Please read this manual carefully before using, and keep it for future reference.
User Manual
BRGC6001SS - 60 cm 4 burner gas stainless steel cooktop
BRGC9001SS - 90 cm 5 burner gas stainless steel cooktop
BRGC6001BLK - 60 cm 4 burner gas glass cooktop
BRGC9001BLK - 90 cm 5 burner gas glass cooktop
BRGC3001BLK - 30 cm single burner gas glass hob
BRGC6040DSS - 60 cm 4 burner gas stainless steel hob
BRGC7001SS - 70 cm 5 burner gas stainless steel hob
Advertisement
Table of Contents
Related Manuals for BROHN BRGC6001SS
Summary of Contents for BROHN BRGC6001SS
- Page 1 Please read this manual carefully before using, and keep it for future reference. User Manual BRGC6001SS - 60 cm 4 burner gas stainless steel cooktop BRGC9001SS - 90 cm 5 burner gas stainless steel cooktop BRGC6001BLK - 60 cm 4 burner gas glass cooktop...
-
Page 2: Table Of Contents
GENERAL SAFETY................................6 DURING USE.................................6 CLEANING................................... 6 INSTALLATION................................6 SPECIFICATIONS ..............................7 BRGC3001BLK..............................7 BRGC6040DSS..............................8 BRGC7001SS..............................9 BRGC6001SS / BRGC6001BLK........................10 BRGC9001BLK............................... 11 BRGC9001SS..............................12 ELECTRICAL DETAILS..............................13 GAS DETAILS................................13 USING THE GAS HOB ............................14 BEFORE FIRST USE..............................14 SWITCHING THE HOB ON............................14 AUTOMATIC IGNITION WITH FLAME FAILURE SAFETY DEVICE...............14... - Page 3 INSTALLATION PROCESS............................22 GAS ADJUSTMENT (CONVERSION TO LPG)...................... 23 MINIMUM FLOW ADJUSTMENT FOR HOB GAS TAPS..................24 GAS TAP MAINTENANCE............................25 ELECTRICAL CONNECTION........................... 25 REPLACING THE MAINS SUPPLY CABLE......................26 INSTALLATION SUMMARY WARNINGS........................ 26 DISPOSAL ................................27 CUSTOMER CARE ..............................28 web: brohn.com.au...
-
Page 4: Package
BEFORE USING YOUR NEW GAS HOB Read this guide, taking special note of the ‘Safety Warnings’ section. Remove any protective film that may still be on your gas hob. web: brohn.com.au... -
Page 5: Safety Warnings
It is strongly recommended that the appliance is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision. It is recommended for children not to play with the appliance. web: brohn.com.au... -
Page 6: General Safety
Manufacturer retailer appliance declines responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance. web: brohn.com.au... -
Page 7: Specifications
P a g e 3. SPECIFICATIONS BRGC3001BLK Product specifications: A = 1 x 14.4 MJ/h triple crown (wok) burner (NG) B = Control panel Front control operation Automatic ignition Metal pan stands Flame failure safety device on each burner web: brohn.com.au... -
Page 8: Brgc6040Dss
A = 1 x 10.8 MJ/h rapid burner (NG) B = 2 x 6.5 MJ/h semi-rapid burners (NG) C = 1 x 3.6 MJ/h auxiliary burner (NG) D = Control panel Side control operation Automatic ignition Metal pan stands Flame failure safety device on each burner web: brohn.com.au... -
Page 9: Brgc7001Ss
C = 2 x 6.5 MJ/h semi-rapid burners (NG) D = 1 x 3.6 MJ/h auxiliary burner (NG) E = Control panel Front control operation Automatic ignition Heavy duty metal pan stands Flame failure safety device on each burner web: brohn.com.au... -
Page 10: Brgc6001Ss / Brgc6001Blk
| 10 P a g e BRGC6001SS / BRGC6001BLK Product specifications: A = 1 x 14.4 MJ/h triple crown (wok) burner (NG) B = 2 x 6.5 MJ/h semi-rapid burners (NG) C = 1 x 3.6 MJ/h auxiliary burner (NG) -
Page 11: Brgc9001Blk
C = 2 x 6.5 MJ/h semi-rapid burners (NG) D = 1 x 3.6 MJ/h auxiliary burner (NG) E = Control panel Front control operation Automatic ignition Heavy duty metal pan stands Flame failure safety device on each burner web: brohn.com.au... -
Page 12: Brgc9001Ss
C = 2 x 6.5 MJ/h semi-rapid burners (NG) D = 1 x 3.6 MJ/h auxiliary burner (NG) E = Control panel Front control operation Automatic ignition Heavy duty metal pan stands Flame failure safety device on each burner web: brohn.com.au... -
Page 13: Electrical Details
220 - 240 Vac 50 / 60 Hz Supply Connection: Max Rated Inputs: 0.0008 kW Mains Supply Lead: 3 core x 0.75mm² (Type RR-F <HAR> marked) GAS DETAILS Connection: Rp ½ (ISO R7) Type: Natural Gas (1.0 KPa) LPG (2.75KPa) web: brohn.com.au... -
