SERVICE
SCHEMATICS
AT END OF
MANUAL
American TV standards
Television system
Channel coverage
VHF: 2-13
UHF: 14-69
Cable TV: 1-125
Microblack Trinitron tube
Picture tube
27-inch picture measured
28-inch picure tube measured
Input
VIDEO INPUT 1, 2 and 3 (phono
jacks)
Output
MONITOR OUTPUT (phono jacks)
AUDIO OUTPUT (VARIABLE) (phono
jacks)
SPECI Fl CATIONS
diagonally
diagonally
Video: 1 Vp-p, 75-ohms
unbalanced, sync negative
Audio: 408 mVrms (100%
modulation, 47 kilohms)
Video: 1 Vp-p, 75-ohms
unbalanced, sync negative
Audio: 408 mVrms (100%
less than 10 kilohms)
More than· 408 mVrms at the
maximum volume setting (variable )
(100% modulation, less than
1 O kilohms)
Canadian Model
Note: The service manual for RM-745 has been
issued separately.
Power requirements 120 V AC, 60 Hz
Power consumption 170W (max.)
1W (in standby condition)
Accessories supplied
Remote Commander RM-745
with 2 size AA batteries
Antenna connector
Optional accessories
U/V mixer EAC-66
Connecting cord VMC-1P3
Design and specifications subject to change without
notice.
INITRON@ COLOR TY
us
Model
Chassis No. SCC-A61A-A
Chassis No. SCC-A668-A
PX
Model
Chassis No. SCC-A05D-A
HASSIS
RK-74A
