THIS MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD CAUSE DEATH OR SERIOUS INJURY.
WELCOME
TO THE TEAM!
Congratulations on your purchase
of a Bullard Thermal Imager.
This document is in English, Francais, Deutsch, and
Espanol. To fi nd this document in other languages
please visit
https://www.bullard.com/thermal-imaging/
or scan the QR code below.
SCAN ME!
Bullard TXS Thermal Imager
WARNING
www.bullard.com
User Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bullard TXS
Summary of Contents for Bullard TXS
- Page 1 Bullard TXS Thermal Imager User Manual WARNING THIS MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT. FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD CAUSE DEATH OR SERIOUS INJURY. WELCOME TO THE TEAM! Congratulations on your purchase of a Bullard Thermal Imager.
-
Page 2: Table Of Contents
THE BULLARD TXS THERMAL IMAGERS ARE EXTREMELY SENSITIVE TO INTENSE, RADIANT HEAT SOURCES. NEVER POINT A BULLARD TXS THERMAL IMAGER AT THE SUN OR ANY OTHER SOURCE OF EXTREME RADIANT HEAT. THIS CAN CAUSE SEVERE DAMAGE, AFFECT THE ACCURACY AND RENDER THE PRODUCT UNSAFE FOR USE. - Page 3 SPECIFIC BATTERIES AND CHARGERS CAN DAMAGE THE BULLARD PRODUCTS AND RENDER THEM UNSAFE FOR USE. WARNING DO NOT ATTEMPT TO DISASSEMBLE THE BULLARD TXS THERMAL IMAGER. IF THE UNIT IS NOT FUNCTIONING PROPERLY, RETURN IT TO THE BULLARD SERVICE CENTER FOR EVALUATION.
-
Page 4: Technical Specifications And Certifications
WEEE Compliance: for your recycling needs please contact info@bullard.de WEEE Einhaltung: Fuer Ihren Recyclingbedarf wenden Sie sich bitte an info@bullard.de Bullard’s Thermal Imager TXS complies with the requirements set forth in the regulation. California Proposition 65 WARNING: Cancer and Reproductive Harm- www.P65Warnings.ca.gov. Proposition de la 65 ADVERTISSMENT: Cancer et Troubles de l’appareil reproducteur -... -
Page 5: Thank You And Congratulations
fi refi ghting tool encompass nearly every aspect of a fi refi ghter’s job. This technology enhances images so that elements not visible to the naked eye are now seen. They can accelerate certain tasks by helping the user make more informed decisions. Some of the many uses for your Bullard TXS Thermal Imager include: •... -
Page 6: What's In The Box
5.1 POWER UP Power ON your Bullard TXS Thermal Imager by pressing the green power button on top of the imager. The screen will turn on and the green power button will illuminate. See Table 1 for the power button indicators. The start-up logo will appear followed by the thermal image within a few seconds. -
Page 7: On-Screen Indicators
The Maximum Scene Temperature (dynamic range) is the temperature above which heat signature diff erences can no longer be distinguished. For the TXS the Maximum Scene Temperature is approximately 1022° F (550° C). As scene conditions approach the Maximum Scene Temperature, the display may show a large red zone where the temperature is at or above 1022°... - Page 8 (particularly refl ective objects such as metals and shiny materials) will see a reduced accuracy of the temperature indication. Temperatures measured with thermal imaging can vary based on several factors (see Bullard’s Limitations with Temperature Readings - Caution statement on p.6). Use these features with caution and verify indicated heat levels through traditional means whenever possible.
-
Page 9: Deployment/Operational Life
7.1 CHARGING THE BATTERY Your Bullard TXS Thermal Imager can be charged with one of two charging systems: the included XS USB Wall Charger or the optional Bullard XS Series Dual Charger. To charge your imager with the XS Series Dual Charger, please refer to the XS Series Dual Charger User Manual. -
Page 10: Safety Considerations, General Warnings, And Limitations 8. Care And Storage Instructions
• Check screw tightness on cover window; torque is 5-inch pounds. • Store your Bullard TXS Thermal Imager, powered off , on the provided USB charger, secured in the XS Series Dual Charger, in the XS Series Hard Carrying Case, or in the delivery case provided. For best performance, leave your imager charging when not in use. -
Page 11: Shipment
If the imager appears unresponsive, it may require a hard power-off . To accomplish this, press and hold the Power button for 10 seconds. If the hard power-off does not solve the issue, removing and reinserting the battery pack is another way to force a camera reset. The Bullard TXS Thermal imager is also equipped with a safety feature which provides automatic shutoff... -
Page 12: Service
Table 4 may have a limited warranty. If you are unsure about the warranty, please contact Bullard Customer Service for assistance. - Page 13 The foregoing is the only warranty made by Bullard. No representative, dealer or any other person is authorized to make any warranty, representation, condition or promise on behalf of Bullard with respect to this product. No terms or conditions other than those stated herein or provided by law, and no agreement or understanding, oral or written, in any way purporting to modify this warranty shall be binding upon Bullard, unless made in writing and signed by an authorized employee of Bullard.
-
Page 14: Maintenance Checklist
Every 12 to 36 months: return the unit to Bullard for the Preventive Maintenance service. www.bullard.com... - Page 15 Bullard TXS Thermal Imager User Manual www.bullard.com...
- Page 16 www.bullard.com...
- Page 17 Bullard TXS Thermal Imager User Manual www.bullard.com...
- Page 18 Bullard TXS Thermal Imager User Manual Bullard Center Americas Operations Bullard GmbH Bullard Asia Pacifi c 2421 Fortune Drive 1898 Safety Way Dieselstrasse 8a 51 Changi Business Park Lexington, KY 40509 • USA Cynthiana, KY 41031 • USA 53424 Remagen • Germany Central 2 877.BULLARD (285.5273)
