Whirlpool ADP 5966 Quick Reference Manual

ADP 5966
Program selector knob
Mains On / Off
Start button
Switches "on" when the dishwasher is
operating. Flashes when a fault occurs.
Switches off at the end of the programme.
Indicators
Add rinse aid
Add regeneration salt
only add regeneration salt immediately before
starting a wash programme.
Wash cycle
Pre-wash Washing
Programmes
Auto Normal
Auto Intensive
Pre-Rinse
Glasses
Quickwash
Eco-Normal
1) Reference programme for energy label in compliance with
EN 50242 regulations;
2) Refer to "User instructions";
Whirlpool is a registered trademark of Whirlpool USA
Before using the dishwasher, read the user instructions!
Quick Reference Guide
Programme
Drying
end
Programme chart
Loading instructions
Recommended programme for routine
40-55°C
washes, for crockery with little dried-on food.
Recommended programme for heavily
60-70°C soiled crockery, especially suitable for pans
and saucepans.
cold Crockery to be washed later.
40°C Light soiling, for example glasses and cups.
Lightly soiled crockery with no dried-on
40°C
food.
1)
50°C Normally or heavily soiled crockery.
Options
"Half load - Multizone" button
Load the upper or lower rack only.
This function can be used with any programme.
Press once = upper rack (the indicator lamp
comes on)
Press twice = lower rack (the indicator lamp
comes on)
Press 3 times = Off (half load function
deactivated).
Time and failure display
Indicates in hours the time remaining until
the start of the wash cycle. Toward the end
of the programme, during the drying cycle,
the display will indicate the time remaining
in minutes.
"F..." Identification of faults for service
technician
"Delayed start" button
The wash cycle can be programmed to start
after 1 - 24 hours. With each successive
touch of the button, the delayed start
indicator increases by 1 hour, and after 24
returns to 00. Then press the Start button.
The dishwasher will start at the set time.
Detergent
A
X
X
-
X
X
X
3) Values may vary in relation to usage, e.g.: different loads,
water temperatures - above or below 15° C - as well as
water hardness and power supply voltage, etc.
(We reserve the right to make technical modifications)
GB
3)
2) 3)
Consumption
B Litres kWh Minutes
X 10.0-13.0 0.80-1.05 50-110
X 13.0-20.0 1.10-2.00 90-140
- 4.0 0.03 14
- 10.0 0.80 55
- 10.0 0.65 30
X 13.0 1.05 110
5019 396 91112
WH/I/K/GB
