Related Manuals for Philips EVNIA 32M2N6800M
Summary of Contents for Philips EVNIA 32M2N6800M
- Page 1 32M2N6800M User manual Customer care and warranty Troubleshooting and FAQs Register your product and get support at www.philips.com/welcome...
-
Page 2: Table Of Contents
(CVS) .....23 9. Technical Specifications ...24 9.1 Resolution & Preset Modes ..27 10. Power Management ....28 11. Customer care and warranty ..29 11.1 Philips’ Panel Monitors Pixel Defect Policy ........ 29 11.2 Customer Care & Warranty ... 32... -
Page 3: Important
Keep the display away from oil. Oil may damage the plastic cover of the display and void the warranty. This electronic user’s guide is intended for anyone who uses the Philips • Remove any object that could fall monitor. Take time to read this user into ventilation holes or prevent manual before you use your monitor. - Page 4 damage will not be covered under • Oil-based cleaning solutions may warranty. damage the plastic parts and void the warranty. • Do not knock or drop the monitor during operation and/or • Unplug the monitor if you are not transportation. going to use it for an extensive period.
-
Page 5: Notational Descriptions
1.2 Notational Descriptions technology. In most cases, the “burn-in”, “after-imaging” or “ghost The following subsections describe the imaging” will disappear gradually notational conventions used in this over some time after the power has document. been switched off. Notes, Cautions, and Warnings Warning It is highly recommended that you Throughout this guide, blocks of text... -
Page 6: Disposal Of Product And Packing Material
From the planning, design, and production stages, Philips emphasizes the importance of making products that can easily be recycled. At Philips, end-of-life management primarily This marking on the product or its entails participation in national take-... -
Page 7: Setting Up The Monitor
Now you can pull Quick Start out the styrofoam. When you pull out the styrofoam, do not squeeze 32M2N6800M the panel . Register your product and get support at www.philips.com/welcome Power *HDMI *USB A-B *Different according to region Install the base 1. - Page 8 Connecting to your PC AC power input HDMI 1 input HDMI 2 input DisplayPort input USB upstream USB downstream/USB fast charger Fast Charger USB downstream HDMI 1 HDMI 2 USB UP AUDIO Audio Out Kensington anti-theft lock Connect to PC USB hub 1.
-
Page 9: Operating The Monitor
2.2 Operating the monitor USB hub To comply with International energy Description of the control buttons standards, the USB hub/ports of this display are disabled during Standby and Off modes. Connected USB devices will not work in this state. To permanently put the USB function in the “ON”... - Page 10 Description of the On-Screen Display What is On-Screen Display (OSD)? On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance or select functions of the monitors directly through an on- screen instruction window.
- Page 11 Main menu Sub menu Standard, Illustrator, FPS, Racing, RTS, SmartImage Brightness 0~100 Movie, LowBlue Mode, EasyRead, Contrast 0~100 Economy, SmartUniformity, Game1, Game2 SmartContrast On, O Gamma 1.8, 2.0, 2.2, 2.4, 2.6 Sharpness 0~100 Native, sRGB, DCI-P3, Adobe RGB Color Space Color Temperature Native, Preset, 5000K, 6500K, 7500K, 8200K, 9300K, 11500K R.G.B.
- Page 12 In through the Philips website. What addition, this feature helps you fine- does Evnia Precision Center do? It is an tune your sight so that enemies get additional software that helps control exposed more quickly when gaming.
-
Page 13: Height Adjustment
Physical Function • Do not press the screen while adjusting the angle of the monitor. Tilt Grasp only the bezel. 20° -5° Swivel +30° -30° Height adjustment 130mm Warning • To avoid potential screen damage, such as panel peeling, ensure that the monitor does not tilt downward by more than -5 degrees. -
Page 14: Remove The Base Assembly For
2.3 Remove the Base Assembly for VESA Mounting 100mm Before you start disassembling the 100mm Display base, please follow the instructions below to avoid any possible damage or injury. 1. Place the monitor face down on a smooth surface. Pay attention not to scratch or damage the screen. -
Page 15: Multiview
7. Toggle to the right to confirm your selection. Why do I need it? MultiView in OSD menu With the ultra-high-resolution Philips • PIP / PBP Mode: There are two MultiView display, you can comfortably modes for MultiView: [PIP] and experience a world of connectivity in the [PBP]. - Page 16 Top-Left Top-Right When the sub source is not detected. (main) (main) (main) Note Bottom-Left Bottom-Right The black strip located on the top and the bottom of the screen is for measuring the correct aspect ratio when in the PBP mode. If you expect to see full- (main) (main) screen, adjust your device's resolutions...
-
Page 17: Image Optimization
LowBlue Mode, EasyRead, Economy, brightness, contrast, color, and sharpness SmartUniformity , Game 1 and Game 2 in real-time. Whether you're working with text applications, displaying images, or watching a video, Philips SmartImage SmartImage GAME delivers great monitor performance. Standard Why do I need it? - Page 18 LED displays can cause HDR Game eye damage and affect vision over time. Developed for well-being, the HDR Movie Philips LowBlue Mode setting uses HDR Vivid smart software technology to reduce DisplayHDR 1000 harmful shortwave blue light. Personal • EasyRead: Helps improve reading...