Page 14: Using The Gas Hob
To ignite a burner: Press in the control knob of the burner that you wish to light and turn it anti-clockwise to the maximum position. If you keep the control knob depressed, the automatic ignition for the burner will operate. web: brohn.com.au... -
Page 15: Energy Saving Tips
200 mm Auxiliary 80 mm The diameter of the bottom of the pan should be compatible with the burner. Use flat bottomed pans only. The burner flame must never extend beyond the diameter of the pan. web: brohn.com.au... -
Page 16: Cleaning
After cleaning and washing them, wipe and dry them carefully. Before placing the burners back on the hob top, make sure that the gas jet is not blocked. IMPORTANT: Make sure that you reassemble the burners in the original way. web: brohn.com.au... -
Page 17: Maintaining The Cast Iron Pan Stands
Using a paper towel, thoroughly dry the pan stands. To maintain the appearance of the cast iron pan stands, we would recommend that you rub a small amount of olive oil into the pan stands after you have finished cleaning them. web: brohn.com.au... -
Page 18: Installation And Gas Connection
The edges of the hob must be a minimum distance of 55 mm from a side or rear wall. 700 mm between the highest point of the hob surface (including the burners) and the underside of any horizontal surface directly above it. web: brohn.com.au... -
Page 19: All Models
Do not leave gaps in the sealing agent or overlap it creating uneven thickness. NOTE: It will be difficult to remove the hob from the benchtop in case when needed, if a silicon sealant used to seal the appliance to the benchtop. Sealing strip Clamp Screw web: brohn.com.au... -
Page 20: Important Information
Prolonged intensive use of the appliance may call for additional ventilation, either by the opening of a window, or by increasing the level of the mechanical ventilation device (where present). web: brohn.com.au... -
Page 21: Dual Gas Regulator Valve Introduction
Out of gas regulator valve thread must match the connecting thread with the gas supply. Regulator valve installation location must be perpendicular to the gas line. After installation, open the gas source switch and check valve body with the gas leak test kit or soap and water for leaks. web: brohn.com.au... -
Page 22: Gas Safety (Installation And Use) Regulations
½” female coupler. Fully tighten the 15 mm x ½” female coupler and seal onto the gas rail. IMPORTANT: The female coupler must be positioned the right way up, as shown in the above picture. web: brohn.com.au... -
Page 23: Gas Adjustment (Conversion To Lpg)
(see table on next page). GENERAL INJECTORS TABLE Power (MJ/h) Kind of gas Nozzle mm Burners Max. Min. 1.80 14.4 1.49 Rapid 10.8 Natural 1.16 Semi-rapid 3.24 0.85 Auxiliary 1.07 14.7 Universal LPG 0.93 Rapid 11.0 web: brohn.com.au... -
Page 24: Minimum Flow Adjustment For Hob Gas Taps
Repeat this process for each one of the gas taps. Install the panel and refit the caps, flame spreaders and knobs after finishing the adjustment. web: brohn.com.au... -
Page 25: Gas Tap Maintenance
Reconnect the gas tap, perform a gas soundness test and then reassemble the hob. ELECTRICAL CONNECTION Power hardwiring connection of the cooktop must be installed by a licensed electrician. Before connecting the appliance, make sure that the supply voltage marked on the rating plate corresponds with your mains supply voltage. web: brohn.com.au... -
Page 26: Replacing The Mains Supply Cable
Sealing materials should be heat resistant to prevent deterioration. Turn on the appliance supply gas tap and light each burner. Check for a clear blue flame without yellow tipping. If burners show any abnormalities check the following: web: brohn.com.au... -
Page 27: Disposal
7. DISPOSAL This appliance requires special waste disposal. For further information regarding the treatment, recovery and recycling of this product please contact your local council, household waste disposal service or store of purchase. The packaging materials are recyclable. web: brohn.com.au... -
Page 28: Customer Care
For further information on the appliance, service, spare parts or to obtain dimension and installation information, please contact our customer service or visit website. Please have above information and documents on hands before contacting customer service Phone: 1300 615 001 Email: info@brohn.com.au Web: brohn.com.au web: brohn.com.au...
