DOMESTIC GAS WATER HEATER
Thank you for choosing Rinnai
●
Please read this manual carefully &
install it as specified.
●
Be sure to ask licenced professional to
perform installation.
Instruction Manual
Model Name
REU-1215W-RS
REU-2024W-RS
Contents
Components & Parts.................................1
Remote Controller....................................2
First Time Use .........................................3
How To Use .............................................4
Safety Notes...........................................11
Installation ..............................................13
Remote Controller Installation ................18
Trouble Shooting....................................24
Error Messages......................................25
Inspection & Maintenance .....................26
Page
Advertisement
Table of Contents
Related Manuals for Rinnai REU-1215W-RS
Summary of Contents for Rinnai REU-1215W-RS
-
Page 1: Table Of Contents
How To Use ..........4 Safety Notes...........11 Installation ..........13 Remote Controller Installation ....18 Trouble Shooting........24 Error Messages........25 Thank you for choosing Rinnai Inspection & Maintenance .....26 ● Please read this manual carefully & install it as specified. Dimensions & Product Specification..28 ●... -
Page 2: Components & Parts
COMPONENTS & PARTS After unpacking the appliance check for damage, if the heater is damaged or appears to have any defects contact your supplier immediately. DO NOT install a damaged appliance before checking with your supplier. Remove the accessories pack and the heater from the carton and check that all the parts are included. -
Page 3: Remote Controller
REMOTE CONTROLLER Remote controllers can be used in following combination. (3 controllers can be installed maximum) 1x main remote controller 1x main remote controller + 1x sub remote controller 1x main remote controller + 2x sub remote controller Main/Sub remote controller MC-195-RS (Sub remote controller is Accessory) Priority display Time display Lock display... -
Page 4: First Time Use
FIRST TIME USE Follow below instructions before use Open water inlet valve fully Plug in Turn on hot water tap, make Open gas valve fully sure there is water flow, then turn off tap To avoid electric shock, don’t use wet hands to touch the power plug or socket. -
Page 5: How To Use
HOW TO USE Setting the remote controller Remote controller setting can be conducted with “ON/OFF button ” and “priority button” at both ON and OFF position. Setting Operation: The sound “Bee” can be heard Press both “ON/OFF” button and from the remote control, indicating “priority”... -
Page 6: Set Clock Time
HOW TO USE Set clock time －－ ： －－" when you turn on the controller without setting clock time. Display shows " Please set the clock following procedure below. －－ ： －－" after blackout or electric plug is disconnected. Please Display also shows "... -
Page 7: Hot Water Temperature
HOW TO USE ● To prevent being scalded, check the water temperature by hand before shower. ● After using hot shower, some hot water will still remain in the water pipe. To prevent being scalded, check water temperature by hand Warning before use. - Page 8 HOW TO USE Deliver hot water with opening hot water tap. ● During hot water delivery display shows "Combustion" display. Combustion display The actual water temperature varies depending on season and length of piping. Please take displayed temperature as rough indication.
- Page 9 HOW TO USE How to use lock function With lock function all buttons stop working to prevent small kids from doing mischief or wrong operation. Lock function can be used for both cases controller is "On" and "Off". In lock mode all operation buttons are blocked except lock button. Lock mode can be set by each controller.
- Page 10 HOW TO USE Press "Function" button once when remote controller is "On" . Display shows as below. Function number Setting mode Press "Up" or "Down" button to change to preferable mode. Saving mode 2 is preset in the factory. Mode Brightness Light off time Dark...
- Page 11 HOW TO USE Press "Up" or "Down" button to change mode. Beep ON is preset in the factory. Mode Beep Beep Silence Press "Function" button twice to go back to original display. Unless pressing "Function" button after 1 minutes it goes back to the original display automatically.
-
Page 12: Safety Notes
SAFETY NOTES Outdoor water heater must not be installed indoor. If the unit is installed indoor, poor ventilation will cause incomplete combustion which leads to oxygen deficiency and CO toxication. Outdoor water heater must not be installed indoor. Check and clean exhaust outlet Check and clean Exhaust outlet regularly to prevent from blocking. - Page 13 " T r o u b l e Shooting". If product doesn’ t still operate properly, please contact Rinnai authorized service centre.
-
Page 14: Installation
INSTALLATION Installation locations for the water heater Please install the unit well ventilated Please do not install near other gas outdoor place (ex.balcony, rooftop) appliances.Please do not put flammable gas or liquid around the unit. ● It is prohibited to install the unit indoor Please do not install the unit underneath ●... - Page 15 Hang water heater on the screw at the notch of the upper hanging bracket and entwist the rest 4 screws on wall plugs to fix the main body. Fix exhaust hood using 4 screws. 5x φ8Wall plugs (Included) Fix 4 screws Remove 4 screws 5x φ4ｘ50 wood screws (Included) REU-1215W-RS REU-2024W-RS Hole location (mm）...
