Page 2
If pressurized air flow exceeds 0.5 bar, the flow sensors may be damaged due to extreme purge speed. Disclaimer Costs connected to any damages to the products caused by lack of following the Instruction Manuals, will be at the customers’ own expense. Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
VFS8 1-18 K (1-20 l/min high temperature) VFS8 2-40 K (2-40 l/min high temperature) Pressure sensors are called: RPS6 0-10 E (0-10 bar standard) RPS6 0-10 K (0-10 bar high temperature) Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
4. Open the adjustable air without exceeding 0.5 bar and ensure slow purge of water. 5. When the system has been emptied, you can fully open the air supply to blow the circuits dry. Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
Page 5
Prepare the manifold Connect the fittings for the main water (in and out) and mount the blinding fittings at the other Mount the fittings of your choice for each cooling channel Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
Page 6
Please only remove the bolts needed for the bracket you are currently mounting. Mount the manifold on the machine or the mould Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
Page 7
Mount screen bracket on the machine. The bracket can be mounted with screws, or with the pre-mounted magnets Push the screen into the bracket, until the snap fit clicks into place Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
Page 8
The Flosense 4.0 screen can have up to 4 manifold connected at the same time. Connect the female end of the M8 cable to the first manifold Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
Page 9
Use an extender cable if necessary Fasten the cable onto the connector Follow the previous four steps for the remaining manifold See Known Issue on page 13 Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
Page 10
Step 9 Configure the Manifolds Once the screen has been connected and has started up, check to see if the correct number of manifolds are being displayed on the home screen. Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
Page 11
Do this for all manifold which are not displayed correctly, and then return to the settings menu by pressing the exit button in the bottom right corner. Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
Page 12
USB to upload the configurations, please follow the next 4 steps. Set the global settings, such as language, measurement units and logging rate See Known Issue on page 13 Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
Page 13
After selecting and naming the configuration, press the tick icon in the bottom right to save You are now ready to use your new Flosense system! Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
1. The buttons on the bottom of the screen have been rearranged, so the checkmark button is now the leftmost button instead of rightmost. The figure in the manual needs to be updated. Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
Page 15
P a g e | 14 Change log Date of change Change Version 29-04-2020 Product release 16-06-2020 Stability issue fixed. Manual edited specifically for Flosense 4.0 Installation Quick Guide – Flosense 4.0 16-06-2020 Version 002...
