- Page 1 Power Post ™ Pump Connection Center ( | Demand Dose, Integrated Alarm standard) USER GUIDE MODEL NUMBER: PRPT-0002...
-
Page 2: Table Of Contents
USER GUIDE | Power Post™ Contents Introduction ................................. 3 Safety Guidelines ..............................3 Product Included ..............................4 Features ................................. 5 Installation .................................. 6 Installing Post ..............................6, 7 Wiring ..................................7, 8 Testing ..................................9 Final Installation ..............................10, 11 General Operation ..............................12 Septic Tank Monitoring ............................ -
Page 3: Introduction
4. DO NOT use this product with or near flammable liquids. 5. DO NOT install this product in locations classified as hazardous or in explosive atmospheres as defined by any applicable electrical safety code. Alderon Industries™ - Leading Edge Control Products | 3... -
Page 4: Product Included
The filter switch is used to activate an alarm when a septic tank effluent filter needs to be serviced and is universal to any brand of effluent filter that has a one-inch through hole. 4 | Alderon Industries™ - Leading Edge Control Products... -
Page 5: Features
(7) Auxiliary Contacts - One set of auxiliary contact terminals are included allowing the alarm to interface with an external device. The contacts are rated for 24VDC @ 0.5A maximum. Alderon Industries™ - Leading Edge Control Products | 5... -
Page 6: Installation
Take the 3-hole rubber grommet (#4) which has slits next to the holes and insert cables, then insert the rubber grommet into the conduit. 5. Place the PVC coupler over the end of the conduit. 6 | Alderon Industries™ - Leading Edge Control Products... -
Page 7: Wiring
STEP 1: INSTALLING WIRE INTO WAGO CONNECTOR 1) Lift tab(s) upward. 2) Insert wire(s) into slot. 3) Press tab(s) downward. TO OPEN TO CLOSE 4) Make sure wire(s) are secured. WAGO WAGO Alderon Industries™ - Leading Edge Control Products | 7... - Page 8 (3B) from step 3-1. Note: The installation example shown is for a 230VAC system, use the same process when connecting 120VAC piggyback Pump Power Cable power cables. 8 | Alderon Industries™ - Leading Edge Control Products...
-
Page 9: Testing
To ensure the product is functioning properly, test once a week. Power Post™ Alarm Circuit Board Terminals: TB-1 and TB-2 = Alarm Float Switch/Sensor TB-3 and TB-4 = Auxiliary Contacts TB-5 and TB-6 = Alarm Power (120VAC, L1 and N) Alderon Industries™ - Leading Edge Control Products | 9... -
Page 10: Final Installation
(2A). Fasten the screws to properly secure the cap (2B). The cap prevents water intrusion and allows airflow to prevent the build up of gases and condensation inside the post. 10 | Alderon Industries™ - Leading Edge Control Products... - Page 11 STEP 3: BACKFILL Once all steps of the installation and wiring are complete, take the dirt/soil removed and backfill the area you dug for the post and riser. Backfill Area Backfill Area Alderon Industries™ - Leading Edge Control Products | 11...
-
Page 12: General Operation
Power Post™ auxiliary contacts. When the Power Post™ is in an alarm condition, the Power Post™ indoor alarm is as well. Power Post™ House to Septic Alarm Septic to Drain Field Float Pump Switch 12 | Alderon Industries™ - Leading Edge Control Products... -
Page 13: Alarm Auxiliary With Auto Dialer
If the alarm is in silence mode for longer than 24 hours, the alarm will reactivate. Power Post™ Auto Dialer House to Septic Septic to Drain Field Alarm Float Pump Switch Alderon Industries™ - Leading Edge Control Products | 13... -
Page 14: Alarm Auxiliary With Power Post™ Indoor Alarm And Auto Dialer
The auto dialer must have its own power supply, separate from that of the Power Post™ indoor alarm. Auto Dialer Power Post™ Power Post™ Indoor Alarm House to Septic Septic to Drain Field Alarm Float Pump Switch 14 | Alderon Industries™ - Leading Edge Control Products... -
Page 15: Troubleshooting
The auxiliary contacts are not activating If the alarm is not activated, then the Test the alarm and the auxiliary contacts auxiliary contacts should also be off should work while the alarm is activated Alderon Industries™ - Leading Edge Control Products | 15... -
Page 16: Specifications
Caution: changes / modifications not approved by Alderon Industries could void the user’s authority to operate the equipment. -
Page 17: Warranty Information
Three-Year Limited Warranty - Standard Products LIMITED WARRANTY: Subject to the conditions of this Three-Year Limited Warranty, Alderon Industries, LLC (“Alderon”) warrants to the original user or consumer of an Alderon product (the “Product”) that, for a period of three (3) years from the date of manufacture, the Product will be free from defects in materials and workmanship under normal use and service, and provided the Product is installed, operated and maintained in accordance with instructions supplied by Alderon. - Page 18 USER GUIDE | Power Post™ This page intentionally left blank 18 | Alderon Industries™ - Leading Edge Control Products...
- Page 19 Power Post™ | USER GUIDE This page intentionally left blank Alderon Industries™ - Leading Edge Control Products | 19...
-
Page 20: Company Information
UG00008_Rev07_PRPT-0002_Power Post | October 17, 2022 7:41 AM Company Location: 151 16th Street South, Hawley, MN 56549 Mailing Address: PO Box 827, Hawley, MN 56549 Main Office Phone: 218.483.3034 Website: alderonind.com General Inquiry Email: info@alderonind.com Submit New Orders: orders@alderonind.com...
