ThePondguy UltraUV Pro Installation Manual

Pond uv clarifier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Table of Contents:

Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
UV Diagrams and Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 -6
Flow Rates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Positioning and Mounting the UV . . . . . . . . . . . . . . . . . . . .8-10
Connecting Your Plumbing . . . . . . . . . . . . . . . . . . . . . . . . .10-11
Installing a Ball Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installing the Quartz Sleeve . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Water Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Connection to the Power Supply . . . . . . . . . . . . . . . . . . . . . . 15
Installing the UV Bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
UV Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Replacing / Cleaning the Quartz Sleeve . . . . . . . . . . . . . . . . 18
Transformer Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Thermal Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . .22-23
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
UltraUV
Pond UV Clarifier
Installation Manual
For Models:
• UltraUV Pro 15 Watt
(Item #130510)
• UltraUV Pro 25 Watt
(Item #130511)
15425 Chets Way | Armada, MI 48005
Pro
®
• UltraUV Pro 55 Watt
(Item #130512)
• UltraUV Pro 110 Watt
(Item #130513)
TM
EPA Est. No. 100154-GBR-1
1
V1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UltraUV Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ThePondguy UltraUV Pro

Summary of Contents for ThePondguy UltraUV Pro

  • Page 1: Table Of Contents

    UltraUV ® Pond UV Clarifier Installation Manual For Models: • UltraUV Pro 15 Watt • UltraUV Pro 55 Watt (Item #130510) (Item #130512) • UltraUV Pro 25 Watt • UltraUV Pro 110 Watt (Item #130511) (Item #130513) Table of Contents: Important Information .

  • Page 2: Important Safety Instructions

    PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USE. FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN EQUIPMENT DAMAGE OR FAILURE, LOSSES, INJURY OR DEATH. WARNING A leak-test must be performed before installing the bulb and plugging in the UltraUV Pro. Follow all installation instructions to avoid damage or failure. WARNING Risk of electric shock.
  • Page 3 • DO NOT place the UltraUV Pro near flammable or other dangerous materials or objects. • ALWAYS unplug the unit if there is no water running through it to prevent overheating. • The UltraUV Pro is NOT submersible; do not place the UltraUV Pro where it might contact or fall in the water.
  • Page 4 Keep sizes separate to avoid Smaller O-Ring incorrect installation. O-Ring Item Number: #130525 2 x Quartz Sleeve 2 x End Cap You will receive two Quartz Sleeve O-Rings O-Ring (H) O-Ring (F) and two End Cap O-Rings. thepondguy.com | 866-POND-HELP (766-3435)

  • Page 5: 55W Uv Diagrams And Parts List

    55W UV DIAGRAMS AND PARTS LIST: DESCRIPTION DIAGRAM ITEM NUMBER Gland Nut End Cap #130548 Bulb Socket UV Bulb #130519 (55W) Quartz Sleeve #130515 End Cap O-Ring #130525 Clear Locking Nut Quartz Sleeve O-Ring #130525 Transformer #130523 (55W) Mounting Bracket #130549 Inlet / Outlet #130547 Union...
  • Page 6 Keep sizes separate to avoid Smaller O-Ring incorrect installation. O-Ring Item Number: #130527 You will receive four Quartz Sleeve O-Rings 4 x Quartz Sleeve 4 x End Cap and four End Cap O-Rings. O-Ring (H) O-Ring (F) thepondguy.com | 866-POND-HELP (766-3435)

  • Page 7: Flow Rates

    Please note: For optimum performance we recommend that you pass the entire volume of your pond through the UltraUV Pro unit once every 2 to 3 hours. We do not recommend the use of pumps with operating pressures in excess of 36 PSI.

  • Page 8: Positioning And Mounting The Uv

    POSITIONING AND MOUNTING THE UV: POSITIONING THE UV: If you are going to position your UltraUV Pro outside or in an area where it is likely to get splashed regularly with water, then you must mount the unit horizontally. If your UltraUV Pro will be positioned in a permanently dry environment, then it can be installed in any position.

  • Page 9: Pump Fed Installation

    1½” or 2” Pipe 1½” or 2” Pipe POND Pump Raised 12” off ground We recommended installing a ball valve on either side of the UltraUV Pro for maintenance. See page 12 for ball valve installation. 15425 Chets Way | Armada, MI 48005...

