Summary of Contents for CAMION ICE MASTER U Series
- Page 1 ICE MASTER U-SERIES ® OWNER’S MANUAL Product Codes: IMU100 Version 1.7 Copyright © Enduraplas. All Rights Reserved.
-
Page 2: Table Of Contents
English CONTENTS INTRODUCTION WARNINGS 4 - 5 GETTING STARTED 6 - 10 CALIBRATING 11 & 12 MAINTAINING 13 & 14 TROUBLESHOOTING 15 & 16 PARTS BREAKDOWNS 17 - 25 WARRANTY 26 - 30 Ice Master U-Series ®... -
Page 3: Introduction
English INTRODUCTION Congratulations! You now own an Camion™ sprayer. Durable design and construction assure you a lifetime of extreme performance. No sprayer is tougher. No sprayer will last longer. Take a look through this owner’s manual to learn how the pros use their Camion™... -
Page 4: Warnings
English WARNINGS 1. Do not exceed vehicle manufacturers loading, towing or lifting specifications and regulations. 2. Ensure tank is firmly secured in an appropriate manner. 3. Use caution at all times, particularly when driving on rough terrain. 4. Comply with chemical manufacturers safety requirements and all relevant legislations. - Page 5 English 13. No modifications and/or alterations may be made to this sprayer. Any such modifications not only void the sprayer warranty but can make the unit dangerous to anyone operating the pump. 14. Always inspect hoses and piping to avoid burst injuries. 15.
-
Page 6: Getting Started
English GETTING STARTED Installing the Mounting System 1) If you wish to use the d-ring tie-down system, select your desired mounting points on each side of the frame 2) Install 2 d-ring tie-downs on each side of the frame using the supplied nuts and bolts. - Page 7 English GETTING STARTED Setting Up & Operating Sprayer 1) Route the cable to your vehicle battery and connect the battery clips to the battery. 2) Take tank lid off and fill tank at least 1/4 full with water, enough to run through the system to check all components are functioning correctly.
- Page 8 English GETTING STARTED Setting Up & Operating Sprayer 5) Turn on pump switch and run clean water through the entire unit before using salt brine to check for any unexpected leaks caused in shipping. 6) Unit is ready for use. Fill with desired liquid.
- Page 9 English GETTING STARTED Draining & Winterizing 1) Completely drain liquid out of tank through the drain port on back of unit (in a safe environment) and close the drain valve when empty. 2) Fill the tank 1/4 with fresh water and run pump to recirculate through system for approximately 2 minutes.
- Page 10 English GETTING STARTED Draining & Winterizing 5) Your applicator should now be safe to store in a dry protected area. Ice Master U-Series ®...
-
Page 11: Calibrating 11
English CALIBRATING Note: Always double check your application rates. Version 1.7... - Page 12 English GPM = Gallons Per Minute GPA = Gallons Per Acre GAL/1000 FT = Gallons Per 1000 Square Feet W = Nozzle spacing Gallons Per Minute Formula: GPA x MPH x W (per nozzle) 5,940 Gallons Per Minute Formula: GAL/1000FT x MPH x W (per nozzle) Gallons Per Acre Formula: 5,940 x GPM (per nozzle) MPH x W...
-
Page 13: Maintaining 13
English MAINTAINING Keeping your sprayer in good condition will help you lengthen the life of the sprayer. Everyone knows a well maintained piece of equipment ensures a longer life span. Sprayer maintenance can seem a huge task if you don’t have the right tools. - Page 14 English If required If damaged Every 250 operating hours o once a year After the first 5 operating hours Weekly or every 40 operating hours At the end of work and/or daily Before starting work Ice Master U-Series ®...
