MAX PROP EASY Instruction Manual

Automatic feathering patented propeller
Hide thumbs Also See for EASY:

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
MAX PROP
PROPELLER
®
EASY / WHISPER / ANTISHOCK model
automatic feathering patented propeller
p.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the EASY and is the answer not in the manual?

Questions and answers

Related Manuals for MAX PROP EASY

Summary of Contents for MAX PROP EASY

  • Page 1 INSTRUCTION MANUAL MAX PROP PROPELLER ® EASY / WHISPER / ANTISHOCK model automatic feathering patented propeller...
  • Page 3 PART ONE MAX PROP EASY / WHISPER / ANTISHOCK model propeller ® installation, operation and maintenance instructions 1.Introduction 2.Checks to be carried out before installing the propeller on the propeller shaft 3.How to install the propeller on the propeller shaft 4.Checks to be carried out before launching the boat...
  • Page 5 PART ONE MAX PROP EASY / WHISPER / ANTISHOCK MODEL PROPELLER ® INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS...
  • Page 6 1. INTRODUCTION Thank you for choosing a MAX PROP feathering propeller, EASY/ WHISPER / ® ANTISHOCK model. This instruction manual is used to answer your questions about installing and operating the propeller. Before installing the propeller on the boat, it is essential to read it carefully.
  • Page 7 b. Check the screwing length of the nut (refer to fig.1 where the screwing length is indicated with “X”). To check this we suggest inserting the propeller onto the conical end of the propeller shaft and pushing it against the cone of the shaft (carry out this operation without inserting the key).
  • Page 8 3. HOW TO INSTALL THE PROPELLER ON THE PROPELLER SHAFT ALBERO PORTA-ELICA PROPELLER SHAFT CHIAVETTA - KEY VITI BLOCCA-ZINCO LOCKING ZINC SCREWS DADO - NUT ZINCO - ZINC VITI BLOCCA-DADO LOCKING NUT SCREWS FORI PER INGRASSAGGIO GREASE HOLES fig. 2...
  • Page 9 a. Insert the already assembled propeller onto the propeller shaft (refer to fig. b. Insert the nut into its seat, screw it in and lock it by using the two locking nut screws that must be inserted in their seats and then tighten. The nut tightening torque must not be too high (approximately 20/30 Newton/meter for propeller shafts smaller than 35 mm and approximately 30/40 Newton/ meter for propeller shafts larger than 35 mm).
  • Page 10 4. CHECKS TO BE CARRIED OUT BEFORE LAUNCHING THE BOAT a. Check that the propeller body is free to rotate with respect to the propeller shaft, so that the blades can move freely from the forward position to the reverse position and vice versa. To verify that this happens, hold the propeller body and the propeller shaft separately with your hands.
  • Page 11 5. WARNINGS FOR THE USE OF THE PROPELLER a. The reverse gear must always be engaged starting from the forward gear position. Therefore, before engaging the reverse gear, the forward gear must be engaged for a moment. b. In order to have the propeller blades feathered, the rotation of the propeller shaft must be blocked, even for a few seconds, while the boat moves forward with a speed of at least 5-6 knots and the propeller blades are arranged in the forward position.

  • Page 12: Propeller Maintenance

    6. PROPELLER MAINTENANCE FORI CONTRASSEGNATI “GREASE” “GREASE” HOLES TUBICINO DI ADDUZIONE DEL GRASSO “GREASE” ADDUCTION TUBE fig. 3 a. Fill the propeller body completely with fluid grease through the designated holes marked “grease” (see fig. 3). • Start with a first hole of your choice •...
  • Page 13 • Screw the grease inlet tube into the hole (the tube is supplied with the propeller). Start injecting grease into the propeller body by applying pressure. Keep the injection pressure applied until the injected grease begins to seep out of the propeller body both through its joints and the surfaces of the elements which, during operation, must rotate with respect to the propeller body (blades and hub).
  • Page 14 7. HOW TO PULL THE PROPELLER OFF THE PROPELLER SHAFT ESTRATTORE PULLER ESTRATTORE PULLER ANELLO PORTA ZINCO VITI A TESTA SVASATA ZINC HOLDER RING COUNTERSUNK HEAD SCREWS ANELLO PORTA ZINCO VITI A TESTA SVASATA ZINC HOLDER RING COUNTERSUNK HEAD SCREWS fig.
  • Page 15 e. Fasten the puller (consisting of a perforated washer) to the zinc-holding ring by using special countersunk head screws. f. In each threaded hole of the zinc-holding ring, a countersunk head screw for locking the puller must be inserted. Check that all screws work together to hold the puller pressed against the zinc-holding ring.
  • Page 17 PART TWO POSSIBILITIES OFFERED BY YOUR MAX PROP EASY / WHISPER / ANTISHOCK MODEL ®...
  • Page 18 All the other characteristics of the propeller have negligible influence compared to the pitch and diameter. The MAX PROP EASY / WHISPER / ANTISHOCK model propeller is supplied ® with the two optimal pitches already set based on the requests and the data provided by the customer at the time of ordering.
  • Page 19 GRANO DI BLOCCAGGIO DELLA VITE/ASTA SCREW/ROD LOCKING GRUB SCREW VITE / ASTA DI REGOLAZIONE DEL PASSO PITCH ADJUSTMENT SCREW / ROD fig. 5 p.17...
  • Page 20 FORWARD If the propeller is right-handed, the forward gear pitch is changed by operating on the screw/rod inserted in the threaded hole “R” (right). If the propeller is left-handed, the forward gear pitch is changed by operating on the screw/rod In case of doubts in understanding the inserted in the threaded hole “L”...
  • Page 21 BACKWARD If the propeller is right-handed, the reverse gear pitch is changed by operating on the screw/rod inserted in the threaded hole “L” (left). If the propeller is left-handed, the reverse gear pitch is changed by operating on the screw/rod In case of doubts in understanding the inserted in the threaded hole “R”...
  • Page 22 C. HOW TO ESTABLISH THE PITCH VARIATION In most cases it is not important to know the absolute value of the forward pitch and the reverse pitch already set, it is instead important to establish the possible variation you may wish to make. The user must first establish what is the target cruising RPM, and, consequently, what is the maximum RPM that the engine must reach at maximum acceleration.
  • Page 23 NOTE p.21...
  • Page 24 2. As soon as the goods are ready, Max Prop s.r.l. gives notice to the customer who must take care of the collection.
  • Page 25 5. In the event that the goods are recognised by Max Prop s.r.l. as actually different or flawed due to manufacturing or material defects, the customer will only be entitled to repair or replacement of the original propeller parts free of charge.
  • Page 26 031024 p.24...
  • Page 28 MAX PROP ® viale Carlo Espinasse, 101 - 20156 Milano - ITALY tel. +39 02 33 404 325 - skype: maxprop1 www.maxprop.it - info@maxprop.it p.26...

This manual is also suitable for:

WhisperAntishock
