍ ｓｔａｂｌｅ ｏｐｅｒａｔｉｏｎ． ＥＮ －Ｓ４Ｐ１Ｃ ｉｓ ｅｑｕｉｐｐｅｄ ａ ＵＳＢ－Ｃ ｐｏｒｔ， ｗｈｉｃｈ ｃａｎ ｄｅｌｉｖｅｒ ｐｏｗｅｒ ｔｏ ｍｏｂｉｌｅ ｐｈｏｎｅ， ｔａｂｌｅｔ， ａｎｄ ｍｏｓｔ ＵＳＢ－Ｃ ｄｅｖｉｃｅｓ． １．２ Ａｐｐｅａｒａｃｅ Ｕｐｐｅｒ Ｖｉｅｗ Ｃｏｏｌｉｎｇ ｈｏｌｅ １－１ Ｕｐｐｅｒ Ｖｉｅｗ Ｉｎｔｒｏｄｕｃｔｉｏｎ ０１...
- Page 6 Ｓｉｄｅ Ｖｉｅｗ Ｄａｔａ Ｉｎｄｉｃａｔｏｒ Unused ＬＡＮ Ｉｎｐｕｔ Ｐｏｒｔ ＤＣ Ｐｏｗｅｒ Ｐｏｒｔ １－２ Ｓｉｄｅ Ｖｉｅｗ Ｆｒｏｎｔ Ｖｉｅｗ ＰｏＥ Ｌｏａｄ Ｉｎｄｉｃａｔｏｒ Ｔｙｐｅ－Ｃ ＰｏＥ Ｏｕｔ Ｄａｔａ Ｉｎｄｉｃａｔｏｒ Ｏｕｐｕｔ Ｐｏｒｔ ｐｕｔ Ｐｏｒｔ １－３ Ｆｒｏｎｔ Ｖｉｅｗ ０２ Ｉｎｔｒｏｄｕｃｔｉｏｎ...
- Page 7 Ｉｎｄｉｃａｔｏｒ Ｄｉｓｐｌａｙ： Ｉｔｅｍｓ Ｓｔａｔｕｓ Ｄｅｓｃｒｉｐｔｉｏｎ Ｓｏｌｉｄ Light PD is powered(Default/Normal) ＰｏＥ Ｌｏａｄ Ｉｎｄｉｃａｔｏｒ No connection to PD Light Off Green Ｄａｔａ ａｖａｉｌａｂｌｅ（Ｎｏｒｍａｌ） Ｄａｔａ Ｆｌａｓｈｉｎｇ Light Ｉｎｄｉｃａｔｏｒ Light Off No Data transmission Yellow Light Ｏff PoE Switch is powered off/defective.
- Page 8 ２． Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ 2.1 Package Contents Ｏｐｅｎ ｔｈｅ ｂｏｘ ｏｆ ｔｈｅ ＥＮ－Ｓ４Ｐ1C ａｎｄ ｃａｒｅｆｕｌｌｙ ｕｎｐａｃｋ ｉｔ， ｔｈｅ ｂｏｘ ｓｈｏｕｌｄ ｃｏｎｔａｉｎ ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｉｔｅｍｓ： ＥＮ－Ｓ４Ｐ１Ｃ Ｏｐｅｒａｔｉｏｎ ｍａｎｕａｌ AC to DC Power Supply Adapter ２．２ Ｉｎｓｐｅｃｔｉｏｎ 2.2.1 Connect the device to the AC to DC power supply, the power cable is 1.5 meters with DC barrel jack at 5.5*2.1mm. 2.2.2 Connect the PoE port to the PoE powered device(PD). Such as the IP Cameras or Wireless APs.
- Page 9 ２． Ｐｌｅａｓｅ ｐｌａｃｅ ｉｔ ｉｎ ａ ｗｅｌｌ－ｖｅｎｔｉｌａｔｅｄ ａｎｄ ｄｒｙ ａｒｅａ， ａｎｄ ｉｔ ｉｓ ｆｏｒ ｉｎｄｏｏｒ ｕｓｅ ｏｎｌｙ． 3. Connect the AC to DC power supply adapter cable with DC barrel jack into the rear of the Procet PoE switch. On the other end of the power cable plug into a standard grounded wall outlet for safety.
- Page 10 ３． Ｉｎｓｔａｌｌａｔｉｏｎ ３．１ Ｉｎｓｐｅｃｔｉｏｎ Inspect the installed equipment before putting it into operation： · Make sure the PD is compliant with our product. · Make sure the Ethernet cable connection is correct. Make sure all connections are correct, and turn on the power, inspect all the indicators.
- Page 11 Qualification Card PASS Creative Lianjie Network Technology Co.Ltd www.procetpoe.com...
