Control Panel - Boss Audio Systems Elite BE7ACP.WX User Manual

Basic Operation

Control Panel

1
2
3
4
5
6
7
1 Power/Mute button
• Press to power on the unit.
• Press and hold to power off the unit.
• When powered on, press to mute or restore
the volume.
2
Home button
• Press to switch between the home menu
and the last selected source.
• When powered on, press and hold to turn
the screen off.
3 Volume up button
4 Voice assistant (Push-To-Talk)
Press to activate voice assistant.
Enable Apple CarPlay, Android Auto or
Bluetooth connection to use voice assistant.
5 Volume down button
6
Reset button
Use a needle or pin to press the button. Reset
the unit if the unit fails to function normally.
7 USB-C port (1.5A charging port)
Media audio, video or picture input from a
USB flash drive.
If needed, use a USB-C adapter (not included)
to fit your USB flash drive into the USB-C port.
TIP:
When the unit is powered off, touch the screen
to turn on or off time/date display.
7
