Linortek Netbell-KB-E2M Wiring Instructions

1. Netbell-KB-E2M Packing List
____ Netbell-KB-M2 Server (01-910-00037) (1)
____ 20FT RJ45 Cable (01-390-00028) (1)
____ 3M Power Cables (01-850-00029) (1)
____ 3M Bell Cables (01-850-00046) (2)
Wago Connector (01-350-00129) (2)
____ External Buzzer Kits (01-910-00040) (2)
____ 24VAC Power Supply (01-850-00024) (1)
____ Mounting Brackets (1)
____ Buzzer Volume Adjustment Kit (1)
____ Netbell Setting Instructions
____ Packing Lists and Wiring Instructions
____ Buzzer Manual
Safety Instructions
•
If the device is not powered via an Ethernet cable, use only the power adapter provided by Linortek that comes with your
order. Other power supplies may damage or destroy the device, affect its behavior, or induce noise.
•
Avoid placing the cables where people may trip over them or where they may be exposed to mechanical pressure as this
may damage them.
•
Do NOT install the device in rooms with high humidity. Do NOT immerse the device in water and do NOT spill or pour
liquids of any kind onto or into the device.
•
Do NOT install the device in surroundings at risk for explosions. Do NOT use the device if you smell gas or other potentially
explosive fumes.
•
Do NOT use the device during thunderstorms. Lightning striking the power grid may cause electric shocks.
•
Do NOT remove the device's power supply (Ethernet cable when using PoE, power adapter when not using PoE) when the
RED LED is blinking and the GREEN LED is on (called Bootload state); a firmware update is ongoing. Cutting off the device's
power during a firmware update (red LED blinking, green LED on) will damage the firmware and render the SERVER
inoperative. In such cases, it will need to be returned to factory for resetting.
Packing List and Wiring Instructions
