  • Page 1 USER MANUAL VERSION 1.0 September 2011 W-TOUCH...

  • Page 2: Important Safety Instructions

    Copyright 2011 All Rights Reserved Manual Version 1.0 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3 CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
  • Page 4 LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.
  • Page 5 Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release 2011 September...

  • Page 6: Table Of Contents

    Table of Contents 1. Packing List ........1 1-1. Standard Accessories ..........1 1-2. Optional Accessories ...........2 2. System View ........3 2-1. Front & Side View ..........3 2-2. Rear View with Stand ...........3 2-3. I/O Ports View ............4 2-4. System Dimension ..........4 3.
  • Page 7 5. Specifications ......14 6. Jumper Setting ......15 6-1. C48 Motherboard ..........15 6-1-1. Motherboard Layout .........15 6-1-2. Connectors & Functions ......17 6-1-3. Jumper & BIOS/Utility Setting....18 Appendix: Drivers Installation ..25...
  • Page 8 The page is intentionally left blank viii...

  • Page 9: Packing List

    Packing List 1-1. Standard Accessories System Power adapter Power cord VGA cable RJ45-DB9 cable (x2) Wall mount kit...

  • Page 10: Optional Accessories

    1-2. Optional Accessories MSR module SSD card Fingerprint module iButton module...

  • Page 11: System View

    System View 2-1. Front & Side View Item No. Description Touch screen MSR module (optional) Fingerprint or iButton module (optional) 2-2. Rear View with Stand Item No. Description Safety label Cable cover...

  • Page 12: I/O Ports View

    2-3. I/O Ports View b c d e Item No. Description DC IN Cash drawer MIC in Line out COM port 1, 2, 3, 4 (from left to right) USB(x4) Parallel 2nd power button HDD slot 2-4. System Dimension 363.4 mm 48.3 mm...

  • Page 13: System Assembly & Disassembly

    System Assembly & Disassembly 3-1. Open Cable Cover 1. Place the system face down. Make sure not to scratch the screen. 2. Loosen the thumb screws(x2) to open the cable cover. 3-2. Open the System To open the system, please open the cable cover firstly as steps dscribed in chapter 1.

  • Page 14: Hdd Replacement

    3-3. HDD Replacement To remove and replace the HDD, please open the cable cover firstly as steps dscribed in chapter 3-1 1. Power the system off. Find the HDD located at the right side. 2. Pull the HDD tray from the system. For easier removal pull the plastic sheet (see picture) at the same time.

  • Page 15: Ram Replacement

    3-4. RAM Replacement To remove and replace the RAM module, please open the rear cover firstly as steps dscribed in chapter 3-2. Removing a RAM module 1. Find the memory slot at the right side of the motherboard. 2. Flip the ejector clips outwards to remove the memory module from the memory slot.

  • Page 16: Peripheral Installation

    Peripheral Installation 4-1. MSR Installation MSR module can be installed to either side of the system. Choose one side and follow the steps below. Before the installation, please open the cable cover firstly as steps described in chapter 3-2 1. Insert MSR module in place and fasten the screws (M3x2) on the back to secure the module.

  • Page 17: Fingerprint And Ibutton Installation

    4-2. Fingerprint and iButton Installation Fingerprint and iButton module can be installed to either side of the system. Choose one side and follow the steps below. Before the installation, please open the cable cover firstly as steps described in chapter 3-1 1.

  • Page 18: Wall Mount Kit Installation

    4-3. Wall Mount Kit Installation The Wall Mount Kit includes a wall plate, a metal bracket, and one screw. (refer to Chapter 1-2 item c) Please follow the steps below for installation. 1. Secure the wall plate to the wall by fastening screws (M3x4) 2.

  • Page 19: Ssd Card Installation

    4. Fasten the screw (x1) through the metal bracket to secure the wall mount kit. 4-4. SSD Card Installation 1. Refer to Chapter 3-3 to open the system. 2. Find the two positioning pins on the system. 1. Insert the SSD card to the cable connector as shown by arrow.

