Summary of Contents for PSS Eco600
- Page 1 Eco UPS 600 – 2200va USER MANUAL www.pssdistributors.com.au...
-
Page 2: Table Of Contents
Contents Introduction statement ....................3 Safety notes ........................3 Description ........................3 Eco 800VA (Powerboard type UPS) ................3 Eco 600, 1000, 1400 and 2200VA ................4 Positioning the UPS ......................5 Connecting the UPS ....................... 5 Monitoring Software ....................... 6 Trouble shooting ...................... -
Page 3: Introduction Statement
1. Introduction statement Thank you for choosing ECO UPS by PSS Distributors, ranging from 600VA-2200VA. This UPS is specifically designed for Small Office Home Office (SOHO) CCTV and POS applications. Its lightweight compact design perfectly fits into the working environment. It is equipped with a voltage regulator which stabilises the voltage. -
Page 4: Eco 600, 1000, 1400 And 2200Va
6. Surge protection outputs only 7. UPS and surge protected outputs. 8. LAN connection. 9. Mounting holes. 10. Battery cover. 3.2 Eco 600, 1000, 1400 and 2200VA 1. ON/OFF Switch 2. LCD: Voltage in and out and load and battery level. LED: Power on, Battery charging and fault. -
Page 5: Positioning The Ups
1. IEC mains input 2. UPS and surge protected outputs. 3. USB communications port and LAN connection 4. USB communications port and RS232 5. LAN connection. 4 Positioning the UPS • Once the unit has been unpacked, examine the UPS for any damage, do not switch the UPS on if there is any damage. -
Page 6: Monitoring Software
• An audible alarm will sound for a second and the devices and LED/LCD will illuminate. • It is safe to now plug in devices that need to be protected by the UPS. 6 Monitoring Software • Connect USB cable suppled to Communications USB on the UPS to a USB on the computer (only supplied on 800, 1400 and 2200VA) •... -
Page 7: Specifications
8 Specifications Model Eco600 Eco800L Eco1000 Eco1400L Eco2200L Capacity 600VA/360W 800VA/480W 1000VA/600W 1400VA/840W 2200VA/132000W Display Input Input Voltage 230V AVR voltage range 162V-290V Frequency range 50Hz ± 10% Output Voltage regulation 230Vac ± 10% Frequency Batt. Mode 50Hz, +/- 1% Waveform Modified/Simulated Sine Wave...
