AURES EKO Quick Start Manual

EKO
Quickstart Guide
SAFETY INSTRUCTIONS
To disconnect the product from the
electrical Power Supply, remove the power
cable plug from the wall socket. The wall
socket must be easily accessible and in close
proximity to the product.
Read these instructions carefully. Save these
instructions for future reference.
Follow all warnings and instructions marked
on the product.
Do not use this product near water.
Do not place this product on an unstable
cart, stand, or table. The product may fall,
causing serious damage to the product.
Only use power supply unit and cables
released by AURES.
Do not allow anything to rest on the power
cord. Do not locate this product where
persons will walk on the cord.
Never spill liquid of any kind on the product.
Ensure that the device connects to a socket/
outlet with ground/earth connection.
CE NOTICE
This device complies with EMC Directive
2014/30/EU and "Low Voltage Directive"
2014/35/EU issued by the Commission of
the European Community.
REL 1.0 September 2024
Model Number
CPU
Storage
Memory
Display
Touch
USB-A
RS232
LAN
Audio
External I/O
C-type
Mini DP
Cash Drawer
Wi-Fi / BT
Speaker
Power Supply
OS Support
Operating Temperature
Storage Temperature
1
2
EKO 15,6"
Rockchip RK3399 (up to 2.o GHz)
eMMC 64GB
4GB DDR4
15,6" TFT LCD FullHD (1920 x 1080)
Projective Capacitive Touch
4 USB2.0 ports
1 port (RJ45)
Gigabit LAN (10/100/1000M BASET LAN)
HD Audio
1 port
MINI-DP
Self Define RJ12 Connector
WLAN (802.11 a/b/g/n, 2.4G/5G),
BT4.0 - combo module
Embedded
12V/5A Adaptor
Android 12 (GMS)
0°C ~ 40°C at 10% ~ 80% humidity
-20°C ~ 60°C at 10% ~ 80% humidity
1. Screen
2. Stand
3. ON/OFF touch button
Dimensions
366.7 x 200 x 276.9 mm
3
