BE950WCPA
USER'S MANUAL
WIRELESS Apple CarPlay & Android Auto™
BLUETOOTH® | 320 WATTS | IN-DASH DOUBLE-DIN
FEATURING . "
mm CAPACITIVE TOUCHSCREEN
Advertisement
Table of Contents
Related Manuals for Boss Audio Systems Elite BE950WCPA
Summary of Contents for Boss Audio Systems Elite BE950WCPA
- Page 1 0920 iPhone® is a trademark of Apple Inc., registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc. BOSS Audio Systems is not a iliated with Apple Inc. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by BOSS Audio Systems is under license.
-
Page 3: Table Of Contents
Contents Contents............2-3 Android Auto..........17 Radio.............. 23 Notes..............4 Warnings............17 Tuning............23 FCC Statement..........5 Using Android Auto........17-18 Bands............. 23 Cautions............6-8 Bluetooth®............. 19 RBDS...............23 About this Manual........... 8 Setup & Connections........1 9 Aux-In.............24 California Prop. 65........... 8 Phone book........... 1 9 Playback............ -
Page 4: Contents
Contents Volume............25 Bluetooth® Settings........27 Source Level...........25 Bluetooth Device........... 27 Audio Effect........... 25 Apple CarPlay Device........27 Balance Fader..........26 Bluetooth Setting........... 27 General Settings..........26 Bluetooth Power..........27 Date & Time........... 26 Auto Connect..........27 Android Auto..........26 Auto Answer..........27 Camera Settings.......... -
Page 5: Notes
SIG, Inc. and any use of such marks by instructions/procedures. Failure to observe the Boss Audio Systems is under license. instructions/procedures can result in Other trademarks and trade names are those injury or damage to the product and or property. -
Page 6: Fcc Statement
Caution FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. - Page 7 Using this product in this condition may result in permanent damage to the system. InstallationPrecautions Boss Audio Systems does not recommend to install the product yourself. We recommend to have it professionally installed by a certified professional. Always consult with a professional installer .
- Page 8 Caution Before Installing To avoid potential shorts in the electrical system, be sure to disconnect the (–) battery cable before installation. Use this unit with a 12-volt battery and negative grounding only. Failure to do so may result in a fire or malfunction. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN...
-
Page 9: About This Manual
Caution Images and Video Watching video while driving is against Federal, State, and Local laws. Drive safely, know and obey traffic rules. Watching this screen and making selections while driving can lead to a serious accident. Check surroundings for safety while camera images are displayed. Do not use features of this product while driving if it cannot be operated safely and legally in your location. -
Page 10: Basic Product Operation
Basic Product Operation Control Details Microphone Power/Home Voice Recognition Volume Control Mute/Screen Off... - Page 11 Basic Product Operation Rear Details Apple CarPlay & Android Auto (2 A Charging) Power / Speaker *Lightning Cable Not Included Harness Steering Wheel Control Radio Antenna Input Input 15 Amp Mini-ATM Fuse GPS Antenna Input I/O Ports Camera Input Hands-free Camera Power Output Microphone Aux-Audio...
-
Page 12: Product Basics
Basic Product Operation Power On /Standby Product Basics 1. Touch once to Power ON Power On /Standby 2. Touch and Hold for Standby 1. Touch once to Power ON NOTE Apple CarPly or Android Auto must 2. Touch and Hold for Standby be active NOTE In Standby Mode, the LED will slowly... -
Page 13: Using/Caring For The Touchscreen
Basic Product Operation Using and Caring for the Touch Screen Use: This head unit utilizes a Capacitive Touchscreen, the same type that is used on high-end mobile devices. It should be used for and cared for like that type of device. -
Page 14: Product Setup
Basic Product Operation Product Setup (Date & Time) Setup Option B: Date and Time Additional Setup see pg. 27 Setup Option A: Apple CarPlay Method Connect your Apple ® device using a Light- ning® cable*. The CarPlay USB port mustbe General >... -
Page 15: Navigating The Menus
Basic Product Operation Basic Operation Navigating the Menus Streaming Radio Phone Media Front and Rear camera Settings Android Auto Apple CarPlay... -
Page 16: Apple Carplay
Apple CarPlay Using Apple CarPlay When using CarPlay, there is no need to pair 2. The iPhone will load the CarPlay your iPhone, the USB cable connected through function. NOTE the USB Port will enable this feature. 3. On the display, the CarPlay will If other devices are connected via Bluetooth, Apple CarPlay usage is limited while driving. -
Page 17: Apple Carplay Display
Wired and wireless Apple CarPlay Using CarPlay How to Disable Apps NOTE CarPlay Display Setup Using your iPhone: Only Apps with the icon can be 1. Using your iPhone: Settings >Screen time > Content & Privacy Restrictions removed from CarPlay. 2. -
Page 18: Android Auto
Wired and wireless Android Auto Using Android Auto Connecting to USB Port NOTE WARNING Connect the Android compatibledevice Android Auto usage is limited while driving. For your safety, the setup process must be via the appropriate USB cable Functions, contents, and usability is accomplished while the vehicle is parked and (not included). - Page 19 Android Auto Using Android Auto Android Auto Permissions Permissions Several features can be allowed or denied access to customize your usability of the product. The access can always be modified in Settings on the Android device.
