- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. BROAN 43004 Owner's Manual Shop genuine replacement parts for BROAN 43004 Find Your BROAN HVAC Parts - Select From 1309 Models -------- Manual continues below --------...
-
Page 2: Tools And Materials
43000 SERIES To register this product visit RANGE HOOD www.broan.com READ AND SAVE THESE INSTRUCTIONS INTENDED FOR DOMESTIC COOKING ONLY CAUTION WARNING 1. For general ventilating use only. Do not use to exhaust hazardous TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY or explosive materials and vapors. -
Page 3: Preparing The Hood
pRepARING THe HOOd ROOF CAP ROOF CAP 1. Unpack hood and check contents. You should receive: 1 – Filter with built-in light lens 1 – 3-1/4" x 10" damper/duct connector BP87 DAMPER (NOT IN- CLUDED) LOCATED AT 1 – Installation parts bag LEAST 6" FROM HOOD IN VERTICAL SECTION OF DUCT DAMPER LIGHT LENS (INCLUDED) ALUMINUM OR REMOVE THE COMBINATION HOOD DAMPER... - Page 4 CABINET CUTOUTS MAKING THEM BOTH SECURE AND AIR TIGHT. 1. Follow appropriate directions below for type of ductwork you 3-1/4" x 10" are installing. RECTANGULAR VENTING 4" (10.2 cm) Wall Cap Discharge: Use saber saw or keyhole saw to cut hole 5¼" slightly larger than duct size used so that duct will line up easily 1½" (3.8 cm) 5¼" (13.3 cm) with damper/duct connector on hood. Install casing strips if cap will be installed on siding. Attach required amount of duct to wall CABINET STARTER HOLES...
-
Page 5: Warranty
RANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. If preparing flaming foods, such as Cherries Jubilee, always turn During this one-year period, Broan-NuTone will, at its option, repair or replace, without charge, any product or part hood ON to HIGH to prevent a high heat situation which can cause which is found to be defective under normal use and service.