  • Page 20: Cash Drawer Installation

    4-5. Cash Drawer Installation You can install a cash drawer through the cash drawer port. Please verify the pin as- signment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 21 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 22: Specifications

    Specifications Model W-TOUCH Motherboard CPU Support Intel PineTrial D525 1.8G L2 1M, Dual Core Chipset CPU with Graphic built-in + ICH 8M System Memory 2 x DDR3 SO-DIMM up to 4GB FSB 800MHz Graphic Memory Shared system memory up to 256MB...

  • Page 23: Jumper Setting

    Jumper Setting 6-1. C48 Motherboard 6-1-1. Motherboard Layout PWR1 MINI_PCIE JP12 JP12 CN24 CN23 RJ45_2 JP10 JP10 JP19 JP19 CN22 RJ11_1 CN21 CN15 CN20 CN17 CN18 CN19 SKT1 JP14 CN16 JP14 CN14 CN13 CN27 CN31 SATA2 JP18 JP20 JP20 JP18 RJ45_1 CN11 CN26...
  • Page 24 DDR3_A2 C48 V2.1 BOTTOM LAYER...

  • Page 25: Connectors & Functions

    6-1-2. Connectors & Functions Connector Purpose Power Button Connector Printer Port Reset Printer Port CN5/8 HDD Power CN11 COM5 For Touch CN13 Card Reader Connector CN14 Line out CN15 HDD LED CN16 Speaker & MIC CN18 MIC IN CN20/JP10 System Indicator CN22 USB Port CN23...

  • Page 26: Jumper & Bios/Utility Setting

    6-1-3. Jumper & BIOS/Utility Setting COM2 RS232/485/422 Setting Function 1 3 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10...
  • Page 27 4. To switch on the power, select "Power". Please save the change before exiting BIOS so as to go for physical jumper adjustment. COM3/COM4 Jumper setup Function JP18 ▲+5V COM3 +12V COM4 ▲+12V Function ▲CMOS Normal CMOS Reset ▲ = Manufacturer Default Setting...
  • Page 28 Cash Drawer Power Setting Function JP19 +19V ▲+12V Power Mode Setting Function ▲ATX Power AT Power System Indicator Function JP10 ▲Disable Enable Inverter Selection Function JP14 ▲ CCFL ▲ = Manufacturer Default Setting...
  • Page 29 CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’. (refer to the jumper shown below) 3. Connect the power cable to the system, and power on the system: in ATX mode: press the power button and it will fail power on in AT mode: turn on system power 4.
  • Page 30 LCD ID Setting Several configurations are applied to different sizes of panel. Please refer to the followings to complete relevant settings. LVDS Resolution Output Interface Bits Channel 800 x 600 Single 1024 x 768 Single 1366 x 768 Single 1st: LCD Panel 2nd: VGA port 800 x 600 Single...
  • Page 31 4. To switch on the power, select "+12V". Please save the change before exiting BIOS to avoid data lost. LCD Brightness Control Setting Please note Brightness Control can only be set by setting jumper JP14 for CCFL on the motherboard C48 V2.1. By default, the inverter is CCFL on the motherboard jumper setting.
  • Page 32 Intel Graphics Driver Setting 1. Right click Desktop. Find "Graphics Properties" and enter the manu. 2. Make sure the Display Device is same as follows. Intel Graphics Driver Output Interface Connector & Jumper Device Name LCD Panel CN26 Notebook VGA Port JP3/6 Monitor...

  • Page 33: Appendix: Drivers Installation

    Appendix: Drivers Installation To downoad the most recent drivers and utilities, and obtain advice regarding the installation of your equipment, please visit the AURES Technical Support Website: www.aures-support.fr (French) www.aures-support.fr/UK (English) www.aures-support.fr/GE (German)
