Panasonic LUMIX DMC-FZ35P Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Digital Camera
  5. LUMIX DMC-FZ35P
  6. Service manual

Panasonic LUMIX DMC-FZ35P Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DMC-FZ35P
Model No.
DMC-FZ35PC
DMC-FZ35PU
DMC-FZ35GC
DMC-FZ35GT
DMC-FZ35GK
DMC-FZ35GN
DMC-FZ35GD
DMC-FZ38EG
DMC-FZ38EP
DMC-FZ38EF
DMC-FZ38EB
DMC-FZ38EE
DMC-FZ38SG
VOL.1
Colours
(K)....................Black Type
© Panasonic Corporation 2009.
Unauthorized copying and distribution is a violation
of law.
ORDER NO.DSC0908044CE
B26
Digital Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUMIX DMC-FZ35P and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic LUMIX DMC-FZ35P

Summary of Contents for Panasonic LUMIX DMC-FZ35P

  • Page 1 ORDER NO.DSC0908044CE Digital Camera DMC-FZ35P Model No. DMC-FZ35PC DMC-FZ35PU DMC-FZ35GC DMC-FZ35GT DMC-FZ35GK DMC-FZ35GN DMC-FZ35GD DMC-FZ38EG DMC-FZ38EP DMC-FZ38EF DMC-FZ38EB DMC-FZ38EE DMC-FZ38SG VOL.1 Colours (K)....Black Type © Panasonic Corporation 2009. Unauthorized copying and distribution is a violation of law.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions -----------------------------------------------3 1.1. General Guidelines ----------------------------------------3 1.2. Leakage Current Cold Check ---------------------------3 1.3. Leakage Current Hot Check (See Figure 1)---------3 1.4. How to Discharge the Capacitor on Main PCB -----4 2 Warning --------------------------------------------------------------5 2.1.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check 1. IMPORTANT SAFETY NOTICE (See Figure 1) There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check.

  • Page 4: How To Discharge The Capacitor On Main Pcb

    1.4. How to Discharge the Capacitor on Main PCB • This unit equipped with two pieces of capacitors as flash charging capacitors. “Either one of the capacitor discharging operation” makes discharging for others as well. CAUTION: 1. Be sure to discharge the capacitor on MAIN PCB. 2.

  • Page 5: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).

  • Page 6: Caution For Ac Cord (For Eb/Gc

    2.3.2.3. How to Replace the Fuse A replacement fuse cover can be purchased from your local Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety.

  • Page 7: How To Replace The Lithium Battery

    Note: The lithium battery is a critical component. (Type No.: ML-614S/ZTK Manufactured by Energy Company, Panasonic Corporation) It must never be subjected to excessive heat or discharge. It must therefore only be fitted in equipment designed specifically for its use.

  • Page 8: Service Navigation

    3 Service Navigation 3.1. Introduction This service manual contains technical information, which will allow service personnel's to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2.

  • Page 9: How To Define The Model Suffix

    3.4. How to Define the Model Suffix There are nine kinds of DMC-FZ35/FZ38, regardless of the colours. • a) DMC-FZ38 (Japan domestic model.)/SG • b) DMC-FZ35P/PC • c) DMC-FZ38EB/EF/EG/EP • d) DMC-FZ38EE • e) DMC-FZ35GD • f) DMC-FZ35GT • g) DMC-FZ35GN •...

  • Page 10: Initial Settings

    3.4.2. INITIAL SETTINGS: When you replace the Main/Flash ROM, be sure to perform the initial settings after achieving the adjustment by ordering the follow- ing procedure in accordance with model suffix of the unit. 1. IMPORTANT NOTICE: Before proceeding Initial settings, be sure to read the following CAUTIONS. 2.
  • Page 11 [CASE 1. After replacing MAIN PCB / FLASH ROM] [Other than "EG, EP, EF and EB" models : (VEP56091A is used as a Main PCB)] When MAIN PCB has just been replaced, all of the model suffix are displayed as follows. (Three pages in total) [Only for "EG, EP, EF and EB"...
  • Page 12 • Step 7. CONFIRMATION: Confirm the display of "PLEASE SET THE CLOCK" in concerned language when the unit is turned on again. When the unit is connected to PC with USB cable, it is detected as removable media. 1) As for your reference Default setting condition is given in the following table. •...

