Instruction Manual
Thank you for purchasing the HAKKO FR-701 Repair System.
Please read the manual before operating the HAKKO FR-701.
Keep this manual readily accessible for reference.
Repair System
●
●
TABLE OF CONTENTS
.......................................................................... 1
..................................................................... 2
.................................................. 4
................................................ 5
.................................................... 5
............................................... 9
............................................. 13
............................................... 18
..................................... 3
.................................. 9
........................................... 10
......................................... 11
......................... 16
........................................ 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-701 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hakko Electronics FR-701

Summary of Contents for Hakko Electronics FR-701

  • Page 1: Table Of Contents

    Repair System Instruction Manual ● Thank you for purchasing the HAKKO FR-701 Repair System. Please read the manual before operating the HAKKO FR-701.  Keep this manual readily accessible for reference. ● TABLE OF CONTENTS 1. PACKING LIST ................1 ..............2 2. SPECIFICATIONS 3. WARNINGS, CAUTIONS AND NOTES ........3 4. PART NAMES (Soldering iron) ..........4 5. INITIAL SETUP (Soldering iron)  ..........5 6. OPERATION (Soldering iron) ............ 5 7. PARAMETER SETTING (Soldering iron) ........9 8. MAINTENANCE (Soldering iron) ..........9 9. PART NAMES (Desoldering Tool) ........... 10 ......... 11 10. INITIAL SETUP (Desoldering Tool) 11. OPERATION (Desoldering Tool) ..........

  • Page 2: Packing List

    1. PACKING LIST Please check to make sure that all items listed below are included in the package. HAKKO FR-701 Station HAKKO FR-4101 Desoldering Handpiece Power cord with N61-05 (ø1.0mm) nozzle HAKKO FX-8801 Soldering iron HAKKO FH-410 Handpiece holder HAKKO FH-800 Iron holder...

  • Page 3: Specifications

    2. SPECIFICATIONS ● HAKKO FX-8801 Power consumption 260W ● Station 65W (26V) Power consumption Dimensions (W × H × D) 190(W) × 140(H) × 220(D) mm Tip to ground resistance < 2 Ω (7.5 × 5.5 × 8.7 in.) Tip to ground potential <...

  • Page 4: Warnings, Cautions And Notes

    ● Use only genuine HAKKO replacement parts. ● Do not allow the HAKKO FR-701 to become wet, or use it when hands are wet. ● Be sure to hold the plug when inserting or removing the handpiece and power cords.

  • Page 5: Part Names (Soldering Iron)

    Power Switch (Main) DESOLDER POWER Clogging SOLDER Indicator Control Buttons (Soldering iron) ENTER DOWN ENTER Receptacle FR-701 (Soldering iron) Power Switch (Soldering iron) Power cord receptacle Fuse ※Use this product with the following models. (Soldering iron) ・HAKKO FX-8801 ・HAKKO FX-8803 ・HAKKO FX-8805 ｛Soldering iron (M)｝...

  • Page 6: Initial Setup (Soldering Iron)

    6. OPERATION (Soldering iron) ● Operation and indication Switch and control button The front panel for the HAKKO FR-701 (Soldering iron) has the following two control buttons. DESOLDER POWER - Use this button to select and change settings.

  • Page 7: After Use

    CAUTION Place the iron in the iron holder when not in use. Turn the power off when the HAKKO FR-701 is not in use for an extended period. B. After use Always clean the tip and coat it with fresh solder after use.
  • Page 8 B. The preset mode The HAKKO FR-701 (Soldering iron) has a preset mode that will allow the unit to store up to 5 preset temperatures you can change between instead of using the above normal mode. Initial preset temperatures P1: 600℉ (316℃), P2: 700℉ (371℃), P3: 750℉ (399℃), P4: 800℉ (427℃), P5: 850℉ (454℃) The initial number of active presets is set to 5 at the factory.
  • Page 9 D. Restriction on setting changes (Password function) It is possible to restrict certain setting changes to the unit. There are three choices for the password setting. (The factory default is "0 : Open") 0 : Open 1 : Partial 2 : Restricted Move to the parameter setting mode ○...

