  • Page 1 ICE MASTER H-SERIES ® OWNER’S MANUAL Product Code: IMH050 Version 1.3 Copyright © Enduraplas. All Rights Reserved.

  • Page 2: Table Of Contents

    English CONTENTS INTRODUCTION WARNINGS 4 - 7 GETTING STARTED 8 - 14 CALIBRATING 15 & 16 MAINTAINING 17 & 18 TROUBLESHOOTING 19 & 20 PARTS BREAKDOWNS 21 - 30 WARRANTY 31 - 33 Ice Master H-Series ®...

  • Page 3: Introduction

    English INTRODUCTION Congratulations! You now own a Camion™ sprayer. Durable design and construction assure you a lifetime of extreme performance. No sprayer is tougher. No sprayer will last longer. Take a look through this owner’s manual to learn how the pros use their Camion™...

  • Page 4: Warnings

    English WARNINGS 1. Do not exceed vehicle manufacturers loading, towing or lifting specifications and regulations. 2. Ensure tank is firmly secured in an appropriate manner. 3. Use caution at all times, particularly when driving on rough terrain. 4. Comply with chemical manufacturers safety requirements and all relevant legislations.
  • Page 5 English 13. No modifications and/or alterations may be made to this sprayer. Any such modifications not only void the sprayer warranty but can make the unit dangerous to anyone operating the pump. 14. Always inspect hoses and piping to avoid burst injuries. 15.
  • Page 6 English 23. Never leave the sprayer unattended without turning off the pump, relieving the line pressure, and flushing the sprayer of any harmful chemicals. 24. You must be in good mental health to operate this sprayer and not be under the influence of alcohol or any drugs that could impair your vision, physical strength, dexterity, judgement, or other mental capacity.
  • Page 7 English COMPATIBLE LIQUIDS Calcium Chloride Brine, Salt Brine and Premium Branded Liquids. Caution: Brine that contain tacky substances or solid particles may clog pumps and nozzles. These are not recommended. Warning: DO NOT USE any products that contain petroleum or petroleum by-products of any kind. These destroy seals and will void warranty.

  • Page 8: Getting Started

    English GETTING STARTED Setting Up Your Sprayer 1) Remove hose from under sprayer and coil up hose on the two brackets mounted on top of tank. 2) Connect the spray gun in the wand clips. 3) Remove mounting point pins from accessory box and install on the two sprayer mounting points.
  • Page 9 English GETTING STARTED Mounting Your Boom 1) Take the four 3/8” x 1-1/2” carriage bolts and feed them through the back of the boom and install the 3/8” SS flat washer then the 3/8” SS lock washer and loosely install 3/8” SS hex nut. 2) Slide boom down adjustable brackets, guiding the carriage bolts into the slots.
  • Page 10 English GETTING STARTED Hooking Up Sprayer 1) Back the tractor up to the sprayer aligning tractor hitch points with the arms at the height of the two lower mounting points. 2) Hook the two lower tractor hitch arms to the mounting point pins on sprayer, then secure with lock pin.

  • Page 11: Add On Options

    English GETTING STARTED Add On Options 1) If you ordered an optional hose reel with your unit, take hose reel from under the sprayer and set on top of tank opposite to lid end. 2) Secure hose reel frame to tank with provided hardware.
  • Page 12 English GETTING STARTED Add On Options 1) If you purchased an optional receiver hitch mount, unpackage hitch and provided pins. 2) Take 3/4” x 4-1/4” quick connecting gold pins and insert into two lower mounting points connecting receiver hitch to unit. 3) Then, take 7/8”...
  • Page 13 English GETTING STARTED Add On Options 5) Align holes on hitch and receiver and install lock pin. Version 1.3...
  • Page 14 English GETTING STARTED Operating Your Sprayer 1) Take tank lid off and fill tank at least a quarter full with water, enough to run through the system to check all components are functioning correctly and are leak free. 2) Ensure the inline valve between tank and pump is in open position (parallel to hose) to allow the liquid to flow from the tank to the pump.

  • Page 15: Calibrating 15

    English CALIBRATING Note: Always double check your application rates. The rate/acre listed is only based off the center section (not the two side nozzles) Version 1.3...
  • Page 16 English GPM = Gallons Per Minute GPA = Gallons Per Acre GAL/1000 FT = Gallons Per 1000 Square Feet W = Nozzle spacing Gallons Per Minute Formula: GPA x MPH x W (per nozzle) 5,940 Gallons Per Minute Formula: GAL/1000FT x MPH x W (per nozzle) Gallons Per Acre Formula: 5,940 x GPM (per nozzle) MPH x W...

