Definitions: Safety Guidelines and Words
This instruction manual uses the following safety alert symbols and words to alert you
to hazardous situations and your risk of personal injury or property damage.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided,
may result in property damage.
IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS OR ANY D
CALL US TOLL FREE AT: 1-855-558-2422.
WARNING: Read and understand all instructions. This manual contains
important safety and operating instructions. Please read this manual carefully
before assembling this stool and save it for reference.
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS
WARNING: BEFORE YOU BEGIN:
• Read all instructions thoroughly.
• Remove all components from the box, and lay them on the floor in an orderly fashion.
• Wear eye protection.
• Be cautious of sharp edges.
• Do not stand on product. You may fall which may cause personal injury.
• 300 lb weight limit.
• Keep this information for future reference.
Seat Strut and Cushion Seat Instructions (Fig. 1-4)
1. Cushion Seat Strut Install (Fig. 1)
• Take the seat strut and install into the top of the upright frame. Be sure to center the seat strut correctly
when installing it and firmly push it in.
2. Cushion Seat and Base Assembly
• Take the base and put it on the bottom of the cushion seat. (Fig. 2)
• Use the (4) Phillips pan head bolts to install the base to the cushion seat. (Fig. 3)
®
3. Cushion Seat and Base Install (Fig. 4)
• Slip the cushion seat and base onto the seat strut.
• Firmly push down the center of the cushion seat to secure it to the seat strut.
FIG. 1 FIG. 2
SEAT STRUT
BASE
UPRIGHT
FRAME
DXSTCS025 Copyright © 2024, D WALT
E
WALT.
E
WALT Industrial Tool Co., or an affiliate thereof
E
WALT TOOL,
E
FIG. 3
CUSHION
CUSHION
SEAT
SEAT
(4)
(4)
PHILLIPS ® PHILLIPS ®
PAN HEAD PAN HEAD
BOLTS
BOLTS
FIG. 4
CUSHION SEAT
Foot Assembly Instructions (Fig. 5-7)
1. Caster Removal (Fig. 5)
• Begin by loosening the nuts on the top of the casters. Holding the top of the caster will assist with removal.
• Once the nut is free, take it off along with the lock washer and flat washer.
• Repeat for the remaining 3 casters.
2. Foot Test (Fig. 6)
• Slip the foot onto the frame.
• Using the hardware from the caster and the supplied bolt, attach the foot to the frame. Do not tighten all
the way at this point.
• Repeat for the remaining 3 legs.
• Place the stool on its 4 legs. Check to see if the stool is level. If it is, tighten all of the bolts to the feet. If
not, move on to step 3.
3. Level Adjustments (Fig. 7)
• Shims (3 included) will be used to make adjustments to level the stool. These shims are to be placed on
the legs before the foot installation if removing the casters.
• In order to use a shim, disassemble the feet that require adjustments. Then, place a shim followed by the
foot, and bolt it together.
• Once more, check to make sure the stool is level. If not, repeat process.
FIG. 5
LEG
LOCK
WASHER
CASTER
Two Year Limited Warranty
D WALT stools are backed by a two year limited warranty. This warranty covers manufacturer defects and
E
workmanship. The warranty excludes misuse or abuse and normal wear and tear. Exclusion is not allowed in some
states and may not apply. This warranty gives you specific legal rights, and you may have other rights, which vary
from state to state. For further detail of warranty coverage, call 1-855-558-2422.
In addition to the warranty, D
90 Day Money Back Guarantee
If you are not completely satisfied with the performance of your D
WALT within 90 days from the date of purchase with a receipt for a full refund – no questions asked.
E
Latin America
This warranty does not apply to products sold in Latin America. For products sold in Latin America, see country
specific warranty information contained in the packaging, call the local company or see website for
warranty information.