  • Page 13: Specifications

    4 Specifications...
  • Page 15 Note: *Above specification is for DMC-FZ35P-K. Some of the specification may differ depends on model suffix. [1].Only for "EB/EF/EG/EP" models. 1).[Interface Digital:] • Data from the PC can not be written to the camera using the USB connection cable. 2).[Motion pictures:] [AVCHD Lite] (With audio) When set to [SH]: 1280k720 pixels (50p recording*1/17 Mbps, only when card is used) /...
  • Page 16 [2].Others: 1).[Focus range Indication:] ft (feet)----------(Only "P" model) m (meter)------(Except "P" model) 2).[Analog video/audio:] NTSC ----------------------------------------------------(Only "P/PC/PU/GT/GD" models) NTSC/PAL Composite (Switched by menu) ----(Except "P/PC/PU/GT/GD" models) Audio line output (stereo) 3).[Conversion settings:] [OFF]/[Tele conversion]/[Close-up]---(Except "GK" model) Not available--------------(Only "GK" model)

  • Page 18: Location Of Controls And Components

    5 Location of Controls and Components...

  • Page 22: Service Mode

    6 Service Mode 6.1. Error Code Memory Function 1. General description This unit is equipped with history of error code memory function, and can be memorized 16 error codes in sequence from the latest. When the error is occurred more than 16, the oldest error is overwritten in sequence. The error code is not memorized when the power supply is shut down forcibly (i.e.,when the unit is powered on by the battery, the　battery is pulled out) The error code is memorized to FLASH ROM when the unit has just before powered off.
  • Page 23 Attribute Main item Sub item Error code Contents (Upper) Error Indication High 4bits Low 4 bits Check point (Lower) Detecting Part/Circuit device LENS Lens drive OIS 18*0 1000 PSD (X) error. Hall element (X axis) position detect OIS X LENSu NG error in OIS unit.
  • Page 24 Attribute Main item Sub item Error code Contents (Upper) Error Indication High 4bits Low 4 bits Check point (Lower) Detecting Part/Circuit device C000 OIS adj. Yaw direction position sensor error D000 OIS adj. Pitch direction position sensor error E000 OIS adj. other error HARD VENUS Flash...
  • Page 25 Important notice about "Error Code List" 1) About "*" indication: The third digit from the left is different as follows. +.In case of 0 (example: 18 0 01000) When the third digit from the left shows "0", this error occurred under the condition of INITIAL SETTINGS has been com- pleted.

  • Page 26: Service Fixture & Tools

    7 Service Fixture & Tools 7.1. Service Fixture and Tools The following Service Fixture and tools are used for checking and servicing this unit.

  • Page 27: Clean Box

    7.2. Clean Box 7.2.1. Servicing the Lens unit. To keep dust proof environment when repairing lens unit, CLEAN BOX is recommended (less than class 10,000 Federal Standard 209D). 7.2.2. Introduction of Clean box. One of our recommended clean box is as shown below. It consists of "Air clean unit"...
  • Page 28 7.4.1. Extension Cable Connections CAUTION-1. (When servicing MAIN PCB) 1. Be sure to discharge the capacitor on MAIN PCB. Refer to “HOW TO DISCHARGE THE CAPACITOR ON MAIN PCB”. The capacitor voltage is not lowered soon even if the AC Cord is unplugged or the battery is removed. 2.

