Elements International KING BED STORAGE SR600KH Assembly Instructions

Caution: Please read instructions thoroughly before unpacking assembly parts. Sharp, exposed staple tips can
cause injury, therefore, for your protection, please remove any exposed staples used in packing.
1. We recommend that you should assemble this product with the assistance of another person; this will make
assembly easier, and will help to eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton
during shipment.
3. Please do not over tighten screws or bolts.
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your
newly purchased product correctly and efficiently.
PART DESC
No.
A
KING DRAWER FRONT PANEL
B
KING DRAWER SIDE PANEL-LEFT
KING DRAWER SIDE PANEL-RIGHT
C
D
KING DRAWER BOTTOM PANEL
E
KING DRAWER BACK PANEL
F
KING HEADBOARD
G
L&R HEADBOARD LEG
HEADBOARD STRETCHER
H
KING FOOTBOARD
I
J
FOOTBOARD BUN FEET
K SIDE RAIL
DRAWER BACK SUPPORT RAIL
L
M DRAWER SUPPORT RAIL WITH KENLINE
N
DRAWER SHORT SUPPORT LEG
O BED SLAT SUPPORT
P
KING SLAT - 13 SLATS (PCE)
DATE: 21-May-2021
Assembly Instructions
KING BED STORAGE
SR600KH/SR650KF/SR650QKR
PART LIST
CODE.
PSR650KFDRWTN
PSR600HBLEGTN
PSR600KHSTRTN
PSR600CGBFTTN
PSR650KFSLTTN
PSR650FDSRLTN
PSR650FDSPLTN
PSR650BDSPLTN
PSR650KBSLTTN
No. HARDWARE LIST (PACK WITH HEADBOARD)
Q'TY
1 Flat Washer 5/16''
2
Spring Washer 5/16''
2
2 3 Bolt 5/16''x50mm
Allen Key M4
4
2
HARDWARE LIST (PACKED WITH SIDERAILS)
2
5 Flat Washer 5/16''
2
Spring Washer 5/16''
6
1
Bolt 5/16''x25mm
7
2
Allen Key M4
8
1
HARDWARE LIST (PACK WITH FOOTBOARD)
1
9
Flat Washer 1/4''
2
Spring Washer 1/4''
10
11 Bolt 1/4''x35mm
2
12 Allen Key M4
1
13
Screw M4*25mm
4
14 Screw M3.5x12mm
2
15 Wooden Dowel Ø10*30
12
16
Kenline Slide
1 SET
CODE
Q'TY
8
8
8
1
12
12
PSR650KBHWTN 12
1
10
10
10
1
50
16
4
4
PSR600XSLD1TN
Page 01 of 04
