  • Page 1 10″ BUILT-IN TEMPERATURE RECORDER – RCDR318 10″ BUILT-IN TEMPERATURE/HUMIDITY RECORDER - RCDR319 For Technical Support contact service@caronproducts.com For Replacement Parts contact parts@caronproducts.com...
  • Page 2: Revision Log

    Revision Log Revisions Description Letter Date 12-16-2015 Initial release. INST-RCDRRI 318-319 10 inch Cobex Rev A 12/16/2015 Page 2...
  • Page 3 Instructions for Installing 10″ Built-in Recorder with Temperature or Temperature/Humidity Option Parts Required: RCDR318 or RCDR319 Tools Required: Phillips Screwdriver Bit, Drill, #33 Drill Bit, #6-32 Tap, Ladder, Sharpie Marker Consumable Item: Chart Paper 10″ for Cobex Thermal Pen (PN PPR-106) Consumable item included in 10″...
  • Page 4 STEP 1 – Unpack Contents of RCDR318 or RCDR319 Parts included in RCDR318 or RCDR319 are (1) chart recorder with recorder panel with sensor and transformer wires, (2) 6-32 X 1/2″ black Phillips screws labeled “A”, (1) 6-32 X 3/8″ silver Phillips screw labeled “B”, (1) 6-32 X 3/8″...
  • Page 5 STEP 2 – Remove Top Access Panel 1. Turn off chamber and unplug power cord. Disconnect electrical power before removing top access panel. 2. Remove (3) screws in top access panel along front of chamber using Phillips screwdriver bit as shown below. Note: Retain screws.
  • Page 6 STEP 3 – Drill and Tap Door in Preparation for Mounting 1. Open chamber door, align recorder bracket and door cover edges and mark both mounting holes as shown below. Note: Let recorder panel with attached wire sleeve hang off to side of chamber while installing recorder. Mark Mounting Holes Recorder Bracket Edge Door Cover Edge...
  • Page 7 STEP 4 – Drill and Tap Wire Sleeve Clip 1. Use #33 bit and #6-32 tap to drill and tap mounting hole for wire sleeve clip located approximately 4″ below screw on right side of chamber and 1″ to right of door as shown below.
  • Page 8 Tapping Mounting Hole STEP 5 – Attach Recorder Note: If chamber has solid door option remove tape from recorder, discard and skip #1 and 1. Remove adhesive from tape on back of recorder. Note: Once adhesive has touched glass it cannot be moved. 2.
  • Page 9 STEP 6 – Replace Accessory Panel with Recorder Panel 1. Remove (2) screws in right side front accessory panel using Phillips screwdriver bit as shown below. Note: Retain screws. Accessory panels may appear different depending on option. Right Side Front Accessory Panel Screws 2.
  • Page 10 5. Insert recorder wire sleeve into wire sleeve clip and mount to side of chamber with silver “B” screw included as shown below. Wire Sleeve Clip STEP 7 – Preparation to Install Recorder Sensor inside Chamber 1. Remove shelves near sensor access plate inside chamber and remove sensor access plate by sliding latches downward as shown below.
  • Page 11: Step 8 - Transformer Connections

    STEP 8 – Transformer Connections Note: All steps listed in this section refer to parts located in service compartment which may appear different depending on chamber options. Connect recorder red wire to transformer on bottom left and black wire to transformer on bottom right as shown below.
  • Page 12 STEP 9 –Connect Recorder Power Harness Note: All steps listed in this section refer to parts located in service compartment which may appear different depending on chamber options. 1. Connect transformer power harness to (green/yellow and brown/blue) chamber power harness labeled “CHART RECORDER” as shown below. Chamber Recorder Power Harness in Service Compartment Transformer Power Harness Chamber Recorder Power Harness...
  • Page 13 2. Loosen rear bulkhead fitting with channel locks as shown below. Rear Bulkhead in Service Compartment Rear Bulkhead Fitting 3. Remove insulation as shown below. Note: Retain insulation. Rear Bulkhead in Service Compartment Insulation INST-RCDRRI 318-319 10 inch Cobex Rev A 12/16/2015 Page 13...
  • Page 14 4. Insert recorder sensor into rear bulkhead, feed recorder sensor from rear bulkhead behind rear wall plenum to sensor access plate and insert into clip as shown below. Note: Recorder sensor, wire and clip location may appear different depending on recorder option as shown below.
  • Page 15 5. Reinstall sensor access plate by sliding latches upward as shown below. Sensor Access Plate Sensor Access Plate Latches 6. Reinstall shelves. 7. Remove slack from recorder sensor wire, coil and secure with wire clip as shown below. Wire Clip in Service Compartment Wire Clip INST-RCDRRI 318-319 10 inch Cobex Rev A 12/16/2015...
  • Page 16 8. Wrap insulation around wires in rear bulkhead as shown below. Rear Bulkhead in Service Compartment Insulation 9. Tighten rear bulkhead fitting in service compartment with channel locks as shown below. Rear Bulkhead in Service Compartment Rear Bulkhead Fitting INST-RCDRRI 318-319 10 inch Cobex Rev A 12/16/2015 Page 16...
  • Page 17 10. Seal recorder sensor and wires in rear bulkhead with retained permagum as shown below. Rear Bulkhead in Service Compartment Recorder Sensor and Wires Sealed with Permagum STEP 11 – Install Top Access Panel 1. Install top access panel by sliding towards rear of chamber until (3) tabs on each side are engaged as shown below.
  • Page 18 2. Secure top access panel along front of chamber with retained (3) screws using Phillips screwdriver bit as shown below. Screw Locations STEP 12 – Prepare Recorder 1. Plug in power cord and turn on chamber. 2. Open chart recorder door by pulling on magnetic door latch as shown below. Magnetic Door Latch 3.
  • Page 19 3. Remove pen cap as shown below. Note: Retain pen cap to be used when chart recorder is not in service to extend pen life. Do not bend pen when handling. Pen Cap 4. Remove chart recorder paper hub by turning hub counterclockwise once pen has moved off chart recorder paper as shown below.
  • Page 20 STEP 13 – Return to Operation 1. Chamber is ready for operation with installed 10 inch Cobex recorder as shown below. INST-RCDRRI 318-319 10 inch Cobex Rev A 12/16/2015 Page 20...