  • Page 29: Disassembly And Assembly Instructions

    8 Disassembly and Assembly Instructions 8.1. Disassembly Flow Chart 8.2. PCB Location...

  • Page 30: Disassembly Procedure

    8.3. Disassembly Procedure 8.3.1. Removal of the Rear Case Unit Item Fig. Removal Rear Case Unit Fig.D1 Card Battery 3 Screws (A) 2 Screws (B) 1 Screw (C) Fig.D2 P9001 (Connector) FP9003 (Flex) FP9006 (Flex) Rear Case Unit EVF Unit Fig.D3 FP9004 (Flex) EVF Unit...
  • Page 31 8.3.2. Removal of the EVF Unit Fig. D2 Fig. D3...
  • Page 32 8.3.3. Removal of the Main P.C.B. Unit, • This unit equipped with two pieces of capacitors as flash charging capacitors. GYRO P.C.B., Battery Frame Unit “Either one of the capacitor discharging operation” makes and Condenser Cover discharging for others as well. Fig.

  • Page 33: Removal Of The Speaker

    8.3.5. Removal of the LCD Unit Fig. D6 8.3.4. Removal of the Speaker Fig. D8 8.3.6. Removal of the Jack Door Unit Fig. D7 Fig. D9...
  • Page 34 8.3.7. Removal of the AF LED P.C.B. Fig. D10 8.3.8. Removal of the Flash Unit, MIC P.C.B. Fig. D11 Fig. D12...
  • Page 35 Fig. D15 8.3.9. Removal of the Top Operation Unit Fig. D13 Fig. D16 Fig. D14...

  • Page 36: Disassembly/Assembly Procedure For The Lens

    8.3.10. Removal of the Lens Unit 8.4. Disassembly/Assembly Proce- dure for the Lens NOTE: When Disassembling and Assembling for the Lens 1. Recommended clean level of repairing lens unit for this model is less than class 10,000. (Federal Standard 209D) To keep maintaining the dust proof environment, it is recommended dealing with Clean box (Refer to “7.2.
  • Page 37 8.4.2. Removal of the 1st Lens Frame Unit 8.4.3. Removal of the 2nd Lens Frame Unit...
  • Page 38 8.4.4. Removal of the Master Flange Unit 8.4.5. Removal of the Cam Frame...
  • Page 39 8.4.6. Removal of the Focus Motor Unit 8.4.7. Removal of the 4th Lens Frame Unit...

  • Page 40: Removal Of The Ccd Unit

    8.4.8. Removal of the 3rd Lens Frame 8.5. Removal of the CCD Unit Unit To prevent the CCD unit from catching the dust and dirt, do not remove the CCD unit except for replacing.

  • Page 41: Measurements And Adjustments

    9 Measurements and Adjustments 9.1. Matrix Chart for Replaced Part and Necessary Adjustment The relation between Replaced part and Necessary Adjustment is shown in the following table. When concerned part is replaced, be sure to achieve the necessary adjustment(s). As for Adjustment condition/procedure, consult the “Adjustment Manual” which is available in Adjustment software. The Adjustment software is available at “TSN Web-site”, therefore, access to “TSN Web-site”...

  • Page 43: Maintenance

    10 Maintenance 10.1. Cleaning Lens, Viewfinder and LCD Panel Do not touch the surface of lens, Viewfinder and LCD Panel with your hand. When cleaning the lens, use air-Blower to blow off the dust. When cleaning the LCD Panel, dampen the lens cleaning paper with lens cleaner, and the gently wipe the their surface. Note: The Lens Cleaning KIT ;...
  • Page 44 DSC0908044CE S1. About Indication of The Schematic Diagram Service Manual S1.1. Important Safety Notice COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS Diagrams and Replacement FOR SAFETY. WHEN REPLACING ANY OF THESE COMPONENTS USE ONLY THE SAME TYPE. 1.Although reference number of the parts is indicated on the P.C.B. drawing and/or Parts List schematic diagrams, it is NOT mounted on the P.C.B.

  • Page 45: S2. Voltage Chart

    S2. Voltage Chart Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester. S2.1.