-
Page 20: Bluetooth
Bluetooth® Setup & Connection Phone Menu First time Pairing NOTE Navigate to the Hands-free menu (pg. 19) Touch search to begin searching for devices Once paired and connected, the device list will Touch display the available Bluetooth profiles. Mobile Device: Search for Boss Audio BE950WCPA_XXXX iOS Devices: Settings >... -
Page 21: Calling
Bluetooth® PHONE Calling History Call Waiting Outgoing To accept another call: Making & Receiving Calls Call 1. Dialing from the dial pad Incoming Touch Call To toggle between calls: 2. History Touch to makecall Call 2 Touch Call 1 3. Contacts Missed Call Private Mode... -
Page 22: Audio
Bluetooth® Audio Audio Streaming Media Player (Bluetooth) Video cannot be viewed on the unit. To play media through Bluetooth, the mobile Playback access is also available through the Display device must be Paired and Connected to the Media Player BE950WCPA_XXXX, see pg. 20. Track info will be displayed when available. -
Page 23: Media
Media USB Playback Navigating Menu WARNING Watching videos or photos while driving is Touch against Federal ,State, and Local laws. Touch Do not use features of this product if it cannot be operated safely and legally in your location. The music will play automatically. browse contents Swipe NOTE Audio &... -
Page 24: Radio
Tuner FM/ AM Controls Return Touch To return to the main interface Touch Tuning Band Search < > Touch and Hold Swipe to quickly tune To search for station Auto Search NOTE To change radio EQ To touch RBDS info (if available) and currently tuned Station will display on the radio icon in the For all EQs，... -
Page 25: Aux-In
AUX IN/CAMERA External Source Reverse View Playback (Audio Only) WARNING When the vehicle is put into reverse gear, the Never rely solely on the rear view camera; camera will display the image on the screen. always check your surroundings before Touch proceeding. -
Page 26: System Tone
Settings Audio System Tone Balance/Fader Touch < > To adjust the EQ bands < > , Touch Left/Right Balance Touch Default Setting: OFF Volume Swipe for quick adjustment Loud Settings are for default volumes for Hands- free. Media Player is a global setting for media. Enhances and gently boosts low and high freq. -
Page 27: General Settings
Settings General Date & Time Touch Radio off after 1min Time Zone Delay 1minute ACC OFF Touch Camera Settings Adjust to correctly display time Default Setting: (GMT-05:00) Eastern Time (US) Camera Trigger Default Setting: OFF Trigger the front or rear camera or close Retain ACC Power Date <... -
Page 28: Display Settings
Settings Illumination Device Day Brightness LED Animation < > Bluetooth Setting Touch Touch Bluetooth Power Touch Will cycle through all colors on LED Adjust day mode brightness value touch buttons. Default Setting: ON Night Brightness Power On/Off Bluetooth < > LED Color Default Setting: ON Touch... -
Page 29: Auto Download Phone Book
Settings Device Radio Seek Quality FM/AM RBDS Auto Download RBDS stations will broadcast information to Phone Book Touch Touch display AF (Alternative Frequency) Automatically downloads phone Adjust the sensitivity of both AM/FM bands book Touch Default Setting: OFF Reset Touch Manual Download Phone book Touch When On, the tuner will automatically locate... -
Page 30: About Settings
Settings About Displays the system information: Hardware Version Software Version Bluetooth Version BT MAC Serial Number USB NCM MAC NOTE Software version information depends on the software used for production... -
Page 31: Troubleshooting
Troubleshooting Cause Solution Issues No Sound Internal amplifier is off Go to Settings > Audio Product is muted Touch the volume. External amplifiers Check the external amplifiers are on. Audio source Change the audio source Media Not Supported Media on USB flash drive Change the media format on the USB device Change the USB device Bad Radio Reception... - Page 32 Microphone needs to be firmly attached to location it’s mounted on. Check to see if microphone is properly plugged in. If you have questions about this product: Customer Service 805-751-4853 M-F 8:30a-5:00p (PST) Tech Support:www.bossaudio.com/support/technical-support BE950WCPA © 2020 Boss Audio Systems...
-
Page 33: Specifications
Specifications General Audio Android Auto Power Input......10.8 V—16 V DC Pre-amp Output........3 Pairs Supported....(8.0) Lollipop or Newer Nominal......14.4 V DC Front......2V, Full-Range Current Consumption......10 A (Max) Rear......2V, Full-Range USB Spec......USB 2.0 (High-Speed) Fuse Type.........15 A, Mini-ATM Sub (Mono)......
