Panther Sauna with Half Moon Window
OWNER'S MANUAL
WARNING! Do not place anything combustible close to
heater, above the heater, and on both sides of the
heater. This includes but not limited to towels, lights, robe hookes,
accessories, etc. Nothing should be on the same wall as your heater
that is combustible.
Advertisement
Related Manuals for Salus Panther
Summary of Contents for Salus Panther
- Page 1 Panther Sauna with Half Moon Window OWNER’S MANUAL WARNING! Do not place anything combustible close to heater, above the heater, and on both sides of the heater. This includes but not limited to towels, lights, robe hookes, accessories, etc. Nothing should be on the same wall as your heater...
- Page 2 BARRELS Installation guide PARTS 1 CENTER CRADLES FINAL H TYPE BODY x70 (+2 STAVE TOP STAVE STAVES reserve) FRONT REAR REAR PANEL LEFT PANEL PANEL PANEL WITH SECTION WINDOW DECORATIVE RIGHT ASPEN FLOORING ROOF NISHING PANEL ROOF DUCKBOARD BOARDS SECTION BOARD INTERIOR BENCH...
- Page 3 BARRELS Installation guide Barrel Nº54 PARTS 2 SCREW SCREW STAINLESS SCREW x130 4.0X50 5.0X120 4.2X7 STEEL SCREW 4.2X7 STAINLESS Ø BOLT HEX NUT FLAT STEEL SCREW 16X140 M16 SW24 WASHER 4.0X50 TOOLS REQUIRED 24mm Rubber 3 People 6´ Recommended STEP ZERO Before you begin, be sure the L= 4´9´´...
- Page 4 BARRELS Installation guide Barrel Nº54 STEP ONE Measure support cradles (A) diagonally from corner to corner. Measurements “a” and “b” should be equal to ensure the cradles are square. Be sure cradles remain level. STEP TWO Place the support cradles (A) Back on level site.
- Page 5 BARRELS Installation guide Barrel Nº54 STEP FOUR Vent Place door panel (F2) in front slot. Be sure panel is centered, leveled, completely seated. A ach side panels (F, F1) using 4 5.0 x 120 (M) screws and 2 4.2 x 70 (N1) stainless steel screws.
- Page 6 BARRELS Installation guide Barrel Nº54 STEP SIX Continue placing body staves (C) WARNING! tightly on both sides of the sauna Use shorter screw 4.0 x 50 (P) using rubber mallet, while fixing for rear panel V1 otherwise body staves on the front panel with the window will be damaged! 4.2 x 70 screws and rear window panel with 4.0 x 50 screws to...
- Page 7 BARRELS Installation guide Barrel Nº54 STEP EIGHT A ach interior supporting leg (J1) to the bench (J), install two sauna benches on wall mounts using stainless steel screws 4.2 x 70 (N1). Hold the seat and leg assembly tight to the sauna wall. Using a level, make sure the bench seat is level from front to back.
- Page 8 BARRELS Installation guide Barrel Nº54 STEP TEN Place waterproof roof cover (Z) and fix it with wooden slat (Z1) and screws 4.0 x 50 (P). Install front and rear decorative roof finishing boards (W), fixing by screws 4.0 x 50 (P). WATCH THE VIDEO...
- Page 9 SEE HOW ASSEMBLY WILL LOOK HERE www.SalusSaunas.com...
