- Page 1 HEAT PUMP USER'S MANUAL HP-19 ▶ Thank you for purchasing the unit. Before operation, please read this user’s manual carefully.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS 3 ~ 4 GENERAL ADVICE BEFORE USE EXTERIOR DESCRIPTION 5 ~ 6 SPECIFICATIONS CONTROL PANEL FUNCTIONS 8 ~ 9 MODE CHANGING METHOD HOW TO SET THE 'OFF' TIMER TEMPERATURE CONTROL OPERATION SELECTION 'ERROR' and WARNING INDICATORS TROUBLE SHOOTING CLEANING AND MAINTENANCE USING MOBILE APPLICATION... -
Page 3: Safety Instructions 3
SAFETY INSTRUCTIONS WARNING ● •Keep this manual in a visible location near the unit for easy reference. The following symbols are for your guidance : You must NOT. You MUST. Use a circuit breaker that fits the capacity. (It may cause fire and electric shock) Before cleaning, disconnect the unit. -
Page 4: General Advice Before Use
SAFETY INSTRUCTIONS CAUTION ● Do not place this unit on uneven, unstable or inclined surface. (This could cause malfunction) When storing this unit, keep it in a dry, cool place. (To prevent corrosion and malfunction) If not being used for some time or if lightening is present, always disconnect power. (To prevent risk of electric shock, short circuit or fire) Do not spray water onto this unit nor use solvents such as benzene, thinner or alcohol for cleaning. -
Page 5: Exterior Description 5
EXTERIOR DESCRIPTION FRONT VIEW ● Digital Controller Louver Outlet (Cool air in A/C, Warm air in Heater) Evaporator Filter Protection Bumper (Ambient air inlet) Condensate Tank Door Casters (Front Lockable) (Condensate Tank Inside) - Page 6 EXTERIOR DESCRIPTION BACK & SIDE VIEW ● Hot Air Outlet Electrical Access Panel Condenser Filter Power Cord...
-
Page 7: Specifications
SPECIFICATIONS MODEL HP-19 Cooling 19,000 (5,570) Capacity Btu/h (W) Heating 19,000 (5,570) Power Supply 230-240 V~, 50 Hz, 1 Ph Cooling Power Consumption Heating Cooling 9.2 (27℃ 50%) / Max.13 (45℃ 40%) Current Consumption Heating 9.5 (20℃ 60%) / Max.11 (27℃ 50%) Max. -
Page 8: Control Panel Functions 8
CONTROL PANEL FUNCTIONS Smart Control System ⑦ ⑧ ⑨... - Page 9 CONTROL PANEL FUNCTIONS NAME DESCRIPTION Power Use to power on / off. Fan Speed Controls fan low / high speed. Raises or lowers the setting temperature or ∨ ∧ Button sleep (off) time. Use to select Cooling / Dehumidification / Fan / Mode Heating / Auto mode.
-
Page 10: Mode Changing Method
MODE CHANGING METHOD ● COOLING MODE If you press the 'Mode' button. 'Cooling symbol' is displayed. ● DEHUMIDIFICATION MODE If you press the 'Mode' button when the 'cooling' is operating, 'dehumidification symbol' is displayed. ● FAN MODE If you press the 'Mode' button when the 'Dehumidification' is operating, 'Fan symbol' is displayed. -
Page 11: How To Set The 'Off' Timer
HOW TO SET THE 'OFF' TIMER This function enables you to set the length of time you want the unit to operate. STEP 1 1. When unit is operating, press the 'Off Timer' button and set the length of time you want by pressing ∧ or ∨. Each time you press the button you will increase the 'time to off' period by 30 mins. -
Page 12: Temperature Control Operation
TEMPERATURE CONTROL OPERATION •When you turn ON, the setting temperature is displayed. •You can change setting temperature. ● Display Room Temperature Range & Setting Range. COOLING MODE Cooling operates when room temperature is Mode Display range Setting range higher than set temperature. Room 18℃... -
Page 13: Selection
SELECTION ● SPOT or ROOM MODE To change the temperature of the entire room, select 'Room mode'. For targeted cooling of machinery servers or people etc select 'Spot mode'. Applicable only when cooling mode. 3 sec • If you want to see room temperature, when unit is operated, push 'mode' and '∨' button simultaneously for 3 seconds. -
Page 14: Error' And Warning Indicators
'ERROR' and WARNING INDICATORS Error Code Problem Cause Corrective Action High pressure Blocked COND filter. Clean the COND filter. Blocked / kinked exhaust duct. Ensure exhaust duct is not blocked Ambient temperature is too high. / kinked. Do not use the air conditioner if ambient temperature is higher 45°C. -
Page 15: Trouble Shooting
TROUBLE SHOOTING TROUBLE CHECK REMEDY Power cable correctly connected. Connect cable correctly. Power button "OFF". Press POWER button to "ON". Fuse (supply) blown. Exchange fuse in board. WORKING Breaker on switch board tripped. Check load capacity and reset. Ambient temperature too high. Check operating temperature range. -
Page 16: Using Mobile Application 16
USING MOBILE APPLICATION USING MOBILE APPLICATION INSTALLING APPLICATION 1. Start Google Play or App Store Start Google Play 2. Find Airrex application Find Airrex application (available in countries: Finland, Sweden, Install the application Norway. Denmark, Iceland, Estonia, Latvia, Lithuania, United Kingdom) 3. - Page 17 Scan the barcode with your the connection process. camera to read to barcode. Press MANUAL to type the serial number manually. 5. Fill in the Rex Nordic 3 6. Turn the HEATPUMP 7. Choose the product to 8. Choose your Wi-Fi years warranty form.
