FlorCraft 709-3908 Owner's Manual

7" wet tile saw with stand
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
7" Wet Tile Saw with Stand
You will need this manual for safety instructions, operating procedures, and warranty.
Put it and the original sales invoice in a safe, dry place for future reference.
Model No. 709-3908
23-1228

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 709-3908 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FlorCraft 709-3908

Summary of Contents for FlorCraft 709-3908

  • Page 1 Model No. 709-3908 Owner's Manual 7" Wet Tile Saw with Stand You will need this manual for safety instructions, operating procedures, and warranty. Put it and the original sales invoice in a safe, dry place for future reference. 23-1228...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PRODUCT SPECIFICATIONS Power Supply ..........120V / 60Hz / 10A SECTION PAGE Horsepower ..............1-1/2 HP Speed (RPM) ............6,000 R/MIN SAFETY RULES / WARNINGS Blade Diameter ..............7 in Arbor Shaft Diameter ............5/8 in General Tool Safety Depth of Cut ..............2-1/4 in Tool Specific Warnings Max.

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES • A guard or any other part that is damaged should be properly WARNING repaired or replaced. Do not perform makeshift repairs. For your own safety, read all of the rules and precautions before • Use the right tool for your job. Do not force your tool to do a operating this tile saw.

  • Page 4: Specific Safety Warnings

    SPECIFIC SAFETY WARNINGS Guidelines for using extension cords DANGER Extension cords are only to be used for temporary purposes. • Risk of serious injury: Keep hands and fingers away from the They do not replace the need for installation of outlets and spinning tile saw blade.

  • Page 5: Contents

    ASSEMBLY PARTS AND COMPONENTS UNPACKING Check for shipping damage. Check immediately whether all parts and accessories are included. ITEM DESCRIPTION Table 27-1/2" Folding Stand (un-assembled) Water Pump Button Head Socket Screw M8 x 60 Sliding Table Washer 8 x 16 x 1.5t Angle Guide Nylon Spacer Hex Head Socket Bolt M10 x 65...

  • Page 6: Assembly

    STAND ASSEMBLY ASSEMBLE TILE SAW STAND Figure 3 1. See Figure 3. Take the upper portions (with the cross bars) of the stand. 2. Insert the four legs by matching the numbers (1-to-1 / 2-to-2) to the numbers on the upper portion of the stand. 3.

  • Page 7: Install The Blade

    INSTALL THE SPLASH GUARD See Figure 6. Place the Cutting Arm and Frame (G) assembly onto the Water Tank. 1. See Figures 8-9. There are two parts to Splash Guard (J). Figure 6 2. Remove the screws and washer from the inner blade guard and outer blade cover before attaching the Splash Guards.
  • Page 8 INSTALL THE WATER PUMP INSTALL THE ANGLE GUIDE See Figure 10 See Figure 12 1. Connect the water hose to the pump nozzle by pushing firmly. 1. Place Angle Guide (M) to the front of Sliding Table (L). 2. Place Pump (K) in Water Tank (F) in the designated area for 2.

  • Page 9: Operation

    OPERATION OPERATIONAL FEATURES Figure 14 Adjustable Laser Alignment System WARNING For more accurate cuts, a laser guide is included with the tile To reduce the risk of accidental start-up, always ensure the switch saw. When used properly, the laser guide makes accurate, is in the OFF position before plugging tool into power source.
  • Page 10 Using the Plunge Function: MAKE A CUT Do not use cracked or broken blades. The tile saw’s Cutting Head can move vertically to make cuts in Do not use side pressure to slow the blades down. the center of the tile, for electrical outlets or air registers. WARNING To Release/Lock the Cutting Head: See Figure 17...
  • Page 11 Make an Angled Cut: 4. Flip the ON/OFF switch to the ON position. Allow the blade to reach its maximum speed and wait for water to arrive at 1. Adjust the Angle Guide to the desired angle. Secure it in the cooling nozzle and is flowing properly before moving the place with the Lock Knob on the Angle Guide.

  • Page 12: Maintenance

    MAINTENANCE TILE SAW MAINTENANCE ADJUST THE SLIDING TABLE This tile saw has been calibrated at the factory to ensure If the table does not slide easily, or there is free play between the accurate cuts. However, some of the components may have guide rails and wheels, or moves from side to side, or is misaligned become misaligned during transport.
  • Page 13 Adjusting Excessive Play in the Table: Adjustments to Square Table Path to Blade: If the upper left table wheels are in proper adjustment, but there Check tile saw by making a straight cut. If cut width varies from is excessive play in the table or if the table movement seems front to back or if there is excessive tile chipping on one side to bind as the table is moved from front to back, then left lower of the cut, but not the other.
  • Page 14 ADJUST THE BLADE ANGLE If the blade is not exactly vertical (0°): • Loosen the miter/bevel locking lever located at the rear The blade angle has been set in the factory, but if the angle is of the Cutting Head. not correct, it must be adjusted.

  • Page 15: General Maintenance

    GENERAL MAINTENANCE WARNING When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause tile saw damage. To ensure safety and reliability, all repairs should be performed by a qualified service technician. WARNING Keep the 7" tile saw dry, clean, and free from oil and grease. Always use a clean cloth when cleaning.

  • Page 16: Parts And Components

    TILE SAW PARTS ILLUSTRATION...
  • Page 17 TILE SAW PARTS LIST Part No. Description Specification Part No. Description Specification TLS1003001 Frame Assembly 25×25 TLS1003050 Bevel Angle Bracket TLS1003002 Socket Head Cap Screw M8×45 TLS1003051 Depth Lock Knob Φ13×L13 TLS1003003 Compression Spring A TLS1003052 Position Pin knob Φ8×H37 Φ6.7×1.8 TLS1003004 Toggle Table Stop...
  • Page 18 TILE SAW PARTS LIST Part No. Description Specification Part No. Description Specification TLS1003097 Wheel B Assembly TLS1003144 Laser Light holder TLS1003098 Hex Socket head Bolt M8×42×Φ8 TLS1003145 Laser Fitting Φ8×Φ12×10 TLS1003099 Bearing Sleeve B TLS1003146 LED Assembly TLS1003100 Work Table Limit Block TLS1003147 Switch Cover TLS1003101...

  • Page 19: Warranty

    MENARDS retail store. At its discretion, FlorCraft agrees to have the tool or any defective part(s) repaired or replaced with the same or similar FlorCraft product or part free of charge, within the stated warranty period, when returned by the original purchaser with original sales receipt.
  • Page 20 Menards, Inc. Eau Claire, WI 54703...