  • Page 10: Gravity Fed Installation

    CONNECTION WITH FLEXIBLE TUBING (15W, 25W & 55W ONLY) The UltraUV Pro is supplied with two universal step down fittings to accept 1/2", 3/4", 1”, 1¼”, and 1½” diameter flexible tubing. Cut step down fittings to the largest connection that will work with your plumbing to ensure sufficient water flow.
  • Page 11 SCHEDULE 40 FLEX OR RIGID PVC: The UltraUV Pro is also supplied with the 2" Union x Slip fitting. 2" Schedule 40 Flex or Rigid PVC can be used up to 5,400 GPH. 3" Schedule 40 Flex or Rigid PVC should be used for any pumps rated over 5,400 GPH (Adapters for use with 1-1/2”...

  • Page 12: Installing A Ball Valve

    INSTALLING A BALL VALVE TO THE INLET AND OUTLET: Installing a ball valve on the inlet and outlet of the UltraUV Pro can make maintenance easier, especially if the unit is used on a gravity fed system (ball valves and adapters not included).

  • Page 13: Installing The Quartz Sleeve

    INSTALLING THE QUARTZ SLEEVE: NOTE: Gloves should be worn when handling and installing the quartz sleeve to prevent the transfer of any debris or oils from contact with the skin. Quartz Clear End Cap Sleeve Locking O-Ring (F) O-Ring (H) Bulb Socket (C) Nut (G) Gland...

  • Page 14: Water Testing

      bulb socket and transformer. Water ensure the seal holds before installing the damage from improper installation is bulb and connecting to the power supply. NOT covered under warranty.       thepondguy.com | 866-POND-HELP (766-3435)

  • Page 15: Connection To The Power Supply

    All electrical installations and wiring must be adequately protected to prevent any damage. The UltraUV Pro must be connected to a permanently installed receptacle. The unit should not be plugged into an extension cord, as this will void the manufacturer's warranty.

  • Page 16: Installing The Uv Bulb

    15. Turn the pump on first, then plug in the UV. The clear locking nuts serve as a bulb function indicator, as they allow light to pass through when the bulb illuminates. HAND TIGHTEN FITTINGS ONLY - DO NOT USE TOOLS thepondguy.com | 866-POND-HELP (766-3435)

  • Page 17: Uv Bulb Replacement

    It is not necessary to stop the water circulating through the UV to change the bulb; however, we recommend turning off the pump temporarily during replacement as a precaution. 1. Unplug the UltraUV Pro from the main power supply. 2. Loosen the gland nut slightly.

  • Page 18: Replacing / Cleaning The Quartz Sleeve

    5. Ensure all components are clean and free from dirt and debris. *Please note that replacement parts are not subject to a claim under warranty. The replacement parts listed on pages 4-6 are available on the www.thepondguy.com thepondguy.com | 866-POND-HELP (766-3435)

  • Page 19: Transformer Replacement

    TRANSFORMER REPLACEMENT: The UltraUV Pro transformer can be easily replaced in the event of any electrical issues. This comes complete with the transformer, bulb connectors, end caps and power cable. Refer to pages 4-6 for proper replacement transformer item numbers.

  • Page 20: Thermal Protection

    THERMAL PROTECTION: The UltraUV Pro pond clarifiers have thermal overload protection which automatically shuts down and then enables a fast re-start when the problem has been cleared. This may be the result of water in the end caps. Please see the troubleshooting section on page 21.

  • Page 21: Troubleshooting

    Contact The Pond Guy Technical Support. Replacement transformers include the transformer unit, wires and bulb connectors and can be purchased as a replacement part from The Pond Guy. Visit thepondguy.com for a complete list of UltraUV Pro replacement parts. 15425 Chets Way | Armada, MI 48005...

  • Page 22: Frequently Asked Questions

    HOW LONG AFTER I INSTALL THE UNIT WILL MY POND BECOME CLEAR? There are many factors which affect how long your UltraUV Pro will take to clear your pond, such as the levels of nutrients available to the algae, the water temperature and the level of sunlight.
  • Page 23 Ensure your pond filtration is removing fish waste and debris efficiently. Dirt in ponds will affect the efficiency of the UltraUV Pro. Check that your pond water volume is circulating through the UltraUV Pro every 2 to 3 hours.

  • Page 24: Warranty

    PRODUCT WARRANTY: UltraUV Pro Pond Clarifiers carry a 3-year warranty. The Pond Guy® will repair or replace any units found to be defective. This limited warranty is extended exclusively to the original purchaser and begins from the date of original purchase receipt. The UV bulb and quartz sleeve are wear items and are not covered by this warranty.

This manual is also suitable for:

130510130511130512130513