- Page 18 USING MOBILE APPLICATION USING MOBILE APPLICATION CONNECTING HEATER TO APPLICATION CONNECTING HEATPUMP TO APPLICATION NOTICE Wi-Fi light blinking twice Searching for Wi-Fi network Wi-Fi light blinking once Connected to Wi-Fi, but not to internet Wi-Fi light on Connected to Wi-Fi and internet.
- Page 19 USING MOBILE APPLICATION USING MOBILE APPLICATION USING THE MOBILE APPLICATION APPLICATION DASHBOARD The mobile application works the same way with the normal control panel. Please refer to the operating instructions in this user manual to understand what each button does. Push notifications Add new product Application settings menu...
- Page 20 USING MOBILE APPLICATION NOTICE WHEN USING MOBILE APPLICATION - Wireless router and LAN cable are separate purchases. Each must be installed separately. - REXNORDIC heat pump uses WPA2 Security method - Airrex heater uses WPA2 Security method to connect to the router. - REXNORDIC heat pump supports only 4GHz of Wi-Fi - Airrex supports only 2,4GHz of Wi-Fi Frequency.
-
Page 21: Wiring Diagram
WIRING DIAGRAM RELAY PCB 250 V~, 5 A TER1 CON1 TER3 TER4 COMP... -
Page 22: The Installation, Service And Operation Manaul 22
The installation, service and operation manual WARNING : Flammable materials. THE INSTALLATION, SERVICE AND OPERATION MANUAL WARNING : Low burning velocity material. WARNING •Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. •The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater. - Page 23 The installation, service and operation manual 2.2 Information and training •The training should include the substance of the following: •Information about the explosion potential of FLAMMABLE REFRIGERANTS to show that flammables may be dangerous when handled without care. •Information about POTENTIAL IGNITION SOURCES, especially those that are not obvious, such as lighters, light switches, vacuum cleaners, electric heaters.
- Page 24 The installation, service and operation manual c) Repair • Portable equipment shall be repaired outside or in a workshop specially equipped for servicing units with FLAMMABLE REFRIGERANTS. • Ensure sufficient ventilation at the repair place. • Be aware that malfunction of the equipment may be caused by refrigerant loss and a refrigerant leak is possible.
- Page 25 The installation, service and operation manual e) Disposal • Ensure sufficient ventilation at the working place. • Remove the refrigerant. If the recovery is not required by national regulations, drain the refrigerant to the outside. Take care that the drained refrigerant will not cause any danger. In doubt, one person should guard the outlet.
- Page 26 The installation, service and operation manual 5. No ignition sources No person carrying out work in relation to a REFRIGERATING SYSTEM which involves exposing any pipe work shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion.
- Page 27 The installation, service and operation manual Repairs to sealed components - During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation.
- Page 28 The installation, service and operation manual Electronic leak detectors may be used to detect refrigerant leaks but, in the case of FLAMMABLE REFRIGERANTS, the sensitivity may not be adequate, or may need re-calibration. (Detection equipment shall be calibrated in a refrigerant-free area.) Ensure that the detector is not a potential source of ignition and is suitable for the refrigerant used.
- Page 29 The installation, service and operation manual d) Pump down refrigerant system, if possible. e) If a vacuum is not possible, make a manifold so that refrigerant can be removed from various parts of the system. f) Make sure that cylinder is situated on the scales before recovery takes place. g) Start the recovery machine and operate in accordance with instructions.
- Page 30 The installation, service and operation manual If compressors or compressor oils are to be removed, ensure that they have been evacuated to an acceptable level to make certain that flammable refrigerant does not remain within the lubricant. The compressor body shall not be heated by an open flame or other ignition sources to accelerate this process.
- Page 31 Memo...
-
Page 32: Warranty
Manufactured by : HEPHZIBAH CO.,LTD. (Juan-dong) 86, Gilpa-ro 71beon-gil, Michuhol-gu, Incheon, Korea TEL : +82-32-509-5834 REX NORDIC GROUP FAX : +82-32-502-5519 Mustanlähteentie 24 A, 07230 Askola, Finland +358 40 180 11 11 I info@rexnordic.com I rexnordic.com Website : www.airrex.biz Manufactured by : HEPHZIBAH CO.,LTD.
