AllClear™ G2 4500
Table of Contents:
Important Information. . . . . . . . . . . . . . . . . . . . . . . . 2
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Technical Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
How it Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing Your AllClear™ G2 Filter. . . . . . . . . . . . . 5-6
Maintaining Your AllClear™ G2 Filter . . . . . . . . . 7-11
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . 14-15
Warranty Information. . . . . . . . . . . . . . . . . . . . . . . . 16
AllClear
Pressurized Filters
Product Manual
AllClear™ G2 3500
G2 Series
™
For Models:
• AllClear™ G2 2000
(Item #130050)
• AllClear™ G2 3500
(Item #130051)
• AllClear™ G2 4500
(Item #130052)
AllClear™ G2 2000
TM
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ThePondguy AllClear G2 2000
Summary of Contents for ThePondguy AllClear G2 2000
-
Page 1: Table Of Contents
AllClear G2 Series ™ Pressurized Filters Product Manual For Models: • AllClear™ G2 2000 (Item #130050) • AllClear™ G2 3500 (Item #130051) • AllClear™ G2 4500 (Item #130052) AllClear™ G2 4500 AllClear™ G2 3500 AllClear™ G2 2000 Table of Contents: Important Information. -
Page 2: Important Information
• ALWAYS cap the backflush outlet when not in use to avoid unintended draining. IMPORTANT: The Pond Guy® is not responsible for equipment damage or failure, losses, injury or death resulting from failure to follow safety precautions, misuse or abuse of equipment. thepondguy.com | 866-POND-HELP (766-3435) -
Page 3: Package Contents
Package Contents ALLCLEAR G2 FILTER: ™ AllClear G2 Series ™ AllClear™ G2 Filter Fitting Kit Backflush Cap (may already be installed on backflush outlet) TECHNICAL SPECS: POWER MAX POND SIZE PLUMBING MODEL POWER MAX FLOW RATE CORD DIMENSIONS (GALLONS) SIZE LENGTH AllClear™... -
Page 4: How It Works
Finally, the water exits the filter and proceeds back into your pond or waterfall. Integrated 9 Watt, UV Clarifier Keeps water crystal clear Filter Media Pads Coarse pad catches large debris and fine pad catches small debris thepondguy.com | 866-POND-HELP (766-3435) - Page 5 Operating with a pump larger than AllClear™ G2 Filter in a protected area. recommended can reduce the filters Watch a video of the AllClear™ G2 Filter installation online @ www.thepondguy.com/allclearg2 Tools Required: • Shovel • Hacksaw • Flathead Screwdriver or Nut Driver...
-
Page 6: Installing Your Allclear G2 Filter
AllClear™ G2 UV Filter into a GFCI protected outlet. Protect Your Investment AllClear™ Rock Cover Camouflage and protect the AllClear™ G2 Filter from the outside elements use an AllClear™ Rock Cover. View online at thepondguy.com/allclearg2 thepondguy.com | 866-POND-HELP (766-3435) -
Page 7: Maintaining Your Allclear G2 Filter
MAINTAINING YOUR ALLCLEAR G2 FILTER: ™ CLEANING THE FILTER MEDIA Step 1 Unplug Unplug your pump and filter. Step 2 Connect a Discharge Hose Connect a discharge hose to the backflush outlet and turn the dial from filter to clean. Step 3 Plug the Pump In Plug the pump in and pull the handle on the top of the... - Page 8 Step 1 Remove Filter Top Slide the clamp on the filter to the open position and remove the filter top. Step 2 Remove Screws Remove the 2 screws holding the rods onto the filter media base. thepondguy.com | 866-POND-HELP (766-3435)
- Page 9 MAINTAINING YOUR ALLCLEAR G2 FILTER: ™ Step 3 Replace Media Pads Replace the media, keeping the pads in the same order as the ones you removed. Step 4 Place the Base Back Place the base back onto the filter media and secure to the rods with the 2 screws.
- Page 10 The quartz sleeve should be cleaned yearly or when water clarity is reduced. You may find the use of Pond Equipment Cleaner helpful for removing debris. If the quartz sleeve if it is scratched, damaged, or cracked, it must be replaced. thepondguy.com | 866-POND-HELP (766-3435)
- Page 11 MAINTAINING YOUR ALLCLEAR G2 FILTER: ™ Step 7 Reinstall Quartz Sleeve Reinstall the o-ring, quartz sleeve, compression nut and screw to lock into place. Step 8 Insert UV into Filter Insert the UV back into the filter top and secure with the 4 screws.
-
Page 12: Troubleshooting
• Verify that the proper amount of water is flowing through the filter. See recommendation for proper water flow on the Technical Specs chart. • Verify O-rings are seated correctly. • Verify filter canister has not been damaged. thepondguy.com | 866-POND-HELP (766-3435) - Page 13 NOTES: 15425 Chets Way | Armada, MI 48005...
-
Page 14: Replacement Parts
110306 110306 110306 Quartz Sleeve 130074 130074 130074 Operating Pieces 130090 130090 130090 Gasket Kit 130087 130087 130087 Screw Set 130091 130091 130091 Fitting Kit 130088 130088 130088 PVC Fitting Kit 130036 130036 130036 I(2x)/K(12x) K(12x) thepondguy.com | 866-POND-HELP (766-3435) - Page 15 REPLACEMENT PARTS: FILTER MEDIA/CANISTER DIAGRAM DESCRIPTION AllClear G2 2000 AllClear G2 3500 AllClear G2 4500 ™ ™ ™ Cleaning Rods/Mesh Tube 130092 130093 130094 Filter Pad Set 130055 130056 130057 Canister Clamp 130086 130086 130086 Filter Canister Clamp w/Filter Pads 130083 130084 130085...
-
Page 16: Warranty Information
Customer Care Department at 866-766-3435. Failure to request an RMA number may result in delay or dismissal of your warranty claim. THANK YOU FOR CHOOSING: The Pond Guy Inc. ® We Know Ponds ™ 15425 Chets Way Armada, MI 48005 866-POND-HELP (766-3435) thepondguy.com View other great products on-line at www.thepondguy.com...
