EN Operation manual
Table of contents
1. Safety notes
Introduction
Use
Instrument maintenance
2. Explanation of the rotary selector switch, buttons and sockets
3. General data
4. Application description
5. Changing the battery/fuse
1. Safety notes / introduction
®
The Testboy
TB-2200 is a general purpose multimeter. This measuring instrument
has been manufactured to the latest safety specifications, and guarantees safe and
reliable use. The multimeter is a valuable aid for all standard measurement tasks in
trade and industrial applications as well as for the hobby electrician interested in
electronics.
Safety specifications meet IEC/EN 61010 -1 / DIN VDE 0411
Scope of supply:
®
1 Testboy
TB-2200 Multimeter including safety test leads
1 Operation manual
1 Ever-ready carrying case
- 14 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the Testboy TB-2200 and is the answer not in the manual?

Questions and answers

Related Manuals for Conrad Testboy TB-2200

Summary of Contents for Conrad Testboy TB-2200

  • Page 1 EN Operation manual Table of contents 1. Safety notes Introduction Instrument maintenance 2. Explanation of the rotary selector switch, buttons and sockets 3. General data 4. Application description 5. Changing the battery/fuse 1. Safety notes / introduction ® The Testboy TB-2200 is a general purpose multimeter.
  • Page 2 Safety precautions ® The Testboy TB-2200 left our factory in a technically safe and flawless condition. In order to maintain this condition, the user must observe the safety notes con- tained in this manual. Caution! - This operation manual contains information and notes required to operate and use this instrument safely.
  • Page 3 Caution! The instrument must only be used under the conditions and for the purposes for which it was designed and built. Thus, it is imperative to observe the notes on safe- ty, the technical data in conjunction with the ambient conditions and use the in- strument in dry conditions.
  • Page 4 3. General data The accuracy relates to 1 year at a temperature between 18 °C – 28° and 75 % humidity (yearly calibrations are offered). Autoranging and manual measurement range selection Max. voltage between the connection socket and ground: 300 V DC/AC Fusing: F 200 mA(4 A)/500 V quick-blow fuse Max.
  • Page 5 Volts DC: RANGE RESOLUTION ACCURACY ± 0.5 % of rdg. + 3 dig- 200 mV 0.1 mV 0.001 V ± 0.8 % of rdg. 20 V 0.01 V + 5 digits 200 V 0.1 V 300 V Input impedance: 10 MΩ Max.
  • Page 6 Alternating current: RANGE RESOLUTION ACCURACY 200 µA 0.1 µA 2000 µA 1 µA ± 1.3 % of reading + 5 digits 20.00 mA 0.01 mA 200.00 mA 0.1 mA 2.00 A 10 mA 4.00 A 0.01 A ± 1.5 % of reading + 8 digits Overload protection: F 200 mA/500 V fuse protection for µA and mA ranges 4 A range is protected by 4 A/500 V Resistance:...

  • Page 7: Dc Voltage Measurement

    4. Application description DC VOLTAGE MEASUREMENT Set the selector switch to measurement range V=. Insert the black test lead into the ‘COM’ socket and the red test lead into the right- hand socket. Using the test probes, touch the test points of the test object. The multimeter automatically searches for the most suitable measurement range.
  • Page 8 When carrying out the cable break detection, if the display does not flash and no acoustic signal is emitted, a dangerous high voltage (>33 V AC or 70 V DC) may nevertheless be present. The non-contact sensor can only detect voltage generat- ed by sufficiently strong electric fields from power sources (grids, >100 V AC).

  • Page 9: Dc Current Measurement

    DC CURRENT MEASUREMENT: Set the selector switch to measurement range A. Use the ‘M’ button to set the device to DC. Insert the black test lead into the ‘COM’ socket and the red test lead into the right- hand socket (up to max. 200 mA). You must use the ‘4 A' socket when measuring currents above 200 mA.

  • Page 10: Continuity Test

    CONTINUITY TEST: Set the selector switch to measurement range ‘Ω’. Insert the black test lead into the ‘COM’ socket and the red test lead into the right- hand socket. Using the button ‘M’, set the device to ‘ )) ’. Using the test probes, touch the test points of the test circuit.
  • Page 11 The WEEE directive regulates the return and recycling of electrical appliances. Manufacturers of electrical appliances are obliged to take back and recycle all electrical appliances free of charge. Elec- trical devices may then no longer be disposed of through conven- tional waste disposal channels.
