- Page 1 _____________________________________________________________ User Guide Flosense 3.0 & 4.0 VNC Quick Guide User Guidelines – VNC Quick Guide 09-10-2020 Version 001...
- Page 2 P a g e Introduction This Quick Guide serves as an easy-to-use guide to help make your VNC connection to the Flosense Manifold system as simple as possible. However, beware that the Quick Guide is a supplement to the full VNC guide and for that reason cannot stand alone. So please ensure that you have read the relevant User guide thoroughly before connecting your Flosense system to your Machine UI or PC with VNC.
- Page 3 P a g e Connecting locally to PC or Machine UI For connecting through a common router, go to page 8 • Connect the Flosense display to your unit with an ethernet cable. The Flosense display needs to be Turned OFF, before connecting the display to the Machine UI or PC as seen on the picture below.
- Page 4 P a g e • Open “Network and Sharing Center” • Press “Ethernet” (or Local Area Connection) as shown below. User Guidelines – VNC Quick Guide 09-10-2020 Version 001...
- Page 5 P a g e • Press “Properties” as seen below. • Select “TCP/IPv4 (Internet Protocol Version 4) and click “Properties” as seen below. User Guidelines – VNC Quick Guide 09-10-2020 Version 001...
- Page 6 P a g e • Enter the network data as seen below For the subnet mask, it is highly recommended to input 255.255.0.0 as seen above. When entering the IP-address, if you have input the recommended subnet mask, the first 6 digits of the IP address will be assigned to your PC/Unit by your network and you can select the remaining digits yourself.
- Page 7 P a g e • Open the Global settings menu on your Flosense unit • Open the Network settings menu as seen below (red circle) • Set IP ALLOCATION to STATIC and Enable VNC • Enter the same Subnet mask as previously. •...
- Page 8 P a g e IMPORTANT! The Flosense display need to have 12 digits in the IP-address field in order to successfully register the IP-address. This means that if you wish to use the IP-address 192.168.4.5, you will need to enter 192.168.004.005 in the Flosense software. •...
- Page 9 P a g e Connecting through a common router If you are connecting your Flosense display locally to a PC or the Machine UI, ignore this part and go back to page 1. In order to be able to connect the Flosense unit to your system using a router, the router needs to have DHCP, for it to be able to designate an IP-address to the Flosense display.
- Page 10 P a g e • Open the Global settings menu on your Flosense display • Open the Network settings menu as seen below (red circle) • Toggle IP ALLOCATION to DYNAMIC and Enable VNC. • Exit and enter the Network settings. The IP-Address should now appear. •...
- Page 11 P a g e | 10 Make sure that you have connected your manifolds to your Flosense display before connecting the units with VNC, as the VNC connection is lost if the Flosense display is turned off or rebooted. User Guidelines – VNC Quick Guide 09-10-2020 Version 001...
- Page 12 P a g e | 11 Change log Date of change Change Version 09-10-2020 VNC Functionality implemented on Flosense systems User Guidelines – VNC Quick Guide 09-10-2020 Version 001...