  • Page 46: S3. Block Diagram

    S3. Block Diagram S3.1. Overall Block Diagram IC6002 (27mm ~ 486mm) IC3001 FLASH ROM IC3101 PRE PROCESS /512Mbit CDS,AGC, 1/2.33" 12 MEGA PIX A/D,TG, SDRAM/512Mbit CCD DRIVER ZOOM IRIS SHUTTER OIS UNIT FOCUS CARD IC9601 HDMI HDMI DRIVER TERMINAL IC9101 MOTOR DRIVE, MICROPHONE OIS DRIVE&...

  • Page 47: S4. Schematic Diagram

    S4. Schematic Diagram S4.1. Interconnection Diagram MICROPHONE FP5201 FP5202 PW 5W MIC GND MIC P.C.B. MIC R IN MIC L IN (FOIL SIDE) MIC REG MAIN - MIC FPC EVF UNIT FT9301 TOP OPERATION UNIT FLASH UNIT BATTERY FP9001 FP9006 PW BL PLUS PW BL MINUS LED RANK...

  • Page 48: S4.2. Gyro Flex Schematic Diagram

    S4.2. Gyro Flex Schematic Diagram / S4.3. AF LED Flex Schematic Diagram C7205 Sleep Vref Vout F1J1A106A024 IC7201 TO MAIN L2ES00000021 C7201 FT9301 (46.5kHz) F1H1A104A028 FT7201 N.C. N.C. N.C. SELF_LED_A C7203 SELF_LED_A PW_GY3R1V F1H1A105A036 SELF_LED_A PW_GY3R1V SELF_LED_K VREF_Y G_GYRO_Y SELF_LED_K (SML-J14DTT96) SELF_LED_K GYRO_GND...

  • Page 49: S4.4. Mic Schematic Diagram

    S4.4. Mic Schematic Diagram CL5205 R5227 CL5206 Q5203 2SD2216J0L C5205 R5214 0.033 F1G1A333A032 R5231 C5201 R5204 C5206 C5209 R5215 R5223 4700 F1G1A1040006 F1G1H181A541 180P F1G0J224A001 6.3V C5202 R5207 MIC_GND 0.015 MIC_R_IN F1G1C153A081 MIC_L_IN R5232 R5211 QR5204 R5205 150K 150K XP0431400L MIC_GND K1MN04BA0208 R5209...

  • Page 50: S4.5. Ccd Flex Schematic Diagram

    S4.5. CCD Flex Schematic Diagram FT3101 TH3101 D4CC11030026 CCD_POWER CCD_THERMO MSUB MSUB MSUBSW MSUBSW SUBSW1 SUBSW1 SUBSW2 SUBSW2 CCD_GND CCD_OUT CCD_GND CCD_GND MSUB MSUB V11B MSUBSW V11B MSUBSW R3107 IC3101 1300 MN34540PAH-V SUBSW1 SUBSW1 SUBSW2 SUBSW2 R3101 V11B V11B 17 18 R3108 R3102 2200...

  • Page 51: S4.6. Lens Flex Schematic Diagram

    S4.6. Lens Flex Schematic Diagram POSITIVE VOLTAGE LINE PHOTO ZOOM ENCODER 1 SENSOR PHOTO ZOOM ENCODER 2 SENSOR DC MOTOR ENC_Vcc(D2R9V) ABS(ZENC1) LED_CONT(Z1_LED) ABS(ZENC2) PHOTO FOCUS ENCODER LED_CONT(Z2_LED) SENSOR ENC_Vcc(D2R9V) ZM2(DCM-) ZM2(DCM-) ZM1(DCM+) DC SOLENOID ZM1(DCM+) (SHUTTER) ABS(FHP) LED_CONT(FHP_LED) ENC_Vcc(D2R9V) SHUTTER UNIT ST3(IRIS_BP) SH-(SHUT_OUT1)

  • Page 52: S5. Print Circuit Board

    S5. Print Circuit Board S5.1. Gyro Flex P.C.B. FT7201 C7201 (Foil Side) DMC-FZ35/FZ38 Gyro Flex P.C.B.

  • Page 53: S5.2. Af Led Flex P.c.b

    S5.2. AF LED Flex P.C.B. VJB59070 D9301 (Foil Side) DMC-FZ35/FZ38 AF LED Flex P.C.B. S-10...