-
Page 19: Smartcontrast
• Off: No optimization by SmartImage 3.3 Customize color space HDR. You can manually select the appropriate Note color space mode to properly display the To switch off the HDR function, please content you are viewing. disable the Input device and its content. Select appropriate color space mode Inconsistent HDR settings between the to fit the content you’re viewing:... -
Page 20: Adaptive Sync
4. Adaptive Sync AMD Radeon R7 260 • ■ Processor A-Series Desktop and Mobility APUs AMD A10-7890K • Adaptive Sync AMD A10-7870K • AMD A10-7850K • PC gaming has long been an imperfect experience because GPUs and monitors AMD A10-7800 •... -
Page 21: Ambiglow
3-step brightness settings allow you to adjust the ambiance to your liking and available wall surface. Whether you are playing games or watching movies, Philips Ambiglow offers you a unique and immersive viewing experience. How does it work? It is recommended that you dim the lighting conditions in your room for maximum effect. -
Page 22: Windows Dynamic Lighting
Dynamic Lighting feature When you find Dynamic Lighting creates a complete and consistent settings, Make the selection based on RGB lighting ecosystem with Philips your personal preference. Evnia Ambiglow across all devices that ultimately caters to a customizable user •... - Page 23 Note • The function is only available for Windows-approved devices/apps. • The connected computer must equipped with a Windows 11 operation system or later.
-
Page 24: Hdr
7. HDR HDR Settings in Windows11/10 system. Steps 1. Right-click on the desktop, and enter Display settings. 2. Select the display/monitor. 3. Select an HDR-capable display under Rearrange your displays. 4. Select Windows HD Color settings. 5. Adjust Brightness for SDR content. Note Windows 10 edition is required. -
Page 25: Designs To Prevent Computer Vision Syndrome (Cvs)
4. Choose a Philips monitor for viewing that is easy on the eyes. Follow the below instructions and use a Philips monitor to efficiently • Anti-glare screen: This feature... -
Page 26: Technical Specifications
9. Technical Specifications Picture/Display Monitor Panel Type Backlight Mini LED backlight Panel Size 31.5" (80 cm) Aspect Ratio 16:9 Pixel Pitch 0.1818 (H) mm x 0.1818 (V) mm Contrast Ratio (typ.) 1000:1 Recommended 3840 X 2160 @ 60 Hz Resolution Maximum Resolution 3840 X 2160 @ 144 Hz Viewing Angle... - Page 27 English, German, Spanish, Greek, French, Italian, Hungarian, Dutch, Portuguese, Brazil Portuguese, Polish, Russian, OSD Languages Swedish, Finnish, Turkish, Czech, Ukranian, Simplified Chinese, Traditional Chinese, Japanese, Korean Other Convenience VESA mount (100 x 100 mm), Kensington Lock Plug & Play DDC/CI, sRGB, Windows 11/10, Mac OS X Compatibility Stand Tilt...
- Page 28 3. In order to update the monitor’s firmware to the latest version, Please download the Evnia Precision Center software from Philips website. It is necessary to be connected to a network when updating the firmware on Evnia Precision Center over-the-air (OTA).
-
Page 29: Resolution & Preset Modes
Please note that your display works best at the native resolution of 3840 X 2160. For best output performance, please always ensure that your graphic card is capable of achieving the maximum resolution and refresh rate of this Philips display. Display Input Format... -
Page 30: Power Management
10. Power Management If you have a VESA DPM compliance display card or software installed on your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse, or other input device is detected, the monitor will 'wake up' automatically. -
Page 31: Customer Care And Warranty
Other Pixel Defect Policy combinations of lit and dark sub-pixels appear as single pixels of other colors. Philips strives to deliver the highest quality products. We use some of the Types of Pixel Defects industry's most advanced manufacturing... - Page 32 To qualify for repair or replacement due to pixel defects during the warranty Black Dot Defects period, a TFT Monitor panel in a Philips Black dot defects appear as pixels or flat panel monitor must have pixel sub-pixels that are always dark or 'off'.
- Page 33 BRIGHT DOT DEFECTS ACCEPTABLE LEVEL 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Distance between two bright dot defects* >15mm Total bright dot defects of all types BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 5 or fewer 2 adjacent dark subpixels 2 or fewer...
-
Page 34: Customer Care & Warranty
Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below. -
Page 35: Troubleshooting
If the problem The Auto Function is not applicable in persists after you have tried these DVI-Digital mode as it is not necessary. solutions, contact a Philips customer service representative. Visible signs of smoke or sparks •... - Page 36 Service contact information listed in • Eliminate the vertical bars using the Important information manual the Phase/Clock of Setup in OSD and contact a Philips customer service Main Controls. It is valid only in VGA representative. mode. * Functionality is different according to display.
-
Page 37: General Faqs
Shut down your computer, and is protected from sharp or disconnect your old monitor, and blunt objects. When handling the reconnect your Philips LCD monitor. monitor, make sure that there is • Turn on your monitor and then turn no pressure or force applied to on your PC. - Page 38 Philips website support page. Can I connect my LCD monitor to any PC, workstation, or Mac? Ans.: Yes. All Philips LCD monitors are fully compatible with standard PCs, Macs, and workstations. You may need a cable adapter to connect the monitor to your Mac system.
-
Page 39: Multiview Faqs
12.3 Multiview FAQs Can I enlarge the PIP sub- window? Ans.: Yes, there are 3 sizes to select: [Small], [Middle], [Large]. You can press to enter the OSD menu. Select your preferred [PIP Size] option from the [PIP / PBP] main menu. - Page 40 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
