- Page 1 Tre Modular - Replicant ADSR DIY Assembly Guide v2.2 Thank you for choosing Tre Modular. In this guide, we will walk you through the process of assembling your very own Tre Modular - Replicant ADSR module.
-
Page 2: Before You Begin
Always adhere to proper soldering techniques, work in a well-ventilated space, and handle electronic components with care to ensure the longevity and optimal performance of your Replicant ADSR. Ensure you have all the necessary components listed in the Bill of Materials. - Page 3 Legend: Front:...
- Page 4 Back:...
-
Page 5: Assembly Guide
Assembly Guide: Step 1: Identify and Sort Components Organize the components into groups based on their types: resistors, capacitors, diodes, potentiometers, connectors, switches and jack sockets. Step 2: Diodes (Front) Insert and solder diodes according to the legend. 1N4148 are placed vertically. 1N4148 diodes For easier soldering, when diode... - Page 6 Step 6: Diodes (Back) Insert and solder 1N4002 diodes according to the legend. Ensure correct orientation, referring to the diode's polarity. Step 7: 10uf Capacitors (Back) Solder 10uf capacitors onto the designated positions on the PCB according to legend. Ensure correct orientation of capacitors, referring to the capacitors polarity. Step 8: Power Connector Solder the IDC connector (Power connector) into its designated spot.
-
Page 7: Additional Information
If the module is working as it should. Insert the module into an available slot in your rack and secure it in place. Enjoy! Additional Information: For any additional questions or support, please contact Tre Modular at support@tremodular.com Happy patching!