  • Page 10: Parameter Setting (Soldering Iron)

    ※4 ○ : Password not required × : Password required ● Changing Parameter Setting The HAKKO FR-701 (Soldering iron) has four parameters. Turn the power on while pressing the button. Perform the setting to select the desired parameter No. Press the...

  • Page 11: Part Names (Desoldering Tool)

    Power Switch (Main) DESOLDER POWER Control Buttons Clogging SOLDER Indicator (Desoldering Tool) Vacuum DOWN ENTER outlet cap ENTER FR-701 Receptacle Power Switch (Desoldering Tool) (Desoldering Tool) ● Handpiece (HAKKO FR-4101 Desoldering Tool) Back holder Filter pipe Assembly Nozzle Heating element (Inside) Release knob Trigger...

  • Page 12: Initial Setup (Desoldering Tool)

    10. INITIAL SETUP (Desoldering Tool) A. Handpiece holder Loosen the adjusting screws to change the angle of the handpiece receptacle as you like, then tighten the screws. CAUTION Increasing the angle of the handpiece receptacle will cause an increase in the handpiece temperature. ●...
  • Page 13 4. Connect the hose from the HAKKO FR-4101 to the vacuum outlet cap on the HAKKO Connect the hose. FR-701 station. 5. Plug the power cord into a grounded power outlet. Ensure that the power switch is OFF before plugging in the power cord.

  • Page 14: Operation (Desoldering Tool)

    SOLDER Indicator - Moving the cursor UP. Increases the value. DOWN ENTER ENTER FR-701 - Moving the cursor DOWN. Decreases the value. - End of sequence (terminates a phase of a data entry mode). A. Desoldering CAUTION If the pump does not operate, immediately clean the nozzle &...
  • Page 15 Please wait for the heater to reach the set temperature. B. Making Changes to Settings ● Selecting the preset number The HAKKO FR-701 (Desoldering Tool) has a preset mode. 1. Press any of the three control buttons. 2. The preset selection screen appears.
  • Page 16 ● Changing various settings (other than preset selections) 1. Press and hold any one 2. The setting selection screen of the three control buttons appears. for at least 2 seconds. Set Temp Offset  Temp Vacuum Check <↑> <↓> <ENT> The following settings can be changed from this screen: Set Temp (Nozzle temperature setting) (Nozzle temperature offset setting)

  • Page 17: Parameter Settings (Desoldering Tool)

    <ENT> button in the parameter setting screen to return to the normal display. 13. MAINTENANCE (Desoldering Tool) Properly maintained, the HAKKO FR-701 desoldering tool should provide years of good service. Efficient desoldering depends upon the temperature, nozzle selection, and proper routine maintenance. Perform the following service procedures as dictated by the conditions of the station's usage.

  • Page 18: Replacing The Filter

    C. Replace the entire filter pipe with ● Replacing the filter a secondary filter pipe. B. Pull Replace the filter as shown following steps A to C. During operation, the filter pipe is very hot. Wait until the filter pipe is cool before replacing the filter or cleaning.

  • Page 19: Trouble Shooting Guide

    (with Filter) 14. TROUBLE SHOOTING GUIDE WARNING Before checking the inside of the HAKKO FR-701 or replacing parts, be sure to disconnect the power plug. ● Nothing happens when the power CHECK : Is the power cord and/or connecting plug disconnected? switch is turned on.
  • Page 20 ● The Heater-error is displayed. CHECK : Is the heater broken? ACTION : If the heater is broken, replace the heating element. (Soldering iron) CHECK : Is the setting value for the low-temperature alarm tolerance too low? ACTION : Increase the setting value. ●...
