GENERAL
Type:
Direct-driven automatic signature
play turntable
Power supply source:
AC 11 OV/22OV/24OV, 50Hz (H/HB)
AC 11 OV/22OV/24OV, 50HzI60Hz
Power rating:
10 watts
Dimensions:
430 mm width
124 mm height (including dust cover)
370 mm depth
Weight:
6.5 kilograms, including dust cover
DRIVING SYSTEM
Motor:
DC-servo motor with frequency
generator
Speeds:
Wow and flutter:
0.04% (WRMS)
Rumble:
60 dB (DIN " B" )
30 cm die-cast aluminium,
Turntable:
MODEL
be restored to its original condition and only
parts identical to those specified be used.
Type:
Statically balanced tubular arm
Effective length:
2 1 5 m m
CARTRIDGE
Frequency response:
20 Hz - 20,000 Hz
o u t p u t :
3 milli volts
Channel separation:
2 0 d B
Tracking force:
2 grams (recommended)
Impedance:
47K ohms
Specifications are subject to change without prior notice.
Advertisement
Table of Contents
Related Manuals for Sharp RP-30H
Summary of Contents for Sharp RP-30H
- Page 1 MODEL be restored to its original condition and only parts identical to those specified be used. GENERAL Type: Direct-driven automatic signature Type: Statically balanced tubular arm play turntable Effective length: 2 1 5 m m Power supply source: AC 11 OV/22OV/24OV, 50Hz (H/HB) AC 11 OV/22OV/24OV, 50HzI60Hz CARTRIDGE Frequency response:...
-
Page 2: Layout Of Parts
Counterbalance Weight Tracking Force Gauge Anti-skating Weight Turntable and Mat Speed indicator Cartridge -Cueing/pause Control Button Cut-out Button Stroboscopic kpeed Indicator Speed Selector AC Supply Lead Figure 2-2... -
Page 3: Ac Mains Voltage
The unit is designed to operate from 1 IOV, 220V or 240V A.C. mains. Check the AC voltage level setting at rear of unit before plugging In supply lead. If necessary, adjust selector to cor- respond to the AC supply voltage of your area. If the AC lead is already plugged into an AC supply supply... - Page 4 REMOVAL OF BOTTOM PLATE (Refer to Figure 4-I) 1. Turn over the set after removing the turntable, but with the dust cover left as it is without fail. 2. Remove the 13 screws retaining the bottom plate, then it can be detached. Figure 4-l SETTING OF CARTRIDGE (Refer to Figure 4-2 and Figure 4-3)
- Page 5 (Refer to Figure 5-I) It may happen that the stylus tip doesn’ t leave the record surface when the cueing/pause control button is set at “ on” or it doesn’ t go down to the record when fhat button is set at “ off” . In this case, make the height of the stylus tip appropriate by changing the movable range (height) of the tonearm l e v e r .
- Page 6 Figure 6-1 3. Set the power switch to “ ON” position. ROTATIONAL SPEED ADJUSTMENT OF TURNTABLE 4. Push the cue/pause control button to raise the tonearm. DRIVE MOTOR Bring the tonearm from its rest to a position over the outer edge of record by hand.
- Page 7 DIRECT DRIVE MOTOR CONTROL CIRCUIT Consists of 72.pole magnet, multigap head having 36 pairs of yokes, and coils. The 20 Hz sine wave is generated when playing the LP record, and the 27 Hz sine wave when playing the EP record. 0.62 0.84 This circuit consists of a charging circuit which comprises...
- Page 8 0 . 1 3 9 0 O I L OR UPC4558 L - C H (Specifications or wiring diagrams ot this rnodel are subject to change for the ifi Figure 8 SCHE...
- Page 9 3 3 l/3 LED2 LED4 sure to replace tnem with parrs of specified part numoer.
- Page 10 PRINTED WIRING BOARD...
- Page 11 Figure 10 CABI...
- Page 12 0 CABINET EXPLODED VIEW...
-
Page 13: Replacement Parts List
R E P L A C E M E N T P A R T S L I S T “HOW TO ORDER REPLACEMENT PARTS” To have your order filled promptly and correctly, please furnish the following informations. 1. MODE NUMBER 2. -
Page 14: Parts List
P A R T S L I S T REF. REF. DESCRIPTION PART NO. PART NO. DESCRIPTION 19-E 33K ohm Weight, Anti-skating 912897706 Shaft, Tonearm Lever 390 ohm 912898639 Rod, Tonearm Lever 120 ohm 912897905 Spring, Tonearm Lever 390 ohm Spring, Shaft 912898494 Lever, Tonearm Lever Rod...
