Phantom Sauna with Half Moon Window
OWNER'S MANUAL
WARNING! Do not place anything combustible close to
heater, above the heater, and on both sides of the
heater. This includes but not limited to towels, lights, robe hookes,
accessories, etc. Nothing should be on the same wall as your heater
that is combustible.
Advertisement
Related Manuals for Salus Phantom
Summary of Contents for Salus Phantom
- Page 1 Phantom Sauna with Half Moon Window OWNER’S MANUAL WARNING! Do not place anything combustible close to heater, above the heater, and on both sides of the heater. This includes but not limited to towels, lights, robe hookes, accessories, etc. Nothing should be on the same wall as your heater...
- Page 2 Installation guide BARRELS PARTS 1 CENTER CRADLES BODY FINAL H-TYPE x80 (+1 STAVE STAVES TOP STAVE reserve) FRONT REAR REAR PANEL LEFT PANEL PANEL PANEL WITH SECTION WINDOW RIGHT ASPEN FLOORING DECORATIVE ROOF NISHING PANEL ROOF DUCKBOARD BOARDS SECTION BOARD WIRE INTERIOR BENCH...
- Page 3 Installation guide Barrel Nº62 BARRELS PARTS 2 x120 SCREW SCREW 5.0X120 SCREW STAINLESS 4.2X7 STEEL SCREW 4.0X50 4.2X7 STAINLESS Ø BOLT HEX NUT FLAT STEEL SCREW 16X140 M16 (SW24) WASHER 4.0X50 TOOLS REQUIRED: 24mm Rubber 3 People 6´ Recommended STEP ZERO Before you begin, be sure the L= 7´4´´...
- Page 4 Installation guide Barrel Nº62 BARRELS STEP ONE Measure support cradles (A) diagonally from corner to corner. Measurements “a” and “b” should be equal to ensure the cradles are square. Be sure cradles remain level. STEP TWO Back Place the support cradles (A) on level site.
- Page 5 Installation guide Barrel Nº62 BARRELS STEP FOUR Vent Place door panel (D) in front slot. Be sure panel is centered, leveled, completely seated. A ach side panels (F, F1) using 4 5.0 x 120 (M) screws and 2 4.2 x 70 (N1) stainless steel screws.
- Page 6 Installation guide Barrel Nº62 BARRELS STEP SIX Continue placing body staves (C) WARNING! tightly on both sides of the sauna Use shorter screw 4.0 x 50 (P) using rubber mallet, while fixing for rear panel E1 otherwise body staves on the front panel with the window will be damaged! 4.2 x 70 screws and rear window panel with 4.0 x 50 screws to...
- Page 7 Installation guide Barrel Nº62 BARRELS STEP EIGHT A ach interior supporting leg (J1) to the bench (J), install two sauna benches on wall mounts using stainless steel screws 4.2 x 70 (N1). Hold the seat and leg assembly tight to the sauna wall. Using a level, make sure the bench seat is level from front to back.
- Page 8 Installation guide Barrel Nº62 BARRELS STEP TEN Place waterproof roof cover (Z) and fix it with wooden slat (Z1) and screws 4.0 x 50 (P). Install front and rear decorative roof finishing boards (W), fixing by screws 4.0 x 50 (P). WATCH THE VIDEO...
- Page 9 SEE HOW ASSEMBLY WILL LOOK HERE www.SalusSaunas.com...