- Page 16 INSTALLATION Water heater installation procedure ● Install the unit at places with enough space for exhaust and air intake. ● To avoid exhaust air coming inslde of room, do not install the unit near the openings of buildings (shaded area at the the below.) Notice Hole location(mm)
- Page 17 It is recommended that stainless steel corrugated pipes (inside diameter more than φ12mm for REU-1215W-RS and φ16mm for REU-2024W-RS) are used at the water inlet and outlet joints of the water heater so as to facilitate the disassembly of the equipment for repair.
-
Page 18: Gas Piping
INSTALLATION Gas piping Gas dedicated ball valves must be installed between the water heater and the gas pipe . Town gas water heater must be connected with metal pipes, cannot use of rubber hoses. Since water heater combusts huge amount of gas in a short time, make sure of providing enough gas to the unit. -
Page 19: Remote Controller Installation
REMOTE CONTROLLER INSTALLATION Please do not install the unit at following places ・In bathroom or places with spray or steam (Controller is not waterproof） ・Places with high temperature or sunshine ・Places where oil scatters ・Ragged wall (Case can be distorted to cause failure) ・Places where some medicines are used (Benzene, Alcohol, extra fatted soap）... - Page 20 REMOTE CONTROLLER INSTALLATION Insert remote controller connector Fix front panel using 4 screws into the connector of unit and fix r e m o t e c o n t r o l l e r c a b l e w i t h bracket, using screws and cable clamp.
- Page 21 REMOTE CONTROLLER INSTALLATION Bring out duplex cable through the hole to connect with remote controller cable with Closed end connector. Peel off the trunking of each cable by 10mm before you crimp them. There is no polar character. Insert hooks of fixing plate into remote controller and move controller down until it clicks. Move downward In case of open wiring, remove cable outlet on remote controller case by nipper.
- Page 22 REMOTE CONTROLLER INSTALLATION Installation onto switch box Put fixing Plate onto switch box using Bring out duplex cable through the hole screws. (M4×25) to connect with remote controller cable with closed end connector. Peel off the trunking of each cable by 10mm before you crimp them.
- Page 23 REMOTE CONTROLLER INSTALLATION How to install remote controllers more than one controller Remote controllers can be used in following combination. (3 controllers can be installed maximum) ・1x main remote controller + 1x sub remote controller ・1x main remote controller + 2x sub remote controller Remove front panel (remove 4 Use closed end connector to crimp screws)
- Page 24 REMOTE CONTROLLER INSTALLATION Refer to p15 ～ p18 to install each Fix front panel using 4 screws controller ●Connect remote controller and duplex cable as below Connect 2 remote controllers Connect 3 remote controllers Main remote Sub remote Main remote Sub remote controller controller...
-
Page 25: Trouble Shooting
Is gas pressure too low? ● If the product doesn’t still operate properly after the above inspections, then disconnect the main plug, insert again to restart the operation. If this doesn’t still solve the problem, please contact Rinnai service centre. -
Page 26: Error Messages
Rinnai service centre. ● When the screen of the digital monitor of the Operating controller is blank, disconnect the power plug and connect again, press power ON. If there is still no light, please call Rinnai service centre. -
Page 27: Inspection & Maintenance
Do not clean it with detergent, thinner etc. Do not remove it. ● In order to ensure safe operation, please take safety inspection every year. Please contact Rinnai service centre about regular inspections. Maintenance ● If there is oil stain on the surface of the product, clean it Rotate water filter to the with wet cloth. - Page 28 INSPECTION & MAINTENANCE In disuse for long term Disconnect power plug and turn the Close gas valve switch to OFF positlon. Close water valve Drain out water inside of heater To avoid electric shock, don’t use wet hands to touch the power plug or socket.
-
Page 29: Dimensions & Product Specification
DIMENSIONS joint joint... - Page 30 DIMENSIONS REU-2024W-RS joint joint...
- Page 31 PRODUCT SPECIFICATION Appliance type Forced exhaust domestic gas water heater Type B Model name REU-1215W-RS REU-2024W-RS Type of gas Town Gas (G 110) Gas supply pressure 8～20 mbar Heat input Qn / Qm 23.5/2.7 kW 38.9/2.9 kW Useful output Pn / Pm 20.7/2.4kW(12/1.4L/min...
- Page 32 Rinnai Holdings (Pacific) Pte Ltd 61 Ubi Road 1 #02-20 & 21 Oxley Bizhub Singapore 408727 www.rinnai.sg Tel:6748 9011 Fax:6745 9240 SU122-990-RS×01(00) 2015.9...
