Summary of Contents for TCL Three MW63V3
- Page 1 Three 4G MiFi Quick Start Guide CJB74V0HWAAC...
- Page 2 Overview Buttons Power • Press and hold for 3 seconds to power on or off your button device. • Press and hold for 10 seconds to reboot your device. Micro Connect to a power supply (5V/1A) using the provided USB port USB cable.
-
Page 3: Status Led
Status LED Signal • Solid blue: your device is connected to the Indicator internet and signal is strong. • Solid red: your device has no network service, no SIM inserted or signal is weak. • Flashing blue: your device is disconnected from the internet. - Page 4 SIM slot Insert a nano SIM into the slot. Reset button Depress the button for 3 seconds using a paperclip to reset the device.
- Page 5 Insert the SIM and Battery Notes: • Before inserting your SIM and battery, make a note of the default SSID and Wi-Fi password on the label inside your Three 4G MiFi. • Check the orientation of your SIM. Make sure you align the SIM with the slot and slide it into the slot until it sits properly.
- Page 6 Power On Press and hold the power button for 3 seconds to turn on your Three 4G MiFi.
- Page 7 Connect a device to your Three 4G MiFi 1. Make sure you've made a note of the Wi-Fi name (SSID) and password on the label underneath the battery. 2. Open the connection settings of the device to be connected, such as a PC, tablet, or smartphone, search for the Wi-Fi name (SSID) and click on it to connect to the Wi-Fi network.
-
Page 8: Configure The Network
Configure the Network To configure the network: 1. Open a web browser on the device connected to the Three 4G MiFi network. 2. Navigate to https://192.168.1.1 and log into the User Interface to configure the desired settings. Note: To get the default login password, remove the back cover of your Three 4G MiFi and check the label located underneath the battery. -
Page 9: Important Safety Information
Important Safety Information Read all the safety information before using your device. Failure to follow these safety instructions could result in injury, or damage to your device or other property. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein. -
Page 10: Power Adapter
Power adapter Charge your device with the supplied USB cable. Only charge with an adapter that is compliant with the applicable international and regional safety standards. Using other adapters could cause damage to the device or pose a risk of injury or death. -
Page 11: Operating Environment
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. In accordance with air regulations, the battery of your product is not fully charged. Please charge it first. • Do not attempt to open the battery (due to the risk of toxic fumes and burns). •... -
Page 12: Specific Absorption Rate (Sar)
Specific Absorption Rate (SAR) This device meets international guidelines for exposure to radio waves. The radio wave exposure guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg for body, and 4 W/kg for limb. - Page 13 UMTS Band 3 (1800MHz) 23 dBm UMTS Band 8 (900MHz) 24.5 dBm LTE FDD B1/20/28/40 24.5 dBm (2100/800/700/2300 MHz) LTE FDD B3 (1800 MHz) 23.9 dBm LTE FDD B7/8 (2600/900 MHz) 24.0 dBm LTE TDD B38 (2600 MHz) 23.5 dBm 802.11 b/g/n 2.4GHz 18.97 dBm 802.11 a/n/ac 5150 –...
- Page 14 not attached to a fixed installation or to the external body of road vehicles, a fixed infrastructure or a fixed outdoor antenna. The 5250-5350 MHz of Wi-Fi 5 GHz can be used inside buildings only. The 5470-5725 MHz band of Wi-Fi 5 GHz can’t be used in road vehicles, trains, aircraft or UAS (Unmanned Aircraft System) scenarios for the following countries: (NI)
- Page 15 Radio Equipment Directive Declaration of Conformity Hereby, TCL Communication Ltd. declares that the radio equipment type MW63V3 is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The full text of the EU declaration of conformity is available at: https://www.tcl.com/global/en/EC_DOC...
-
Page 16: General Information
In non-European Union jurisdictions: Items of equipment with this symbol are not to be thrown into ordinary bins if your jurisdiction or your region has suitable recycling and collection facilities; instead they are to be taken to collection points for recycling. General information Website www.tcl.com/global... -
Page 17: Software Update
Refusing or forgetting to install an update can affect your device’s performance and, in the event of a security update, expose your device to security vulnerabilities. For more information about software update, please go to tcl.com... -
Page 18: Limited Warranty
You live (“Consumer Rights”). This Limited Warranty sets out certain situations when the Manufacturer will, or will not, provide a remedy for the TCL device. This Limited Warranty does not limit or... - Page 19 Consumer Rights relating to the TCL device. For more information about limited warranty, please go to https://www.tcl.com/global/en/warranty In case of any defect of your device which prevents you from normal use thereof, you must immediately inform your vendor and present your device with your...