  • Page 54: S5.3. Mic P.c.b

    S5.3. Mic P.C.B. R5213 C5208 C5207 R5216 C5210 R5212 Q5203 R5206 QR5204 R5207 1 2 3 C5213 R5209 (Component Side) CL5203 LB5203 CL5201 R5231 CL5205 CL5204 CL5206 C5201 R5220 CL5202 VA5201 R5232 CL5207 VA5202 FP5201 R5203 R5221 R5219 C5212 (Foil Side) DMC-FZ35/FZ38 Mic P.C.B.

  • Page 55: S5.4. Ccd Flex P.c.b

    S5.4. CCD Flex P.C.B. FT3101 C3101 IC3101 R3107 R3101 TH3101 (Component Side) (Foil Side) DMC-FZ35/FZ38 CCD Flex P.C.B. S-12...

  • Page 56: S5.5. Lens Flex P.c.b

    S5.5. Lens Flex P.C.B. FOCUS MOTOR UNIT ZOOM MOTOR FOCUS ENCODER SHUTTER UNIT OIS UNIT ZOOM ZOOM ENCODER 2 ENCODER 1 CAM ENCODER Pin 1 Pin 40 DMC-FZ35, FZ38 LENS FLEX P.C.B. S-13...
  • Page 57 S-14...

  • Page 58: S6. Replacement Parts List

    ELECTROSTATIC DISCHARGE (ESD) TO ELECTROSTATICALLY SENSITIVE (ES) DEVICES section. <DEFINITION OF PARTS SUPPLIER> 1. Parts marked with [Energy] in the remarks column are supplied from Panasonic Corporation Energy Company. 2. Parts marked with [SPC] in the remarks column are supplied from AVC-CSC-SPC.
  • Page 59 DMC-FZ38EG,EP,EF,EB,EE,SG DMC-FZ35P,PC,PU,GC,GT,GK,GN,GD vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks R5217 D0GA104JA021 RESISTOR VEP56091A MAIN P.C.B. 1 (RTL) E.S.D. EE,SG,P,PC, R5218 D0GA472JA021 RESISTOR PU,GC,GT,GK,GN,GD R5219 D0GA104JA021 RESISTOR VEP56091B MAIN P.C.B. 1 (RTL) E.S.D. EG,EP,EF,EB R5220 D0GA472JA021 RESISTOR VEP59069A...
  • Page 60 DMC-FZ38EG,EP,EF,EB,EE,SG DMC-FZ35P,PC,PU,GC,GT,GK,GN,GD vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks L0AA01A00041 SPEAKER VHD1684 SCREW VMP9538 SP FIX PLATE VHD1684 SCREW VMP9421 LCD HOLDER VHD1684 SCREW VYK3P91 REAR CASE (1) U VHD1870 SCREW VMS7523 STRAP HOLDER...
  • Page 61 DMC-FZ38EG,EP,EF,EB,EE,SG DMC-FZ35P,PC,PU,GC,GT,GK,GN,GD vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VQT2E85 OPERATING INSTRUCTIONS 1 EP [SPC] ----- BATTERY PACK 1 EG,EP,EF,EB,EE,SG,PU, (POLISH/CZECH) GC,GT,GN,GD VQT2E86 OPERATING INSTRUCTIONS 1 EP [SPC] ----- BATTERY PACK 1 P,PC (HUNGARIAN/FINNISH) -----...

  • Page 62: S7. Exploded View

    S7. Exploded View S7.1. Frame and Casing Section (1) B51 B52 61-1 61-4 61-2 61-3 12-1 12-2 S-19...

  • Page 63: S7.2. Frame And Casing Section (2

    S7.2. Frame and Casing Section (2) 35-2 22-1 S-20...

  • Page 64: S7.3. Packing Parts And Accessories Section

    S7.3. Packing Parts and Accessories Section (EP/EE/EF/EG/GC) (EB/GC/SG) (Not supplied) (GD) 125, (GK) (GN) (GT) S-21...
