Summary of Contents for iTechworld 2000W
- Page 1 USER GUIDE INVERTER PURE SINE WAVE...
-
Page 2: Table Of Contents
CONTENTS Overview Key Features Product Overview Remote Overview (Sold Separately) LED Indicators Fault LED Indicators Installation AC Output Installation Chassis Grounding Connecting the Battery Basic Setup Diagram Remote Installation Mounting Requirements Cable & Fuse Guide Battery Preparation Operation Operating the Inverter AC 240V Output Overview Safety Precautions Contact Us... -
Page 3: Overview
OVERVIEW The iTechworld Inverter range was designed and developed to convert your 12V power from your battery system into safe and reliable 240V power. This allows you to operate appliances you’ d typically have to stay at home to use, from the comfort of your caravan, camper, or 4WD. - Page 4 POSITIVE TERMINAL POWER SWITCH NEGATIVE TERMINAL LED INDICATORS COOLING FAN REMOTE PORT 240V OUTPUT PORT...
-
Page 5: Remote Overview (Sold Separately)
REMOTE OVERVIEW (SOLD SEPERATELY): FAULT POWER BATTERY 100% LOAD The inverter remote provides you with the ability to control the inverter' s basic features from a more convenient location. For the remote to function, the on/off switch on the inverter must be turned on. POWER BUTTON Press and hold for 3 seconds to turn the inverter on/off. -
Page 6: Led Indicators
Flashes 4 Times draw of your appliance/s does not exceed Detected the rated maximum of the inverter. Isolate the inverter, then reconnect the appliance. If you are still experiencing Flashes 5 Times Internal Fault Detected issues, please contact the iTechworld service centre. -
Page 7: Installation
INSTALLATION AC OUTPUT INSTALLATION: WE RECOMMEND THIS INSTALL IS DONE BY A LICENSED ELECTRICIAN Before installing the inverter into your system, ensure the unit is switched off and that there are no devices plugged into the AC 240V outputs. THIS STEP SHOULD BE COMPLETED BEFORE INSTALLATION... -
Page 8: Chassis Grounding
CHASSIS GROUNDING: Grounding of the inverter is mandatory before use to prevent damage or injury. Locate the grounding point on the provided mounting bracket near the negative terminal of the inverter. Ground the inverter by securely attaching a copper cable which is at least 4mm 2. -
Page 9: Basic Setup Diagram
BASIC SETUP DIAGRAM: MAXI FUSE MAXI FUSE BUSBARS FOR WIRING ACCESSORIES (OPTIONAL) MAXI FUSE MAXI FUSE BM500... -
Page 10: Remote Installation
REMOTE INSTALLATION (SOLD SEPARATELY): The remote allows the inverter to be operated from a distance, making it perfect for installations where the inverter is not easily accessible. 1 - Select a space you would like the inverter remote to be installed, preferably away from moisture in a canopy or caravan wall. -
Page 11: Mounting Requirements
4 - Remove the faceplate of the inverter remote by pulling on the small recess along one of the outer edges. 5 - Insert the remote into the prepared hole and secure it in place using M3 screws 6 - Reattach the inverter remote faceplate and connect the included RJ12 cable to the core MOUNTING REQUIREMENTS: When mounting the inverter, please adhere to the following guidelines:... -
Page 12: Cable & Fuse Guide
COOL - Opt for a mounting location that stays within 0°C and 40°C. SAFE - Ensure the mounting area is free from fumes and other potential hazards. LIMIT DUST - Mount the inverter in an area with minimal dust ingress to prevent dust from being drawn in my the fans during operation. -
Page 13: Battery Preparation
SLD, AGM, GEL, or LiFeP04. The inverters are also capable of being connected to batteries in parallel. Paralleling an iTechworld battery with a compatible iTechworld battery of the same Ah and type will increase the maximum continuous discharge rate. -
Page 14: Operation
OPERATION OPERATING THE INVERTER: Once you’ve wired the input side, your inverter is ready to power your 240V appliances. Before operating the inverter, ensure the total wattage of the appliance/s you intend to use is below the rated wattage of the inverter. 1 - If you’re powering the inverter from an 12V source, ensure that the battery has enough charge to support the draw. -
Page 15: Ac 240V Output Overview
It is important to note you can only connect appliances with a wattage the same or below the rated max of the specific inverter.For instance, iTechworld 300OW inverter has a maximum continuous output of 3000W. So you will have to ensure the combined wattage of all the connected devices does not exceed 3000W. -
Page 16: Specifications
440 x 265 x 97mm 494 x 289 x 105mm Protections Safety Features 15.5±0.2V DC 10.5±0.2V DC Remote Terminal RJ12 Dimensions 86 x 86 x 19mm The iTechworld Inverter Range comply with AS/NZS 4763:2011 and IEC/EN 62368-1 including Australian deviations. -
Page 17: Safety Precautions
SAFETY PRECAUTIONS For safe operation and optimal performance, the iTechworld Pure Sine Wave Inverter must be installed and operated correctly. Please carefully read, understand, and follow all instructions and guidelines in this user guide. Pure Sine Wave Inverter. Failure to follow these instructions may result in damage to the unit, property, death, or serious injury. - Page 18 DANGER: Do not disassemble or modify the inverter, doing so may result in a risk of DANGER: This inverter is only suitable for battery types listed in the user guide. Do not use it for other purposes. DANGER: Do not connect the inverter with reverse polarity, as doing so may result in a risk EXPLOSION HAZARD: (such as gas bottles).
-
Page 20: Contact Us
When it comes to energy storage and creation at iTechworld, we take pride in being one of the biggest names in the industry. Based in Australia, we are a family-owned and operated business. With many more innovative products on the horizon we are committed to constantly raising the bar to provide bigger and better benefi ts to all our customers Australia-wide.
