ELECTRICAL SPECIFICATIONS

ABSOLUTE MAXIMUM RATINGS

Parameter
Supply Voltage (VCC)
Backup Battery Voltage (V_BCKP)
Input Pin Voltage
Input Power at RF_IN
Storage Temperature

OPERATING CONDITIONS

Parameter
Supply Voltage (VDD33)
Acquisition Current (exclude active antenna current)
Tracking Current (exclude active antenna current)
Backup Voltage (V_BCKP)
Backup Current (VDD33 voltage applied)
Backup Current (VDD33 voltage off)
Output Low Voltage
Output HIGH Voltage
Input LOW Voltage
Input HIGH Voltage
Input LOW Current
Input HIGH Current
RF Input Impedance (RF_IN)
Minimum Maximum
-0.5
-0.5
-0.5 VCC+0.5
-55
9
3.6
3.6
+5
+100
Min Typ
3 3.3
240
240
1.3
54
13
2.4
2
-10
-10
50
Condition
Volt
Volt
Volt
dBm
degC
Max Unit
3.6 Volt
mA
mA
3.6 Volt
uA
uA
0.4 Volt
Volt
0.8 Volt
Volt
10 uA
10 uA
Ohm
