Summary of Contents for Carestream DRYVIEW 6950
- Page 1 Site Readiness & Preparation for Installation of DRYVIEW 6950 Laser Imager, DRYVIEW 5950 Laser Imager, DRYVIEW 5700 Laser Imager H241_0099 Publication No. AN9405 2024-03-06...
- Page 2 All rights reserved. No part of this manual may be reproduced or copied in any form by any means—graphic, electronic, or mechanical, including photocopying, typing, or information retrieval systems—without written permission.
-
Page 3: Table Of Contents
Contents Checklist............................ 2 Installation Skills Required......................5 Installation Tools........................6 Equipment Specifications......................7 DRYVIEW 6950 Laser Imager........................7 DRYVIEW 5950 Laser Imager........................9 DRYVIEW 5700 Laser Imager.........................10 Location Requirements......................11 Power Requirements......................12 Network Requirements......................13 Modalities..........................15 Smart Link and Remote Management Services (RMS)..........1... -
Page 4: Checklist
Use this checklist to ensure that all guidelines and site specifications for installation of your DRYVIEW Laser Imager have been fulfilled. Preparation for installation is your responsibility; however, Carestream has resources available to help you if needed. Review the requirements contained in this document and, if you have questions, please contact your Authorized Carestream Service Provider. - Page 5 Installation and setup the or Carestream Service Skills Required Imager. Installation of DRYVIEW Provider Laser Imager by customer biomedical engineers is supported by some Carestream countries. Contact your Carestream Sales Representative for details. Carestream Field Engineer Tools needed to install Installation...
- Page 6 Provide network (host) name, Network Configuration Engineers, IT personnel DICOM port number, IP Requirements address, subnet mask, and default gateway. Modality Carestream Field Engineer Modalities Provide the following Configuration or Carestream Service information for each Provider, Biomedical modality:manufacturer, Engineers modality type (MR, CR, CT, DR, etc.), model name, software...
-
Page 7: Installation Skills Required
Installer Education and Experience Installation of the DRYVIEW Laser Imagers by customer Biomedical Engineers, is supported by Carestream in some countries. Please contact your Carestream Sales Representative for details. The following education and experience levels are required for those who install DRYVIEW Laser Imagers: •... -
Page 8: Installation Tools
For the “basic install” the latest Secure Link and WebLink versions are not required, however for advanced troubleshooting/set up it is required to install on your service laptop Secure Link Client version 3.2.4.02 or higher. Please refer to Carestream Service Assets web page for further information. -
Page 9: Equipment Specifications
Equipment Specifications DRYVIEW 6950 Laser Imager DRYVIEW 6950 Laser Imager without sorter (A) Width: 62.6 cm (24.7 in.) (B) Depth: 68.6 cm (27.0 in.) (C) Height: 115.0 cm (45.3 in.) Weight: 147 kg (325 lb) H241_0090 (1) Distance from Wall: 31 cm (12 in.) (2) Clearance for Right Side: 31 cm (12 in.) - Page 10 Equipment Specifications DRYVIEW 6950 Laser Imager with sorter (A) Width: 62.6 cm (24.7 in.) (B) Depth: 68.6 cm (27.0 in.) (C) Height: 159.0 cm (62.6 in.) Weight: 177 kg (390 lb) H241_0091 Note: The approximate weight of a 35 x 43 cm (14 x 17 in.) film cartridge is 3.5 kg (7.7 lb.).
-
Page 11: Dryview 5950 Laser Imager
Equipment Specifications DRYVIEW 5950 Laser Imager (A) Width: 65 cm (25 in.) (B) Depth: 65 cm (25 in.) (C) Height: 67 cm (26 in.) Weight: 79 kg (175 lb) H241_0088 (1) Distance from Wall: 31 cm (12 in.) (2) Clearance for Right Side: 31 cm (12 in.) (3) Clearance for Front: 31 cm (12 in.) (4) Clearance for Left Side: 31 cm (12 in.) H241_0093... -
Page 12: Dryview 5700 Laser Imager
Equipment Specifications DRYVIEW 5700 Laser Imager (A) Width: 61 cm (24 in) (B) Depth: 66 cm (26 in.) (C) Height: 47 cm (19 in.) Weight: 54 kg (120 lb) H241_0087 (1) Distance from Wall: 31 cm (12 in.) (2) Clearance for Right Side: 31 cm (12 in.) (3) Clearance for Front: 31 cm (12 in.) (4) Clearance for Left Side: 31 cm (12 in.) H241_0092... -
Page 13: Location Requirements
80 % RH, non-condensing. Operating Space Requirements • The DRYVIEW 6950 Laser Imager requires a flat, level floor space and at least 61 cm (24 in.) around the top, sides, and back. • The DRYVIEW 5950 Laser Imager and DRYVIEW 5700 Laser Imager require a flat, stable surface (stand or table) that supports the dimensions and weight of the imager. -
Page 14: Power Requirements
Power Requirements • A power cord is provided with this equipment. All countries must use an agency- approved power cord with a plug type suitable for the country of use. Connect the equipment to a power source that is suitable for the voltage and current ratings at your site. -
Page 15: Network Requirements
• The imager receives digital images from medical imaging devices (modalities) over a 10/100/1000 Base-T Ethernet network. During the installation, Carestream personnel or Biomedical Engineers (in countries where applicable), will enter the network information for the DRYVIEW Laser Imager to let it communicate across the network. - Page 16 Network Requirements ONLY if Proxy Server is used. Required Information Record Information from Customer Site Proxy type Proxy address Proxy port number Proxy username Proxy password Proxy domain For all sites enabling Remote Management Services, the DRYVIEW Laser Imager will also access a secure external server.
-
Page 17: Modalities
Modalities A list of the modalities that will connect to the DRYVIEW Laser Imager must be available at installation. This list must include the following configuration information for each modality: Required Information Record Information from Customer Site Modality Manufacturer Modality Type (CT, DR, MR, CR, etc.) Model Name Modality Name (Descriptive name assigned by the customer for use on the Local Panel) -
Page 18: Smart Link And Remote Management Services (Rms)
To guarantee a successful RMS Smart Link connectivity, provide the following to the customer’s IT department Some adjustments may be necessary by the customer IT. The site IT manager must configure the firewall to let the Carestream device to communicate with the Carestream secure Smart Link servers (PTC IoT cloud). - Page 19 Smart Link and Remote Management Services (RMS) Server Description Host IP Address Time Zone Offset Ent-Prod Production carestreamhealth.axeda.com 40.114.92.56 -5:00 Enterprise server Ent-Prod Production carestreamhealthprod.cloud.thi 52.186.103.126 -5:00 Enterprise server ngworx.com gas-aus2 GAS Host Australia gas-aus2.axeda.com 54.153.206.11 +11.00 gas-aus3 GAS Host Australia gas-aus3.axeda.com 54.66.217.58 +9.00...
- Page 20 TCP/IP port 53 is used to sync data between the DNS servers, while UDP port 53 is used by the Carestream device (DNS client) to resolve the URL (e.g., Production Enterprise server, see above table) via the DNS server. The DNS server on site will still need to sync data with DNS servers outside.
- Page 21 Carestream Health, Inc. 150 Verona Street Rochester, NY, USA 14608 © Carestream Health, Inc., 2024 Made in USA. CARESTREAM and DRYVIEW are trademarks of Carestream Health. Pub. No. AN9405 Rev. A...
