Single Phase
Electric Vehicle Charger
Protection Units
SP-EVCP-T(C), SP-EVCP-R(C), SP-EVCP-M(C), SP-EVCP-B(C), SP-EVCP-RB(C)
Installation Manual
May 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-EVCP-RB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Matt:e SP-EVCP-RB

  • Page 1 Single Phase Electric Vehicle Charger Protection Units SP-EVCP-T(C), SP-EVCP-R(C), SP-EVCP-M(C), SP-EVCP-B(C), SP-EVCP-RB(C) Installation Manual May 2021...
  • Page 2: Table Of Contents

    Single-phase EV charger protection unit Contents Product Description Warning Notice Safety Advice Introduction Dimensions & Mounting the unit Electrical Connections Operating Instructions Status Indicator Specifications Warranty Declaration of Conformity PRODUCT ADVISORY NOTICE This product must be installed by a competent person in accordance with the IET Wiring Regulations, BS7671 (18 Edition or later) and current Building Regulations.
  • Page 3: Product Description

    PME supplies are feeding Electric Vehicle Chargers. They should NOT be used on premises with 3 phase supplies. This manual covers the SP-EVCP-T(C), SP-EVCP-R(C), SP-EVCP-M(C), SP-EVCP-B(C), SP-EVCP-RB(C) models manufactured after February 2021. The units are not intended for any purpose other than that defined within this document.
  • Page 4: Introduction

    The B version has a 2 pole Type B RCCB, single pole MCB and a single terminal on the incoming side of the unit. The SP-EVCP-R(C), SP-EVCP-RB(C), IP-EVCP-R(C) versions are rated to be connected directly to the supply meter tails via suitable connectors. All other versions must be connected via the Consumer Distribution Board or ‘Garage Board’...
  • Page 5: Dimensions & Mounting The Unit

    Single-phase EV charger protection unit Dimensions P a g e...
  • Page 6 Single-phase EV charger protection unit P a g e...
  • Page 7 Single-phase EV charger protection unit P a g e...
  • Page 8 Single-phase EV charger protection unit P a g e...
  • Page 9: Electrical Connections

    Single-phase EV charger protection unit Electrical Connections The user wiring connections are indicated in the diagrams below. Connect the supply cable from the distribution board directly to the ‘Incoming Supply’ terminals. Connect the outgoing cable to the contactor L, E & N terminals. If required, connect the CT to the 3 pin connector on the PCB.
  • Page 10 Single-phase EV charger protection unit Connect the supply cable from the distribution board directly to the MCB ‘Incoming Supply’ terminals. Connect the outgoing cable to the contactor L, E & N terminals. If required, connect the CT to the 3 pin connector on the PCB.
  • Page 11 Single-phase EV charger protection unit With Techna RCBO Connect the supply cable from the distribution board (or meter tails) directly to the RCBO ‘Incoming Supply’ terminals. Connect the outgoing cable to the contactor L, E & N terminals. If required, connect the CT to the 3 pin connector on the PCB.
  • Page 12 Single-phase EV charger protection unit SP-EVCP-R (Cxx) with IMO RCBO Connect the supply cable from the distribution board (or meter tails) directly to the RCBO ‘Incoming Supply’ terminals. Connect the outgoing cable to the contactor L, E & N terminals. If required, connect the CT to the 3 pin connector on the PCB.
  • Page 13 Single-phase EV charger protection unit Connect the supply cable from the distribution board (or meter tails) directly to the MCB/RCCD ‘Incoming Supply’ terminals. Connect the outgoing cable to the contactor L, E & N terminals. If required, connect the CT to the 3 pin connector on the PCB Check ALL power and earth connections before switching on.
  • Page 14 Single-phase EV charger protection unit Connect the supply cable from the distribution board (or meter tails) directly to the RCBO ‘Incoming Supply’ terminals. Connect the outgoing cable to the contactor L, E & N terminals. If required, connect the CT to the 3 pin connector on the PCB Check ALL power and earth connections before switching on.
  • Page 15 Single-phase EV charger protection unit 15 | P a g e...
  • Page 16: Operating Instructions

    Single-phase EV charger protection unit Operating Instructions With the supply switched on the electronic control circuit in unit will continuously monitor the incoming supply voltage. If the incoming supply is within limits, approximately 5 seconds after switching on the contactor will energise and connect the load to the incoming supply and the CPC.
  • Page 17: Status Indicator

    Single-phase EV charger protection unit LED Status Indicator A dual colour (Red / Green) LED gives a visual indication of the real time status of the unit. 17 | P a g e...
  • Page 18: Specifications

    The SP-EVCP units are guaranteed for a period of 3 years from the date of manufacture. This warranty is limited to the replacement of faulty components only. t: 01543 227290 e: info@matt-e.co.uk w: www.matt-e.co.uk matt:e Ltd, Unit 5, Common Barn Farm, Tamworth Road, Lichfield WS14 9PX 18 | P a g e...
  • Page 19: Declaration Of Conformity

    Single-phase EV charger protection unit 19 | P a g e...
