Summary of Contents for Shimano Steps OPUS ELECTRIC
- Page 1 ELECTRIC QUICK START GUIDE...
- Page 2 SHIMANO STEPS is for all you people - young, old and in between - who love to cycle and get outdoors, and put a premi- um on healthy living.
- Page 3 CONNECTING / REMOVING THE BATTERY LOCK! CLICK! REMOVE BATTERY PRIOR TO BEFORE RIDING YOUR TRANSPORT AND STORE ELECTRIC BIKE, MAKE SURE SEPARATELY. THE BATTERY IS FIRMLY ATTACHED. CONNECTING To position in the holder, align the indentation from the bottom of the battery with the protrusion on the holder. Slide to the right until a clicking sound is heard.
- Page 4 POWERING THE MOTOR ON /OFF 2 SECONDS PRESS ONCE. DO NOT STEP ON THE PEDAL WHEN TURNING THE SYSTEM ON /OFF. Power on the system by holding down the cycle computer’s “POWER” button for 2 seconds and press the battery’s “POWER” button once.
- Page 5 CYCLE COMPUTER DISPLAY CLIC! INSTALLING Slide the cycle computer onto the bracket. It should click into place. To remove, simply push the lever on the bracket while sliding out the computer. Light Icon Current Time Battery Charge 08:23 Current Speed km/h Assist Mode Display Speed Unit Display...
- Page 6 SETTING THE SUPPORT MODE Changes the cycle computer’s display Higher assistance level Lower assistance level Set the support mode by using the assist switch. Choose one of the 5 modes by using the UP / DOWN buttons. Low level of assistance; best for long distances. NORMAL Intermediate level of assistance;...
-
Page 7: Battery Status Indicator
BATTERY STATUS INDICATOR RANGE Based on field testing, the confirmed ranges are as follows*: 125 km MAKE SURE TO HAVE A SUFFICIENT CHARGE BEFORE USING THE SYSTEM. 100 km 75 km 50 km 25 km 0 km NORMAL HIGH Approximate Maximum Distance (km) * Ranges may vary due to load, road and weather conditions. -
Page 8: Charging The Battery
CHARGING THE BATTERY CHARGE TIME 80% charge in 2.5 hours, 100% charge in 4 hours. *MAKE SURE TO FULLY CHARGE THE BATTERY BEFORE YOUR FIRST USE. Battery mount charger connector Charger plug WHEN CHARGING OFF THE BIKE, MAKE SURE TO CHARGE PRESCRIBED CHARGING THE BATTERY ON A FLAT AND TEMPS ARE BETWEEN... - Page 9 CONTACT US HAVE ANY QUESTIONS? Contact us at info@opusbike.com or visit our website. OPUSBIKE.COM...
