Summary of Contents for EbV elektronik CETA 106
- Page 1 CETA Heating circuit control Menu Operating...
- Page 2 Control System CETA Operating...
- Page 3 Control System CETA Operating - Entry (Menu, parameter) - safe...
- Page 4 Control System CETA Operating - Return (Menu, Parameter without safing)
- Page 5 Control System CETA Operating - Navigation Selection of menu items - Parameter adjustment...
- Page 6 Control System CETA Operating Control system Control system Control system - Navigation Selection of menu items - Parameter adjustment...
- Page 7 Control System CETA Operating Basic Display From the basic display, shortly press the "Prog" button to go to the menu selection. Menu level selection Menu 01 … 28 (Device-specific)
- Page 8 Control System CETA Operating Basic Display Menu: 01 = Info 02 = Cycle times Menu level selection 03 = System 06 = Heating circuit 08 = Delta T1 Menu 26 = Clock 01 … 28 27 = Sensor calibration (Device-specific) 28 = Relay test...
- Page 9 Control System CETA Operating Basic Display Menu level selection Parameter selection Parameter 01 Parameter 02 Menu Last parameter of the selected of the selected of the selected 01 … 28 menu menu menu (Device-specific) Adjustment of The setting Adjustment the selected range see op.
- Page 10 Control System CETA Operating The availability of the individual menu levels, the parameters as well as the settings of the individual parameters can be foand in the enclosed operating instructions. Also to be foand on www.ebv-gmbh.com...
- Page 11 Control System CETA Operating - manual mode Basic Display Each CETA control has the possibility to activate a manual mode. The manual mode is individually adapted to the control function. Manual mode...
- Page 12 Control System CETA Operating – manual mode Basic Display From the basic display, press the "Prog" key for 3 seconds to activate manual mode. Manual mode...
- Page 13 Control system CETA Operating – manual mode CETA 106 Basic Display Manual mode - The heating circuit pump is in continuous operation - The mixing valve control is de-energized.
- Page 14 Control system CETA Operating - manual mode CETA 106 Basic Display Manual mode The key is used to end manual operation.
- Page 15 Control system CETA Error codes „Error“ flashes in the display The error code is displayed alternately with the basic display. Fehler Codes 11-0 F1 Interruption 13-0 F3 Interruption 11-1 F1 Short circuit 13-1 F3 Short circuit 12-0 F2 Interruption 14-0 F4 Interruption 12-1 F2 Short circuit...
- Page 16 Control system CETA Menu 02 (Cycle times) Parameter selection Parameter adjustment Return 2 switching cycles per day are without save available Same on/off time means deactivation of the switching cycle Switching times are assigned in the HC/DHW menu (06:05/07:05) Return with save...
- Page 17 Control system CETA Menu 02 (Cycle times) Parameter selection Parameter adjustment Return without save Changing the switch-on time via + / - Changing the switch-off time Return with save via + / -...
- Page 18 Control system CETA Menu 02 (Cycle times) Parameter selection Parameter adjustment Return without save Return with save...
- Page 19 Control system CETA Menu 02 (Cycle times) Parameter selection Parameter adjustment Return without save Return with save...
- Page 20 Control system CETA Menu 02 (Cycle times) Parameter selection Continue to the next day by pressing the + key. Parameter adjustment Return without save Return with save...
- Page 21 Control system CETA Menu 02 (Cycle times) After the last input (Prog) the menu can be left with "Esc".
- Page 22 Control system CETA Menü 01 (INFO)
- Page 23 Do you have any questions? You can reach our support by e-mail to support@ebv-gmbh.de...