  • Page 17: Maintaining 17

    English MAINTAINING Keeping your sprayer in good condition will help you lengthen the life of the sprayer. Everyone knows a well maintained piece of equipment ensures a longer life span. Sprayer maintenance can seem a huge task if you don’t have the right tools.
  • Page 18 English If required If damaged Every 250 operating hours o once a year After the first 5 operating hours Weekly or every 40 operating hours At the end of work and/or daily Before starting work Ice Master H-Series ®...

  • Page 19: Troubleshooting 19

    English TROUBLESHOOTING CONDITION CAUSE REMEDY Pump will not 1) Air leak on suction 1) Tighten/replace prime plumbing fittings & hose 2) Blocked/Restricted clamps. Verify suction intake hose hoses are in good 3) Filter cap condition disengaged 2) Remove blockage 4) Filter gasket from suction line, damaged/missing ensure line is not...
  • Page 20 English CONDITION CAUSE REMEDY Pressure gauge 1) Plugged with debris 1) Un-thread, check not registering and clean pressure gauge Hand gun loses 1) Debris in hose or 1) Un-thread nozzle pressure nozzle tip and clean 2) Pump losing prime 2) See Remedy for 3) Pump pressure ‘Pump will not prime dropping/fluctuating...

  • Page 21: Parts Breakdowns

    OVERVIEW CPA0100 Optional VIEW A VIEW B VIEW C IMB7-H IMHMB01 Optional Version 1.3...
  • Page 22 DETAIL VIEW A VIEW A VIEW A VIEW B DETAIL VIEW B VIEW B Ice Master H-Series ®...
  • Page 23 DETAIL VIEW C VIEW C Version 1.3...

  • Page 24: Parts List

    PARTS LIST ITEM NO. PART # DESCRIPTION QTY. CA3511221 8 inch lid CPSB01 10MM Site Glass Ball Level Indicator CHAS050723 1/2" x 1-1/2" Stainless Hex Bolt All Thread CHNSN0533 1/2" Nylock Nut 304 SS CHBS030523 3-8" x 1" SS Hex Bolt CHNSN0323 3/8"...
  • Page 25 PARTS LIST ITEM NO. PART # DESCRIPTION QTY. CFCC003 Clamp for 1/2" Hose CHWSF013 1/4" SS Flat Washer CHBS010723 1/4 X 1-1/2 SS Bolt CHNSN0123 1/4" Stainless Lock Nut CFCW001 Clamp For 3/4" Hose CLUVGC02502 Site gauge hose CEWCIM01 Ice Master Wire Harness CTEW029 Butt Connector Crimp CNST013...
  • Page 26 IMB7 - H NOZZLE BOOM IMSB7H - 7 NOZZLE BOOM FOR 3-POINT, 55 GAL. Ice Master H-Series ®...
  • Page 27 OVERVIEW Version 1.3...
  • Page 28 PARTS LIST ITEM NO. Part # DESCRIPTION QTY. AZFPM005 IMS4-6 Stainless boom bracket AZFPM020 1" x 17-3/4" Poly Pipe For Deicing Boom AZFPM022 1" x 14-13/16" Poly Pipe For Deicing Boom AZFPM021 1" x 6-1/4" Poly Pipe For Deicing Boom CBCR100 1"...
  • Page 29 DETAIL VIEW HOSE REEL ITEM NO. PART # DESCRIPTION QTY. AMAH01GY HR030/050 REEL ONLY CFCC003 Clamp for 1/2" Hose CPLF01 Heavy Duty Spray Gun STAL16-viton seals CFRB06 1/4-3/8 BSP FEMALE ELBOW CFRB07 STAINLESS PIPE 3/8 THREAD BOTH ENDS CFRB08 3/8 X 1/4 BALL BEARING SWIVEL CFRB09 1/4 MALE THREAD X 1/2 HOSE BARB CFRH03C...
  • Page 30 IMHMB01 - HITCH ITEM NO. Part # DESCRIPTION QTY. AZKI009SS Bracket for Tail Gate Mount Sprayer Stainless Steel CHCS0920618 Steel Hitch Pin, 7/8" Dia x 4-1/4" Usable Length CV712HP .75 IN x 4.25 IN snap Lock Hitch Pin IMHMB01 Ice Master H-Series ®...

  • Page 31: Warranty

    Buyer of Camion ® Products that it will be free from defects in workmanship for a period of one (1) Year after the date of the original purchase. At it’s sole option, Camion ® will repair or replace defective parts at no charge for parts and labor.
  • Page 32 (10) days that the defect becomes known, in writing, at: cs@camionsystems.com. The original invoice or other similar proof of purchase of the applicable product or part must be provided by the Buyer to Camion ®...

  • Page 33: How To Activate

    English ACTIVATE YOUR 10-YEAR WARRANTY How to Activate To double your 5-year tank warranty, visit www.camionsystems.com/warranty/ and register this product. Watch Instruction Videos: www.youtube.com Discover More Helpful Tips: www.IceControlTraining.com Version 1.3...