-
Page 15: Troubleshooting 15
English TROUBLESHOOTING CONDITION CAUSE REMEDY Pump will not 1) Air leak on suction 1) Tighten/replace prime plumbing fittings & hose 2) Blocked/Restricted clamps. Verify suction intake hose hoses are in good 3) Filter cap condition disengaged 2) Remove blockage 4) Filter gasket from suction line, damaged/missing ensure line is not... - Page 16 English CONDITION CAUSE REMEDY Pressure gauge 1) Plugged with debris 1) Un-thread, check not registering and clean pressure gauge Hand gun loses 1) Debris in hose or 1) Un-thread nozzle pressure nozzle tip and clean 2) Pump losing prime 2) See Remedy for 3) Pump pressure ‘Pump will not prime dropping/fluctuating...
-
Page 17: Parts Breakdowns
English OVERVIEW Deicing Hose Reel Detail Detail View A Detail View C Detail View B Version 1.7... - Page 18 English DETAIL VIEW A Detail A Ice Master U-Series ®...
- Page 19 English DETAIL VIEW B Detail B Version 1.7...
- Page 20 English DETAIL VIEW C Detail C Ice Master U-Series ®...
- Page 21 English PARTS LIST ITEM NO. PART # DESCRIPTION QTY. AZFB060BSS Base Only for 60 100 Gal SS AZFB060DSS D Ring Stainless Steel AMTHSFB100OE 100 Gallon FB tank AVB195 Baffle Ball For 8"lid tanks CA3511221 8 inch lid AZKB0005SS 23.75" Stainless Steel Adj. Boom Bracket CPFG10 5/8 Top hat grommet CPFG15...
- Page 22 English PARTS LIST ITEM NO. PART # DESCRIPTION QTY. CLUESB020002 1/2" hose from inline strainer to pump CLUESB020004 .75 hose from Tank to Tee CLUESB020004 .75 Hose Return to Tank CV3EL12HB 1/2 X 1/2 hose barb 90 degree CLUVGC02502 1/2" Site Glass Hose FG 100 CPSB01 10MM Site Glass Ball Level Indicator CHBZ010225...
- Page 23 English DETAIL VIEW HOSE REEL ITEM NO. PART # DESCRIPTION QTY. AMAH01GY HR030/050 REEL ONLY CFCC003 Clamp for 1/2" Hose CPLF01 Heavy Duty Spray Gun STAL16-viton seals CFRB06 1/4-3/8 BSP FEMALE ELBOW CFRB07 STAINLESS PIPE 3/8 THREAD BOTH ENDS CFRB08 3/8 X 1/4 BALL BEARING SWIVEL CFRB09 1/4 MALE THREAD X 1/2 HOSE BARB...
- Page 24 English OVERVIEW Ice Master U-Series ®...
- Page 25 English PARTS LIST ITEM NO. Part # DESCRIPTION QTY. AZFPM005 IMS4-6 Stainless boom bracket AZFPM020 1" x 17-3/4" Poly Pipe For Deicing Boom AZFPM022 1" x 14-13/16" Poly Pipe For Deicing Boom AZFPM021 1" x 6-1/4" Poly Pipe For Deicing Boom CBCR100 1"...
-
Page 26: Warranty
English WARRANTY • • • • • • • • Ice Master U-Series ®... - Page 27 English WARRANTY Version 1.7...
- Page 28 English ACTIVATE YOUR 2-WINTER WARRANTY How to Activate To double your 5-year tank warranty, visit www.camionsystems.com/warranty/ and register this product. Watch Instruction Videos: www.youtube.com Discover More Helpful Tips: blog.enduraplas.com/ice-control Ice Master U-Series ®...
- Page 29 English Watch Instruction Videos: www.youtube.com Discover More Helpful Tips: blog.enduraplas.com/ice-control Version 1.7...
- Page 30 CAMION ® by Enduraplas 1 (877) 265-9929 cs@camionsystems.com www.camionsystems.com 113 1st Street, Neche ND 58265, USA Discover More Helpful Tips: blog.enduraplas.com/ice-control Copyright © Enduraplas. All Rights Reserved.
