Series CL220BR
Bromine Feeder
Owner's Manual
Hayward Industries
1415 Vantage Park Dr., Suite 400
Charlotte, NC 28203
Phone: (908) 355-7995
www.hayward.com
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Contents
Safety Instructions..................1
Installation.............................5
Operation................................7
Maintenance...........................8
Specifications.........................9
Replacement Parts................10
Warranty............................Back
CL220BR
ISCL220BR RevE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hayward CL220BR Series
Summary of Contents for Hayward CL220BR Series
-
Page 1: Table Of Contents
ISCL220BR RevE Series CL220BR Bromine Feeder Owner's Manual Contents Safety Instructions....1 Installation......5 Operation........7 Maintenance......8 Specifications......9 Replacement Parts....10 Warranty......Back CL220BR Hayward Industries 1415 Vantage Park Dr., Suite 400 Charlotte, NC 28203 Phone: (908) 355-7995 www.hayward.com USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 2: Safety Instructions
– Wear eye and skin protection while maintaining or servicing this unit. WARNING – Do not inhale fumes from the brominator or chemical container. WARNING – Bromine feeder may be under pressure. Use caution removing cover. SAVE THESE INSTRUCTIONS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... - Page 3 – Failure to keep suction outlet components clear of debris, such as leaves, dirt, hair, paper and other material can result in an increase potential for suction entrapment as described above. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 4 To reduce the risk of electric shock, do NOT use an extension cord to connect unit to electric supply. Provide USE ONLY HAYWARD GENUINE REPLACEMENT PARTS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 5 A storable pool is constructed so that it is capable of being readily disassembled for storage and reassembled to its original integrity. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 6: Installation
If you have brass or bronze backwash valves, or other sensitive metallic components, consult your dealer for precautions or recommendations for your particular system. NOTICE – After starting up system, re-check all connections for leaks. Re-tighten as required. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... - Page 7 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 8: Operation
Refill bromine feeder with slow dissolving Bactericide-Algaecide-Disinfectant-Bromine Tablets. Secure cover to bromine feeder. If installed in a flooded system, open valves to assure flow from pump to pool. 10. Turn flow control valve on brominator to desired setting and restart pump. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 9: Maintenance
When vacuuming, close flow control valve to prevent bypass of sediment and possible clogging of control valve. Lubrication Never use petroleum type lubricants on Cover O-Ring. To lubricate use Genuine Hayward Part Jack’s Lube No. 327 (Part No. SP032712). USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 10: Specifications
Maximum Rated Output of CL220BR Control Position Bromine Pounds Per Day Pool 100% 2.45 Pool 50% 0.66 Spa 100% 3.80 Spa 50% 0.33 Maximum Head Loss 2.01 PSI @ 0.75 GPM Dimensions CL200BR 14-3/4" 7-3/4" USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 11: Replacement Parts
Cover CLX220G Saddle Fitting CLX200K O-Ring CLX220K Saddle Clamp CLX200H Feeder Tube (Some Models) CLX220J Plastic Tubing - 8 ft. CLX200PA Control Valve Assembly SP032712 Hayward Jack's Lube #327 3/8" Hole Saddle Clamp Assembly USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 12: Warranty
Hayward Industries, Inc. © 2024 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties. For patent information, refer to www.hayward.com/patents.
