www.nordictrack.com
Model No. NTEL7706.2
Serial No.
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
1-888-825-2588
CALL TOLL-FREE:
Mon.–Fri., 6 a.m.–6 p.m. MT
Sat. 8 a.m.–5 p.m. MT
ON THE WEB:
www.nordictrackservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
All manuals and user guides at all-guides.com
Serial
Number
Decal
USERʼS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUDIOSTRIDER 800 and is the answer not in the manual?

Questions and answers

Related Manuals for Reebok AUDIOSTRIDER 800

Summary of Contents for Reebok AUDIOSTRIDER 800

  • Page 1 All manuals and user guides at all-guides.com www.nordictrack.com USERʼS MANUAL Model No. NTEL7706.2 Serial No. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care. IMPORTANT: Please register this product (see the limited warranty on the back cover of this manual) before contacting Customer Care.

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    All manuals and user guides at all-guides.com IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical exerciser before using your elliptical exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    Thank you for selecting the revolutionary NordicTrack tions after reading this manual, please see the front ® AUDIOSTRIDER 800 elliptical exerciser. The cover of this manual. To help us assist you, note the NordicTrack AUDIOSTRIDER 800 elliptical exerciser product model number and serial number before con- provides an impressive selection of features designed tacting us.

  • Page 5: Assembly

    All manuals and user guides at all-guides.com ASSEMBLY Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included tool(s), assembly requires a Phillips screwdriver and a rubber mallet As you assemble the elliptical exerciser, use the drawings below to identify small parts.
  • Page 6 All manuals and user guides at all-guides.com 2. While another person lifts the Folding Frame (2), attach the Rear Stabilizer (3) to the Folding Frame with two M10 x 93mm Button Screws (82) and two M10 Curved Washers (99). Next, tighten the Center Foot (95) into the Frame (1).
  • Page 7 All manuals and user guides at all-guides.com 4. Identify the Left Pedal (34) and the Left Pedal Arm (32), which are marked with stickers. Attach the Left Pedal (34) to the Left Pedal Arm (32) with two M6 x 62mm Screws (108), two M6 x 35mm Screws (109), and four M6 Split Washers (102).
  • Page 8 All manuals and user guides at all-guides.com 6. While another person holds the Upright (10) near the Frame (1), connect the Upper Wire Harness (65) to the Lower Wire Harness (64). Carefully insert the Upright (10) into the Frame (1); be careful not to damage the Wire Harnesses (64, 65).
  • Page 9 All manuals and user guides at all-guides.com 8. Hold the Left Rear Upper Body Cover (26) and the Left Front Upper Body Cover (27) around the left Upper Body Leg (24). Attach the Upper Body Covers with five M4 x 16mm Screws (97). Attach the Right Rear Upper Body Cover (28) and the Right Front Upper Body Cover (29) in the same way.
  • Page 10 All manuals and user guides at all-guides.com 10. Attach the Left Link Arm (30) to the Left Pedal Arm (32) with an M8 x 15mm Button Screw (106), an M8.5 x 16mm x 1.5mm Washer (103), and an Axle Cover (66). Attach the Left Link Arm (30) to the left Upper Body Leg (24) with an M8 x 25mm Button Screw (110), two M8.5 x 16mm x 1.5mm...

  • Page 11: How To Use The Elliptical Exerciser

    All manuals and user guides at all-guides.com HOW TO USE THE ELLIPTICAL EXERCISER HOW TO FOLD AND UNFOLD THE ELLIPTICAL HOW TO MOVE THE ELLIPTICAL EXERCISER EXERCISER To move the elliptical exerciser, first fold it as When the elliptical exerciser is not in use, the frame described at the left.
  • Page 12 All manuals and user guides at all-guides.com HOW TO EXERCISE ON THE ELLIPTICAL EXERCISER To mount the elliptical exerciser, hold the upper body Upper Body Arms arms and step onto the pedal that is in the lower posi- tion. Next, step onto the other pedal. Push the pedals until they begin to move with a continuous motion.
  • Page 13 All manuals and user guides at all-guides.com CONSOLE DIAGRAM FEATURES OF THE CONSOLE The console features the iFit interactive workout sys- tem, which enables the console to accept iFit cards The advanced console offers an array of features containing workouts designed to help you achieve designed to make your workouts more effective and specific fitness goals.
  • Page 14 All manuals and user guides at all-guides.com HOW TO USE THE MANUAL MODE The lower right corner of the display will show the distance (total number of revolutions) that you 1. Press any button on the console or begin ped- have pedaled.
  • Page 15 All manuals and user guides at all-guides.com 6. Turn on the fan if desired. 3. Begin pedaling to start the program. To turn on the fan at high speed, press the Fan Each program is divided into either 20 or 30 one- button.
  • Page 16 All manuals and user guides at all-guides.com 4. Hold the handgrip pulse sensor. To view the approximate number of calories that you are burning per hour and the approximate number of calories that you have burned during It is not necessary to hold the handgrip pulse sen- your workout, press the Display button again.
  • Page 17 All manuals and user guides at all-guides.com 2. Insert an iFit card and select a program. If the resistance setting for the current segment is too high or too low, you can manually override the setting by pressing the OneTouch Resistance but- To use an iFit program, insert an iFit card into the tons.

  • Page 18: Maintenance And Troubleshooting

    All manuals and user guides at all-guides.com MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical exerciser Adjust the position of the Side Shields (14, 15) until regularly. Replace any worn parts immediately. the Discs (12) no longer rub against them, and then tighten the Bolt Sets (88) and the M4 x 16mm Screws To clean the elliptical exerciser, use a damp cloth and (97).

  • Page 19: Exercise Guidelines

    All manuals and user guides at all-guides.com EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 20: Part List

    PART LIST—Model No. NTEL7706.2 All manuals and user guides at all-guides.com R0312A Key No. Qty. Description Key No. Qty. Description Frame Clamp Folding Frame Large Axle Cover Rear Stabilizer Crank Bushing Front Stabilizer Crank Bushing Sleeve Ramp Crank Arm Front Ramp Cover Crank Arm Spacer Rear Ramp Cover Large Pulley...
  • Page 21 All manuals and user guides at all-guides.com Key No. Qty. Description Key No. Qty. Description M8 Split Washer M8 x 25mm Button Screw M6 Split Washer M10 x 20mm Button Screw M8.5 x 16mm x 1.5mm Washer M8 x 25mm Shoulder Screw M8 x 20mm x 2mm Washer M8 x 30mm Button Screw M8 x 16mm Button Screw...

  • Page 22: Exploded Drawing

    EXPLODED DRAWING A—Model No. NTEL7706.2 All manuals and user guides at all-guides.com R0312A...
  • Page 23 EXPLODED DRAWING B—Model No. NTEL7706.2 All manuals and user guides at all-guides.com R0312A 59 58...

  • Page 24: Ordering Replacement Parts

    All manuals and user guides at all-guides.com ORDERING REPLACEMENT PARTS To order replacement parts, see the front cover of this manual. To help us assist you, please be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
