- Page 1 Please read this manual carefully before using, and keep it for future reference. User Manual 60 cm Ceramic Cooktop, Model Code: TRC600 60 cm Ceramic Cooktop, Model Code: BRCC6001...
- Page 2 P a g e INSTRUCTION MANUAL 60cm Ceramic Cooktop MODEL: BRCC6001 web: brohn.com.au...
-
Page 3: Table Of Contents
START OPERATION ..........................17 FINISHED COOKING ..........................18 LOCKING CONTROLS ........................... 19 USING TIMER ............................20 COOKING GUIDELINES ..........................24 CLEANING AND MAINTENANCE ......................... 26 TROUBLESHOOTING / TECHNICAL SPECIFICATIONS................27 DISPOSAL ................................ 28 10. CUSTOMER CARE ............................29 web: brohn.com.au... -
Page 4: Package
Evidence of damage will be required. 1.2 BEFORE USING YOUR NEW CERAMIC HOB Read this guide, taking special note of the ‘Safety Warnings’ section. Remove any protective film that may still be on your ceramic hob. web: brohn.com.au... -
Page 5: Safety Warnings
Make sure to read all rules and regulations in this manual. Anyone who is not familiar with this appliance is not to operate it. These instructions do not cover every possible situation web: brohn.com.au... - Page 6 Do not disconnect the appliance by using wet hands, gripping end of plug or forcefully pulling cord to disconnect. Grip end of plug, and do not pull cord to disconnect. Do not use appliance if there is a technical fault. All faults must be fixed by a qualified/authorised person. web: brohn.com.au...
- Page 7 Do not leave any items on top of the cooktop as these can become a fire hazard. This appliance is not intended to be operated by means of an external timer or separated remote control system. web: brohn.com.au...
-
Page 8: Product Overview
P a g e 3. PRODUCT OVERVIEW TOP VIEW 1. Max. 1800 W zone 2. Max. 1200 W zone 3. Max. 1800 W zone 4. Max. 1200 W zone 5. Glass plate 6. Control panel web: brohn.com.au... -
Page 9: Control Panel
P a g e CONTROL PANEL Heating zone selection controls Power regulation touch control Key lock control ON/OFF control Timer control web: brohn.com.au... -
Page 10: Installation
Under any circumstances, ensure the ceramic cooker hob is well ventilated and the air inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As shown below: Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm. web: brohn.com.au... - Page 11 P a g e | 11 A (mm) B (mm) C (mm) 50 minimum 20 minimum Air intake Air exit 5 mm web: brohn.com.au...
-
Page 12: Locating The Fixing Brackets
Fix the hob on the work surface by screwing four brackets on the bottom of hob (see picture) after installation. Adjust the bracket position to suit for different work surface’s thickness. web: brohn.com.au... -
Page 13: Cautions
6. A steam cleaner is not to be used. 7. This ceramic hob can be connected only to a supply with system impedance no more than 0.427 ohm. In case if necessary, please consult your supply authority for system impedance information. web: brohn.com.au... -
Page 14: Connecting The Hob To The Main Power Supply
3. The installer must ensure that the correct electrical connection has been made and that it complies with safety regulations. 4. The cable must not be bent or compressed. 5. The cable must be checked regularly and only replaced by a properly qualified professional. web: brohn.com.au... -
Page 15: Using Your Cooktop
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Always centre your pan on the cooking zone. Always lift pans off the ceramic hob – do not slide, or they may scratch the glass. web: brohn.com.au... -
Page 16: Using Touch Controls
You will hear a beep each time a touch is registered. Make sure the controls are always clean, dry, and that there is no object (e.g. a utensil or a cloth) covering them. Even a thin film of water may make the controls difficult to operate. web: brohn.com.au... -
Page 17: Start Operation
You will need to start again at step 1. You can modify the heat setting at any time during cooking. You can modify the power level from 0 to 9 by the slide control. web: brohn.com.au... -
Page 18: Finished Cooking
“H” will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature. It can also be used as an energy saving function if you want to heat further pans, use the hotplate that is still hot. web: brohn.com.au... -
Page 19: Locking Controls
Auto Shutdown Safety feature of the hob is auto shut down. This occurs whenever you forget to switch off a cooking zone. The default shutdown times are shown in the table below: Power level Default working timer (hour) web: brohn.com.au... -
Page 20: Using Timer
4. Touch the timer control again and the first digit will start flashing: you can adjust the time in 10-miute increments. 5. Touching the “-” and “+” together, the timer is cancelled, and the “--” will show in the minute display. web: brohn.com.au... - Page 21 2. Touch timer control, it shows the remaining minute timer. 3. Set the time by touching the “-” or “+” control to “00” as above. Or touch the “-” and “+” together to set the timer to “00” immediately. web: brohn.com.au...
- Page 22 5. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator flash for 5 seconds. NOTE: The red dot next to power level indicator will illuminate indicating that zone is selected. web: brohn.com.au...
- Page 23 3. When cooking timer expires, the corresponding cooking zone will be switch off automatically. NOTE: If you want to change the time after the timer is set, you have to start from step 1. web: brohn.com.au...
-
Page 24: Cooking Guidelines
5. Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a lower setting, return the meat to the pan and add your sauce. 6. Stir the ingredients gently to make sure they are heated through. 7. Serve immediately. web: brohn.com.au... - Page 25 slow warming reheating 3 - 4 rapid simmering cooking rice 5 - 6 pancakes sautéing 7 - 8 cooking pasta stir-frying searing bringing soup to the boil boiling water web: brohn.com.au...
-
Page 26: Cleaning And Maintenance
Make sure you wipe the touch control area with a clean damp area dry before turning the hob back sponge or cloth. Wipe the area completely dry with a paper towel. Switch the power to the hob back on. web: brohn.com.au... -
Page 27: Troubleshooting
Cookware is This may be caused by the This is normal for cookware and does making crackling construction of your cookware not indicate a fault. or clicking noises. (layers of different metals vibrating differently). web: brohn.com.au... -
Page 28: Troubleshooting / Technical Specifications
P a g e | 28 Technical Specifications Cooktop model BRCC6001 Cooking Zones 4 Zones Supply Voltage 220-240V~/380-415V 2N~ Installed Electric Power 6000W Product Size L×W×H (mm) 590X520X55 Building-in Dimensions A×B (mm) 560X490 Notice: We continually strive to improve our products, the specifications and designs might be changed without notice. -
Page 29: Customer Care
For further information on the appliance, service, spare parts or to obtain dimension and installation information, please contact our customer service or visit website. Please have above information and documents on hands before contacting customer service Phone: 1300 615 001 Email: info@brohn.com.au Web: brohn.com.au web: brohn.com.au...
