Sealey SGE115 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND
CAUTIONS. USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO
MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. RETAIN INSTRUCTIONS FOR FUTURE USE.
1. SAFETY INSTRUCTIONS
1.1. ELECTRICAL SAFETY p WARNING! It is the user’s responsibility to read, understand and comply with the following:
You must check all electrical equipment and appliances to ensure they are safe before using. You must inspect power supply leads, plugs and
all electrical connections for wear and damage. You must ensure the risk of electric shock is minimised by the installation of appropriate safety
devices. An RCCB (Residual Current Circuit Breaker) should be incorporated in the main distribution board. We also recommend that an RCD
(Residual Current Device) is used with all electrical products. It is particularly important to use an RCD together with portable products that are
plugged into an electrical supply not protected by an RCCB. If in doubt consult a qualified electrician. You may obtain a Residual Current Device
by contacting your Sealey dealer. You must also read and understand the following instructions concerning electrical safety.
1.1.1. The Electricity At Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by
a qualified electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance
and the safety of the appliance operator. If in doubt about electrical safety, contact a qualified electrician.
1.1.3. Ensure the insulation on all cables and the product itself is safe before connecting to the mains power
supply. See 1.1.1. & 1.1.2. above and use a Portable Appliance Tester (PAT).
1.1.4. Ensure that cables are always protected against short circuit and overload.
1.1.5. Regularly inspect power supply, leads, plugs and all electrical connections for wear and damage,
especially power connections, to ensure that none is loose.
1.1.6. Important: Ensure the voltage marked on the product is the same as the electrical power supply
to be used and check that plugs are fitted with the correct capacity fuse. A 13 amp plug may require
a fuse smaller than 13 amps for certain products, see fuse rating at right.
1.1.7. DO NOT pull or carry the powered appliance by its power supply lead.
1.1.8. DO NOT pull power plugs from sockets by the power cable.
1.1.9. DO NOT use worn or damage leads, plugs or connections. Immediately replace or have repaired by
a qualified electrician. A U.K. 3 pin plug with ASTA/BS approval is fitted. In case of damage, cut off
and fit a new plug according to the following instructions (discard old plug safely).
(UK only - see diagram at right). Ensure the unit is correctly earthed via a three-pin plug.
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires have been correctly connected, that the cable outer
insulation extends beyond the cable restraint and that the restraint is tight.
Double insulated products are fitted with live (BROWN) and neutral (BLUE) wires only. Double insulated products are always marked with
this symbol . To re-wire, connect the brown & blue wires as indicated above. DO NOT connect the brown or blue to the earth terminal.
1.1.10. Cable extension reels. When a cable extension reel is used it should be fully unwound before connection. A cable reel with an RCD
fitted is recommended since any product which is plugged into the cable reel will be protected. The section of the cores of the cable
is important and should be at least 1.5mm
for others that may be used in the other output sockets, we recommend the use of 2.5mm
1.2. GENERAL SAFETY
Disconnect the grinder from the mains power before changing accessories, servicing or performing any maintenance.
Maintain grinder and discs in good condition. Check moving parts and alignment. If necessary use an authorised service agent.
3
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
3
WARNING! Always work with the grinder safety guard in place.
3
Wear approved safety goggles, ear defenders, gloves and, if grinder generates dust, dust mask.
p
The grinding wheel or disc must only be changed by persons holding an appropriate grinding wheel certificate.
3
Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain long hair.
3
Use grinder in a suitable work area. Keep area clean, tidy and free from unrelated materials and ensure adequate lighting.
3
Maintain correct balance and footing, DO NOT over-reach. Ensure the floor is not slippery and wear non-slip shoes.
3
Use only approved grinding discs and only use the normal grinding surface. Never use the side or upper surface of disc for cutting.
3
Check grinding disc to ensure there are no splits, cracks or other damage (see Section 4). If in doubt do not use the disc.
3
Grinding discs must be securely attached before use, but not over-tightened.
3
Secure unstable workpiece with a clamp, vice or other adequate holding device and ensure the grinder is gripped with both hands.
3
Keep non-essential persons away from the working area, use screens if necessary.
3
DO NOT operate the grinder if any parts are missing or the grinder is damaged.
3
DO NOT use the grinder for a task it is not designed to perform.
7
DO NOT operate the grinder where there are flammable solids, liquids or gasses.
7
WARNING! DO NOT grind any materials containing asbestos.
7
DO NOT get the grinder wet or use in damp or wet locations.
p
DO NOT switch the grinder on whilst the disc is in contact with the workpiece.
7
DO NOT cover the grinder air vents. To do so will overheat the machine.
7
DO NOT touch the workpiece immediately after grinding, it will be very hot.
7
DO NOT use the grinder as a fixed tool and DO NOT try to cool the grinding discs with water of other lubricants.
7
DO NOT hold unsecured work in your hand and DO NOT touch the grinding disc whilst operating, or whilst plugged into the mains power.
7
DO NOT leave the grinder running unattended, and DO NOT lay the grinder down whilst it is running.
7
DO NOT operate the grinder when you are tired or under the influence of alcohol, drugs or intoxicating medication.
7
When not in use switch off grinder, remove plug from power supply and store in safe, dry, childproof area.
7
3
INSTRUCTIONS FOR:
800W 4.5” H. D. ANGLE GRINDER
Model:
, but to be absolutely sure that the capacity of the cable reel is suitable for this product and
2
SGE115
Yellow & Green
Earth Wire
Blue
Neutral
Wire
FUSE RATING
section cable.
2
Brown
Live
Wire
Cable
Restraint
5 AMP
SGE115 - 2 - 011001
